Makita Spare Parts for Brushcutter EM3400L
€20.81
Tax included
Makita Spare Parts for Brushcutter EM3400L
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Brushcutter EM3400L.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Brushcutter EM3400L
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Brushcutter EM3400L.
In the following table, look for the model of Brush Cutter and the respective parts of the code.
| EM3400L - BRUSHCUTTER 34CC MAKITA pag.1 | ||
| # | Part Num. | Description |
| 1 | 195251-9 | LOOP HANDLE SET INC. 2,3,4 |
| 2 | 911253-5 | PAN HEAD SCREW M5X30 |
| 3 | 451596-8 | LOOP HANDLE 28 MS335.4C |
| 4 | 451597-6 | HANDLE CLAMP 28 MS335.4C |
| 13 | 125558-9 | HANGER ASSEMBLY EBH341U |
| 14 | 922232-8 | HEX. SOCKET HEAD BOLT M5X20 |
| 20 | 142837-0 | SHAFT PIPE COMPLETE X EM3400L |
| 21 | 443146-3 | FELT RING 8 EBH341U |
| 22 | 325675-7 | SHAFT EBH341U |
| 23 | 266617-1 | SCREW M6X23 |
| 24 | 346973-6 | PROTECTOR CLAMP X EM3400L |
| 25 | 911263-2 | PAN HEAD SCREW M5X40 |
| 26 | 264035-7 | HEX. NUT M5 RBC2510 |
| 27 | 451878-8 | UPPER PROTECTOR EM3400L |
| 28 | 140424-9 | PROTECTOR COMPLETE INC. 29,30 RBC2510 |
| 29 | 346262-9 | CUTTER X EM3400L |
| 30 | 266574-3 | TAPPING SCREW 5X25 |
| 50 | 922213-2 | H.S.H.BOLT M5X12 WITH WR EBH341U |
| 51 | 126506-1 | GEAR CASE ASSYMBLY INC. 52-68 EM3400L |
| 52 | KC00000014 | HEX BOLT M6X8 M6X8 |
| 53 | KC00000009 | BALL BEARING 629 |
| 54 | KC00000008 | PLATE |
| 55 | KC00000012 | BALL BEARING 6201DDU |
| 56 | KC00000005 | RETAINING RING R-32 |
| 57 | KC00000003 | GUARD EM3400L |
| 58 | KC00000007 | P.H.SCREW M4X20 WITH W |
| 59 | KC00000013 | RECEIVE WASHER EM3400L |
| 60 | KC00000004 | CLAMP WASHER X EM3400L |
| 61 | 168526-9 | CUP EBH341U |
| 62 | KC00000016 | HEX NUT M10 |
| 63 | KC00000015 | HEX. SOCKET HEAD BOLT M6X30 WR |
| 64 | KC00000017 | CUTTER SHAFT SET X EM3400L |
| 65 | KC00000011 | BALL BEARING 6000 |
| 66 | KC00000010 | BALL BEARING 6000Z |
| 67 | KC00000006 | RETAINING RING S-10 |
| 68 | 257988-7 | RETAINING RING (INT) R-26 RBC2510 |
| EM3400L - BRUSHCUTTER 34CC MAKITA pag.2 | ||
| 5 | 126505-3 | CONTROL LEVER ASS'Y INC. 81-98 EM3400L |
| 81 | 266130-9 | TAPPING SCREW BIND PT 3X16 X 6203/13 / 6313DW |
| 82 | 451595-0 | SWITCH COVER MS335.4C |
| 83 | 451594-2 | SWITCH LEVER MS335.4C |
| 84 | 232251-9 | LEAF SPRING EBH341U |
| 85 | 187574-9 | LEVER CASE SET INC. 97 X EM4350LH |
| 86 | 346249-1 | PIPE CLAMP 28 MS335.4C |
