Makita Spare Parts for Cordless Rotary Hammer Drill DHR182ZJ

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Cordless Rotary Hammer Drill DHR182ZJ

In the following table, look for the model of the Cordless Rotary Hammer Drill and the respective parts of the code.
Makita DHR182ZJ

DHR182ZJ - CORDLESS ROTARY HAMMER SDS+18V BL 3 FUNZIONI
Rif. Part Num. Description
1 286037-3 CAP 34
2 961057-5 CIRCLIP S17
3 253377-4 WASHER 17
4 458845-4 Chuck Cover Dhr182
5 257416-2 RING 21
6 216022-2 STEEL BALL 7
7 346177-0 GUIDE WASHER HR2601
8 232347-6 CONICAL COMPRESSION SPRING 21-29
9 921923-8 HEX BOLT M 8 X 120 X HR2020
10 417911-6 GRIP BASE HR1830
11 266053-1 PT SCREW PT 4X35
12 136043-7 GEAR HOUSING ASS'Y
13 213278-8 RING 13 X HR2020
14 458851-9 LOCK BUTTON
15 234264-6 COMPRESSION SPRING 3
16 136040-3 CHANGE LEVER
17 158057-6 GRI 36 ASSY HR2230
18 232473-1 COMPRESSION SPRING 8
19 347463-2 CHANGE PLATE B
20 347555-7 RETAINING RING 25
21 267304-5 FLAT WASHER 25 HR1830
22 232360-4 COMPRESSION SPRING 25 HR1841F
23 226854-9 SUR GEAR 44
24 327039-1 DRIVING FLANGE HR1841F
25 216019-1 STEEL BALL 3 DHR24 * / HR26 **
26 326886-7 TOOL HOLDER HR1841F
27 326887-5 IMACT BOLT HR1841F
28 213117-2 O-RING 11 HR2410
29 253380-5 FLAT WASHER 13 HR1841F
30 326888-3 RING 60 HR1841F
31 232357-3 COMPRESSION SPRING 10A HR1841F
32 327038-3 CU SLEEVE HR1841F
33 233942-5 RING SPRING 22
34 267175-0 FLAT WASHER 24 6914DW
35 345681-6 JOINT PLATE HR1830
36 347462-4 CHANGE PLATE A
37 233458-0 COMPRESSION SPRING 32 HR1830
38 327215-7 STRIKER
39 213832-8 O-RING 13 HR1841F
40 326890-6 PYSTON CYLINDER HR1841F
41 347127-8 GUIDE PLATE HR1841F
42 324612-8 PISTON JOINT HR1830
43 232361-2 COMPRESSION SPRING 6-13 HR1841F
44 347130-9 SPRING GUIDE HR1841F
45 961008-8 RETAINING RING S5 X 9565CLR
46 226853-1 SUR GEAR 12
47 327216-5 CAM SHAFT
48 327217-3 CLUTCH CAM
49 219029-7 SEASH BEARING 9 HR1841F
50 253733-8 FLAT WASHER 9 X 2708
51 251510-2 HSH BOLT M3X12
52 253381-3 FLAT WASHER 3 HR1841F
53 347129-4 SPRING PLATE HR1841F
54 221496-4 HELICAL GEAR 23 HR1841F
55 211016-2 BALL BEARING 626DD
56 232359-9 COMPRESSION SPRING 7 HR1841F
57 213833-6 O-RING 60 HR1841F
58 140F85-1 INNER HOUSING COM.
59 213641-5 O-RING 51 FOR GA
60 443138-2 FILTER X HR3200C
61 458848-8 AIR DUCT
62 251510-2 HSH BOLT M3X12
63 519549-4 ROTOR ARMATURE ASS'Y
64 213118-0 O-RING 12 X HR5210C
65 327227-0 RING 9
66 210162-8 BALL BEARING 609LLU HR1841F
67 267231-6 FLAT WASHER 9 X HR2020
68 458841-2 SLEEVE 12
69 210035-5 BALL BEARING 625DDW
70 210035-5 BALL BEARING 625DDW
71 232474-9 COMPRESSION SPRING 4
72 310913-0 LOCK PLATE
73 458846-2 STOPPER PLATE
74 266130-9 SCREW 3X16 X 6203/13 / 6313DW
75 629393-2 STATOR
76 652069-6 FLAT HD SCREW M3x6
77 183L14-7 MOTOR HOUSING
78 266130-9 SCREW 3X16 X 6203/13 / 6313DW
79 268076-5 PIN 6 UH200DWEX
80 266490-9 TAPPING SCREW PT 2X6
81 458847-0 SPRING SUPPORT
82 232358-1 COMPRESSION SPRING 10B HR1841F
83 422354-9 BELLOWS
84 620995-7 CONTROLLER
85 458844-6 F/R CHANGE LEVER
86 651380-3 SWITCH C3JW-6B-25
89 183L12-1 HANDLE SET
90 266130-9 SCREW 3X16 X 6203/13 / 6313DW
91 140F99-0 CAP COMPLETE
92 643874-2 TERMINAL
94 620549-0 LED CIRCUIT
96 256586-4 FLT FILLISTER 2,5
97 458850-1 GUIDE PLATE
98 232475-7 COMPRESSION SPRING 3
99 458849-6 SHATTER
100 256585-6 ROD 4
102 136154-8 TOOL HOLDER
103 136042-9 CAM SHAFT CPL
415486-9 POLE 8450/HP2032/BHR16HR1830
821552-6 MakPac Type 4 Connector Carry Case Kitbox
453974-8 Latch For Stacking Case Makpac
199544-6 HAMMER SERVICE KIT
