Annovi Reverberi Parts for Pressure Washer AR589
Annovi Reverberi original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair any issues for Pressure Washer Annovi Reverberi 589 - 14989.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi Reverberi Parts for Pressure Washer AR589
Annovi Reverberi original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair any issues for Pressure Washer Annovi Reverberi 589 - 14989.
In the following tables, look for the spare part and its respective code.
| Annovi Reverberi 589 - 14989 | ||
Chassis Pag.1 |
||
| # | Part Num | Description |
| 1 | 4580710 | Grey RAL 7042 cover |
| 2 | 4580700 | Blue RAL 5002 cover |
| 3 | 4580800 | Blue RAL 5002 cap |
| 4 | 4580672 | Grey RAL 7042 knob |
| 5 | 4582020 | Screw |
| 6 | 4580500 | Hood |
| 7 | 4580590 | Accessory holder |
| 8 | 4582020 | Screw |
| 9 | 4381640 | Rubber |
| 10 | 4582020 | Screw |
| 11 | 3080580 | Cable gland |
| 12 | 4581940 | Bracket kit |
| 13 | 3560430 | Extension |
| 14 | 3560420 | Knob |
| 15 | 4580740 | Blue RAL 5002 cap |
| Hose Reel Pag.2 | ||
| 1 | 4820410 | Cover |
| 2 | 4581950 | Screw |
| 3 | 4581960 | Washer |
| 4 | 4580540 | Bracket |
| 5 | 4101710 | Ring |
| 6 | 4200060 | Ring |
| 7 | 5460660 | O-ring |
| 8 | 4101760 | Connection |
| 9 | 4101520 | Fork |
| 10 | 4581020 | Connection |
| 11 | 4581970 | O-ring |
| 12 | 4580450 | Screw |
| 13 | 4101770 | Disc |
| 14 | 4102120 | Support |
| 15 | 4101680 | Disc |
| 16 | 50943 | Screw |
| 17 | 4580550 | Bracket |
| 18 | 50943 | Screw |
| 19 | 4101750 | Pin |
| 20 | 5460700 | Screw |
| 21 | 4101660 | Lever |
| 22 | 4101673 | Blue RAL 5002 knob |
| 23 | 4581980 | Screw |
| 24 | 4382520 | O-ring |
| 25 | 4381240 | High pressure tube |
| Carrello Pag.3 | ||
| 1 | 4580610 | Blue RAL 5002 knob |
| 2 | 4580600 | Handle |
| 3 | 50943 | Screw |
| 4 | 4581990 | Screw |
| 5 | 4582000 | Nut |
| 6 | 4580770 | Tube |
| 7 | 5460810 | Screw |
| 8 | 4821080 | Guide |
| 9 | 50943 | Screw |
| 10 | 4821110 | Hook |
| 11 | 4821020 | Spring |
| 12 | 4220271 | Blue RAL 5002 lever 5002 |
| 13 | 4580560 | Base |
| 14 | 4580620 | Accessory holder |
| 15 | 2180330 | Rubber |
| 16 | 50943 | Screw |
| 17 | 4580760 | Accessory holder Blue RAL 5002 |
| 18 | 50943 | Screw |
| 19 | 4581960 | Washer |
| 20 | 4582010 | Screw |
| 21 | 4580790 | Cap |
| 22 | 4220280 | Accessory holder Blue RAL 5002 |
| 23 | 5460700 | Screw |
| 24 | 4580880 | Axle |
| 25 | 4381100 | Wheel |
| 26 | 4980170 | Washer |
| 27 | 4980160 | Pin |
| 28 | 4381631 | Protection Grey RAL 7042 |
| Elettropompa Pag.4 | ||
| 1 | 4580100 | Electric pump pre-assembly |
| 2 | 3400540 | Bearing |
| 3 | 2900500 | Screw |
| 4 | 4381890 | Rubber |
| 5 | 4240690 | Cable |
| Pump Pag.5 | ||
| 1 | 47512 | Pump kit |
| 2 | 46756 | Head pre-assembly |
| 3 | 3400970 | Head |
| 4 | 740290 | OR gasket |
| 5 | 3401000 | Connection |
| 6 | 1460431 | OR gasket |
| 7 | 2901070 | Shutter |
| 8 | 3780450 | Spring |
| 9 | 3401100 | Injector |
| 10 | 2840890 | OR gasket |
| 11 | 3960430 | Connection |
| 12 | 3961100 | OR gasket |
| 13 | 1200690 | OR gasket |
| 14 | 3960440 | Cap |
| 15 | 43456 | Pressure gauge |
| 16 | 620301 | Cap |
| 17 | 1682800 | OR gasket |
| 18 | 3720730 | Cap |
| 19 | 42709 | Regulation valve kit |
| 20 | 600180 | OR gasket |
| 21 | 2901270 | Seat |
| 22 | 1460151 | Piston |
| 23 | 770140 | OR gasket |
| 24 | 2841520 | OR gasket |
| 25 | 1344870 | Piston guide |
| 26 | 1080190 | OR gasket |
| 27 | 2021900 | Piston |
| 28 | 600180 | Gasket OR |
| 29 | 1080401 | Ring |
| 30 | 1343450 | Plate |
| 31 | 1460190 | Spring |
| 32 | 1980220 | Plate |
| 33 | 1344881 | Insert |