| 87 | 922218-2 | H.S.H.BOLT M5X14 WITH WR EBH341U |
| 88 | 451593-4 | LOCK LEVER MS335.4C |
| 89 | 233541-3 | TORSION SPRING 7 EBH341U |
| 90 | 168868-1 | CONTROL CABLE X EM3400L |
| 91 | 233540-5 | TORSION SPRING 11 EBH341U |
| 92 | 451592-6 | THROTTLE LEVER MS335.4C |
| 93 | 638676-9 | LEAD UNIT MS335.C |
| 94 | 638677-7 | LEAD UNIT MS335.4C |
| 95 | 456083-2 | CORRUGATE TUBE X EM3400L |
| 96 | 266326-2 | TAPPING SCREW 4X18 X MT601 |
| 97 | 187574-9 | LEVER CASE SET INC. 85 X EM4350LH |
| 98 | 325907-2 | LOCK PIN X EM4350LH |
| EM3400L - BRUSHCUTTER 34CC MAKITA pag.3 | ||
| 101 | 911218-7 | PAN HEAD SCREW M5X14 |
| 102 | 632D74-3 | LEAD UNIT X EM3400L |
| 103 | 345963-6 | CLAMP EBH341U |
| 104 | 455371-4 | CYLINDER COVER EM3400L |
| 105 | 911218-7 | PAN HEAD SCREW M5X14 |
| 106 | 126418-8 | IGNITION COIL ASSEMBLY INC. 107-109 X EM3400L / MS-34C |
| 107 | ZG00000001 | IGNITION COIL WIRE EM3400L |
| 108 | ZG00000002 | CAP,PLUG EM3400L |
| 109 | ZG00000003 | SPRING,PLUG CAP EM3400 |
| 111 | 922138-0 | H.S.H.BOLT M4X20 WITH WR |
| 112 | 452049-0 | SPACER EX2650LH |
| 113 | 266917-9 | HEX. SOCKET HEAD BOLT M5X55 |
| 114 | 165754-7 | EXHAUST MUFFLER X EM3400L |
| 115 | 346829-3 | MUFFLER GASKET EM3400L |
| 116 | 442208-4 | CYLINDER GASKET EM3400L |
| 117 | 319133-3 | CYLINDER X EM3400L |
| 118 | 922231-0 | HEX. SOCKET HEAD BOLT M5X20 |
| 119 | 442210-7 | INSULATOR GASKET X EM3400L |
| 120 | 455378-0 | INSULATOR X EM3400L |
| 121 | 922243-3 | HEX. SOCKET HEAD BOLT M5X25 X 2702 |
| 122 | 168648-5 | SPARK PLUG (BPMR7A) X RBC350-RBC420-PB500R |
| 123 | 424491-5 | GROMMET X DBC260 |
| 124 | 424656-9 | PLUG CAP COVER X EM3400L |
| 125 | 442177-9 | GASKET AIR CLEANER |
| 126 | 346591-0 | CARBURETOR PLATE EM3400L |
| 127 | 442177-9 | GASKET AIR CLEANER |
| 129 | 0043105550 | SCREW M5X55 XRBC520 |
| 130 | 455377-2 | AIR CLEANER COVER EM3400L |
| 131 | 911536-3 | SCREW M4X20 |
| 132 | 126502-9 | AIR CLEANER PLATE ASSEMBLY INC. 133-139 EM3400L |
| 133 | 443194-2 | AIR CLEANER ELEMENT X EM3400L |
| 134 | ZH00000001 | TAPPING SCREW CT 4X12 |
| 135 | 455374-8 | CHOKE PLATE EM3400L |
| 136 | ZH00000001 | TAPPING SCREW CT 4X12 |
| 137 | 455376-4 | AIR CLEANER CHECK PLATE X EM3400L |
| 138 | 455373-0 | AIR CLEANER PLATE X EM3400L |
| 139 | 455375-6 | CHOKE LEVER X EM3400L |
| 140 | 126501-1 | RECOIL STARTER ASSEMBLY INC. 141,142,144-150 X EM3400L |
| 141 | JL03007287 | PLATE X EM3400L |
| 142 | JL03007280 | STARTER KNOB EM3400L |
