Makita Spare Parts for SDS-Plus Rotary Hammer HR2300
€48.75
Tax included
Makita Spare Parts for SDS-Plus Rotary Hammer HR2300
MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Rotary Hammer SDS-PLUS 720W SDS-PLUS HR2300.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for SDS-Plus Rotary Hammer HR2300
MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Rotary Hammer SDS-PLUS 720W SDS-PLUS HR2300.
In the following table, look for the model of Hammer and the respective parts of the code.
| ROTARY HAMMER 720W SDS-PLUS 2300 | ||
| # | Part Num. | Description |
| 1 | 286288-8 | CAP 35 HR2601 |
| 2 | 451533-2 | FRONT COVER HR2601 |
| 3 | 325813-1 | RING 21 HR2601 |
| 4 | 346177-0 | GUIDE WASHER HR2601 |
| 5 | 233916-6 | SPRING 21-29 X HR2020 |
| 6 | 233989-9 | CIRCLIP 14 HR2601 |
| 7 | 346221-3 | WASHER 16 HR2601 |
| 8 | 122878-2 | SIDE HANDLE CPL HR2601 |
| 9 | 346181-9 | GRIP SPRING 50 HR2601 |
| 10 | 266349-0 | SCREW M8x50 HR2601 |
| 11 | 451539-0 | GRIP BASE HR2601 |
| 12 | 313179-1 | RACK HR2601 |
| 13 | 451540-5 | LOCK BUTTON HR2601 |
| 14 | 233360-7 | COMPRESSION SPRING 4 X MT952 |
| 15 | 154935-8 | HANDLE 36 HR2601 |
| 16 | 140270-0 | GEAR BOX HR2300 |
| 17 | 331890-3 | CUP SLEEVE HR2601 |
| 18 | 211294-4 | BALL BEARING 6806LLU HR2601 |
| 19 | 232152-1 | LEAF SPRING X 6832 |
| 20 | 325785-0 | PUSH CORN HR2601 |
| 21 | 234147-0 | COMPRESSION SPRING 5 HR2601 |
| 22 | 253308-3 | WASHER 6 43SB / 6510B-2 / 5016N |
| 23 | 213381-5 | O-RING 21 NEW HR3510 / 20 |
| 24 | 451531-6 | LEVER B HR2601 |
| 25 | 451532-4 | COVER LEVER HR2601 |
| 26 | 216022-2 | STEEL BALL 7 |
| 27 | 216019-1 | STEEL BALL 3 X 6960DW |
| 28 | 140264-5 | TOOL HOLDER HR2300 |
| 29 | 313149-0 | FLANGE HR2601 |
| 30 | 227232-6 | GEAR 51 HR2601 |
| 31 | 268226-2 | PIN 6 X HK1820 / L |
| 32 | 267414-8 | WASHER 30 HR2601 |
| 33 | 234148-8 | COMPRESSION SPRING 31 HR2601 |
| 34 | 267153-0 | WASHER 30 HR2601 |
| 35 | 257932-4 | SPIRO LOCK WASHER 30 HR2601 |
| 36 | 267153-0 | WASHER 30 HR2601 |
| 37 | 325782-6 | SLEEVE 9A MT870 |
| 38 | 325789-2 | IMPACT BOLT HR2601 |
| 39 | 325794-9 | O RING 10A MT870 |
| 40 | 424267-0 | O-RING SHOCK 12 |
| 41 | 325798-1 | O-RING CASE A MT870 |
| 42 | 213073-6 | O-RING 9 X HR2020 |
| 43 | 233979-2 | CIRCLIP 28 HR2601 |
| 44 | 325784-2 | STRIKER HR2601 |
| 45 | 213258-4 | O-RING 17.5 X HR2210 / 20 |
| 46 | 310345-1 | PISTON CYLINDER HR2601 |
| 47 | 346036-8 | GUIDE PLATE BHR261D |
| 48 | 324215-8 | PISTON PIN X X HR2020 |
| 49 | 234098-7 | COMPRESSION SPRING 14 BHR261D |
| 50 | 211012-0 | BEARING X 9524NB |
| 56 | 227243-1 | GEAR 10 HR2601 |
| 57 | 331815-7 | CAM CLUTCH B HR2601 |
| 58 | 219020-5 | SWASH BEARING 10 HR2601 |
| 59 | 267234-0 | FLAT WASHER 8 X HR2020 |
| 60 | 310344-3 | BEARING BOX HR2601 |
| 61 | 211032-4 | BEARING X 1902 |
| 62 | 266437-3 | SCREW M4x16 FRENAFIL X HR4001C |
| 63 | 285735-6 | RETAINING BEARING HR2601 |
| 64 | 227719-8 | GEAR 26 HR2601 |
| 65 | 213728-3 | RING 68 X BHR261D |
| 68 | 443153-6 | FELT HR2601 |
| 69 | 141572-7 | INNER HOUSING HR2300 |
| 70 | 213407-3 | SEAL 26 X 3901 |
| 71 | 213133-4 | SEAL OIL 12 X HR2800 |
| 72 | 262569-4 | SLEEVE 9 HR2601 |
| 73 | 211097-6 | BEARING 5604R |
| 74 | 961006-2 | RETAINING RING S10 |
| 75 | 240121-8 | FAN 65 HR2601 |
| 76 | 515354-7 | ARMATURE HR2300 |
| 77 | 681652-2 | INSULATION WASHER X JR180D |
| 78 | 210023-2 | BEARING 9910/11 |
| 79 | 267804-5 | WASHER 15 HR2230 |
| 83 | 266361-0 | SCREW 4 X 30 X 9554NB |
| 84 | 451527-7 | BUFFLE HR2601 |
| 85 | 626629-0 | STATOR FIELD HR2300 |
| 86 | 451538-2 | MOTOR HOUSING HR2300 |
| 89 | 194074-2 | CARBON BRUSHE CB-325 X 9554NB |
| 90 | 638655-7 | BRUSHE HOLDER HR2601 |
| 91 | 266556-5 | SCREW 3X12 HR26001 |
| 92 | 266361-0 | SCREW 4 X 30 X 9554NB |
| 95 | 682566-8 | CORD GUARD X HR2450 |
| 97 | 650625-6 | SWITCH HR2601 |
| 99 | 687682-1 | CORD CLAMP X JS1000 |
| 100 | 266385-6 | 4x14 SCREW FOR GA9020 |
| 101 | 266326-2 | SCREW 4x18 X MT601 |
| 102 | 451528-5 | COVER HANDLE HR2601 |
| 103 | 266326-2 | SCREW 4x18 X MT601 |
| 104 | 267447-3 | WASHER 14 HR2601 |
| 105 | 233992-0 | CIRCLIP 15 HR2601 |
| 106 | 267437-6 | WASHER 17 HR2601 |
| 107 | 424364-2 | WASHER RUBBER 16 HR2601 |
| 999 | 195105-0 | SERVICE KIT HR2300 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
