Makita Spare Parts for Sander SA5040C
€22.33
Tax included
Makita Spare Parts for Sander SA5040C
We have the Makita original Spares for Sander 125 mm SA5040C, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Sander 125 mm SA5040C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Sander SA5040C
Fix Your Sander 125 mm SA5040C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Sander and the respective parts of the code.
| Sander SA5040C | ||
| # | Part Num. | Description |
| 1 | 168705-9 | GEAR BOX FOR GA |
| 2 | 252137-1 | NUT M5X8 |
| 3 | 267034-8 | FLAT WASHER 5 X 4302C |
| 4 | 227595-0 | GEAR FOR 7 GA |
| 5 | 211142-7 | BEARING 6001LLB X GD0800C |
| 6 | 318835-8 | COVER GEAR BOX |
| 10 | 253084-9 | ROND.P.12 8419B / 5016NB |
| 11 | 240134-9 | FAN FOR 60 GA |
| 12 | 515383-0 | ARMATURE |
| 13 | 681656-4 | INSULATING WASHER X GD0810C |
| 14 | 253823-7 | ROND. FLAT 7 X JS1600 |
| 15 | 210027-4 | BEARING 627DDW X 9561CV |
| 16 | 421738-8 | RING LABYRINTH 22 X 9561CV |
| 17 | 267756-0 | WAVY WASHER X BO6040 |
| 18 | 688117-5 | SOCKET X GD0800C |
| 19 | 259039-2 | LOCKING 6 X 9566CV |
| 22 | 453367-9 | FLAP |
| 23 | 266258-3 | SCREW 4 X 70 X 9564 |
| 24 | 344871-8 | RETAINING X GD0800C |
| 25 | 626653-3 | STATOR 220-240V |
| 27 | 191978-9 | CARBON BRUSHES CB 318 (EX 310) |
| 28 | 266007-8 | SCREW M3 X10 HP2030 |
| 29 | 643769-9 | HOLDER BRUSHES |
| 30 | 453366-1 | HOUSING MOTOR |
| 31 | 266326-2 | SCREW 4x18 X MT601 |
| 32 | 687169-3 | CLAMP cable tie HP1620 |
| 33 | 638947-4 | HOLDER SWITCH |
| 35 | 682559-5 | SAVE CABLE X 6822 |
| 36 | 266326-2 | SCREW 4x18 X MT601 |
| 38 | 453365-3 | BACK COVER C |
| 39 | 620127-6 | REGULATOR |
| 40 | 651418-4 | SWITCH ST115A-40 X 9541 |
| 42 | 233071-4 | SPRING COMPRESSION 4 X 9541 |
| 43 | 453847-5 | LEVER SWITCH |
| 44 | 453368-7 | KEY SWITCH |
| 46 | 453369-5 | BUTTON |
| 47 | 234057-1 | SPRING COMPRRESSIONE 6 GA5021C |
| 48 | 266361-0 | SCREW 4 X 30 X 9554NB |
| 49 | 213032-0 | RING 4 X GA4530 |
| 50 | 256535-1 | PLUG FOR 6 GA |
| 51 | 263002-9 | PIN RUBBER 4 |
| 52 | 210026-6 | BEARING 696ZZ |
| 53 | 961005-4 | RETAINING RING S9 |
| 54 | 253180-3 | FLAT WASHER 10 X 6221DW |
| 55 | 310508-9 | SOCKET FOR GA |
| 56 | 346556-2 | C PLATE FOR GA |
| 57 | 227596-8 | GEAR FOR 37 GA |
| 58 | 313228-4 | JUNCTION FOR GA |
| 59 | 210302-8 | BEARING 6903ZZ FOR GA |
| 60 | 253744-3 | ROND.PIANA 12 24B / 12N / 14 |
| 61 | 263002-9 | PIN RUBBER 4 |
| 62 | 213641-5 | RING FOR 51 GA |
| 63 | 318837-4 | BEARING BOX |
| 64 | 265490-6 | SCREW M4 X 16 X 9561CV |
| 65 | 211129-9 | BALL BEARING NSK 6201DD |
| 66 | 267279-8 | FLAT WASHER 21 X HR2450FT |
| 67 | 443124-3 | FELT RING 17 GD0600 |
| 68 | 285854-8 | RETAINING BEARING 20-33 |
| 70 | 326130-2 | POST FOR GA |
| 72 | 453378-4 | COVER COVER HEAD |
| 73 | 265083-9 | SCREW M8 X 11 X 9565CVL |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s MAKITA websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to MAKITA brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