| 34 | 1080070 | Pin |
| 35 | 1980470 | Screw |
| 36 | 1060120 | Nut |
| 37 | 800220 | Screw |
| 38 | 3400650 | Cap |
| 39 | 2849051 | Complete valve |
| 40 | 2841520 | OR gasket |
| 41 | 2841530 | Cap |
| 42 | 2841910 | Water seal |
| 43 | 770590 | OR gasket |
| 44 | 2840550 | Bush |
| 45 | 2841390 | Bush |
| 46 | 1683500 | Oil seal |
| 47 | 3400020 | Piston guide |
| 48 | 3040510 | OR gasket |
| 49 | 2901170 | Spring |
| 50 | 2840530 | Piston |
| 51 | 2840050 | Retainer |
| 52 | 1120680 | OR gasket |
| 53 | 600180 | OR gasket |
| 54 | 2022040 | Rod |
| 55 | 2021630 | Spring |
| 56 | 2021650 | Washer |
| 57 | 1260821 | OR gasket |
| 58 | 1344830 | Connector |
| 59 | 42580 | TSS Retrofit Kit |
| 60 | 47507 | TSS box pre-assembly |
| 61 | 2022201 | Fork |
| A | 2233 | Valve kit |
| B | 2313 | Piston kit |
| C | 47509 | Oil seal kit |
| F | 47369 | OR gasket kit |
| Motor Pag.6 | ||
| 1 | 4581310 | Engine |
| 2 | 3400800 | Bearing |
| 3 | 4380400 | Pump body |
| 4 | 1460590 | Bearing |
| 5 | 4380410 | Shield |
| 6 | 2020990 | Washer |
| 7 | 5580220 | Washer |
| 8 | 2320090 | Screw |
| 9 | 3440370 | Fan |
| 10 | 3441000 | Ring |
| 11 | 4380820 | Fan cover |
| 12 | 1460460 | Screw |
| 13 | 3400590 | Plate |
| 14 | 3081750 | Washer |
| 15 | 3081950 | Screw |
| Electric Circuit Pag.7 | ||
| 1 | 660170 | Gasket OR |
| 2 | 4380830 | Box |
| 3 | 1462900 | Gland |
| 4 | 2022201 | Fork |
| 5 | 2021480 | Gland |
| 6 | 2020570 | Screw |
| 7 | 4382540 | Switch |
| 8 | 390341 | OR Gasket |
| 9 | 2180670 | OR Gasket |
| 10 | 4380840 | Cover |
| 11 | 2021480 | Gland |
| 12 | 3081620 | Condenser |
| 13 | 4382450 | Headset |
| 14 | 2320640 | OR Gasket |
| 15 | 4382440 | Condenser holder |
| 16 | 1262400 | Washer |
| 17 | 2021090 | Screw |
| Standard Accessories Pag.8 | ||
| 1 | 4383510 | Gun Blue RAL 5002 |
| 2 | 3083690 | OR Gasket |
| 3 | 4821180 | Lance (Adjustable jet) |
| 4 | 4821190 | Lance (Rotopower) |
| 5 | 4581160 | High pressure foam |
| 6 | 4581170 | High pressure reinforced hose |
| 7 | 391000 | OR Gasket |
| 8 | 4382520 | OR Gasket |
| 9 | 3082130 | Water connection kit |
| Optional Pag.9 | ||
| A1 | 46575 | Gun |
| A2 | 46578 | Rotopower Lance |
| A3 | 41572 | Adjustable Lance |
| A4 | 46576 | Head |
| A5 | 40106 | Hose |
| A6 | 46581 | High pressure reinforced hose |
| A7 | 46580 | Foam |
| A8 | 41552 | Foam |
| A9 | 41687 | Patio |
| A10 | 46359 | Patio |
| A11 | 46368 | Patio Pro |
| A12 | 41577 | Fixed Brush |
| A13 | 41578 | Rotating Brush |
| A14 | 46361 | Washing Brush |
| A15 | 46364 | Pipe cleaning accessory |
| A16 | 46366 | Pipe cleaning accessory |
| A17 | 41588 | Pipe cleaning accessory |
| A18 | 41693 | Pipe cleaning accessory |
| A19 | 46582 | Extension (high pressure reinforced hose ) |
| A20 | 46354 | Underbody lance |
| A21 | 41590 | Underbody lance |
| A22 | 41762 | Sandblasting lance |
| A23 | 3207 | Sand |
| A24 | 41770 | Sand |
| A25 | 41592 | Water suction |
| A26 | 47332 | Water suction |
| A27 | 41580 | Quick coupling |
| A28 | 40439 | Quick coupling |
| A29 | 41593 | Water filter |
| A30 | 41663 | Water filter |
| A31 | 41758 | Adapter |
| A32 | 41872 | Car and Boat Cleaner |
| A33 | 41871 | Bike and Motorcycle Cleaner |
| A34 | 43487 | Decking Surface Cleaner |
| A35 | 43485 | Solar Panel Cleaner |
| A36 | 43484 | Synthetic Grass Cleaner |
| A37 | 43486 | Wall and Stone Cleaner |
| A38 | 43483 | Awning Cleaner |
| A39 | 43488 | Glass Cleaner |
| A40 | 41870 | Universal Cleaner |
| A41 | 43491 | Universal Cleaner |
| A42 | 46705 | 1 lt Cleaner |
| A43 | 46706 | HYG Cleaner 5 lt |
| A44 | 46707 | HYG Cleaner 12 lt |