| 144 | JL03007281 | STARTER CASE COMPLETE X EM3400L |
| 145 | JL12650113 | NUT |
| 146 | JL03007284 | STARTER ROPE EM3400L |
| 147 | JL03007282 | SPIRAL SPRING EM3400L |
| 148 | JL03007283 | REEL EM34 |
| 149 | JL03007285 | WASHER |
| 150 | JL03007286 | TAPPING SCREW |
| 151 | 168863-1 | PULLEY X EM3400L |
| 152 | 424657-7 | DAMPER X EM3400L |
| 154 | 911243-8 | PAN HEAD SCREW M5X25 HR2010 |
| 155 | 922233-6 | HEX SOCKET HEAD BOLT M5X20 X DCS230T |
| 156 | 143321-8 | CLUTCH CASE COMPLETE EM3400L |
| 158 | 451157-4 | SPACER EBH341U |
| 159 | 961057-5 | RETAINING RING S17 |
| 160 | 210126-2 | BALL BEARING 6003LLU |
| 161 | 962153-2 | RETAINING RING R35 |
| 162 | 165577-3 | CLUTCH DRUM EBH341U |
| 163 | 455370-6 | TANK GUARD EM3400L |
| 164 | 922223-9 | H.S.H.BOLT M5X16 WITH WR EBH341U EX2650LH |
| 165 | 266571-9 | SHOULDER HEX. BOLT M8X23 EBH341U |
| 166 | 267849-3 | WAVE WASHER |
| 167 | 125757-3 | CLUTCH ASSEMBLY X EM3400L |
| 168 | 253762-1 | FLAT WASHER 8 X LS1040 |
| 170 | 266596-3 | HEX. HEAD BOLT M6X16 WITH W X RBK420G |
| 171 | 267427-9 | FLAT WASHER 7 M6 X RBC310 / 410 / RBK410 |
| 172 | 319137-5 | FLYWHEEL X EM3400L |
| 173 | 922233-6 | HEX SOCKET HEAD BOLT M5X20 X DCS230T |
| 174 | 318453-2 | PIPE RETAINER EBH341U |
| 175 | 318454-0 | PIPE BRACKET EBH341U |
| 176 | 424204-4 | DAMPER EBH341U |
| 177 | 961151-3 | RETAINING RING S-32 EBH341U |
| 178 | 424103-0 | PLATE EBH341U |
| 179 | 424102-2 | PLATE EBH341U |
| 180 | 163447-0 | GASOLINE FILTER X DCS230T |
| 181 | 345920-4 | HOSE CLAMP EBH341U |
| 182 | 126503-7 | TUBE ASSEMBLY EM3400L |
| 183 | 168668-9 | FUEL TANK CAP ASSY RBC2510 |
| 184 | 452920-8 | FUEL TANK CAP |
| 185 | 140436-2 | STRAP CPL EBH341U |
| 186 | 455379-8 | FUEL TANK EM3400L |
| 187 | 257359-8 | PISTON RING EM3400L |
| 189 | 319136-7 | PISTON X EM3400L |
| 191 | 268337-3 | PISTON PIN 8 |
| 192 | 233976-8-4 | CLIP EBH252L (4pcs) |
| 193 | 212702-8 | NEEDLE CAGE 810 |
| 194 | 254040-2 | WOODRUFF KEY 3 EBH341U |
| 195 | 142542-9 | CRANKSHAFT COMPLETE X EM3400L |
| 196 | 135647-2 | CRANK CASE ASS'Y INC. 197,198,200-203 EM3400L |
| 197 | 922253-0 | H.S.H.BOLT M5X30 WITH WR |
| 198 | 213628-7 | OIL SEAL RBC2510 |
| 200 | 210113-1 | BALL BEARING 6001 RBC2510 |
| 201 | 210113-1 | BALL BEARING 6001 RBC2510 |
| 202 | 442209-2 | CRANK CASE GASKET EM3400L |
| 203 | 213628-7 | OIL SEAL RBC2510 |
| 204 | 424446-0 | DAMPER RBC2510 |
| 205 | 455372-2 | GUARD X EM3400L |
| 206 | 922213-2 | H.S.H.BOLT M5X12 WITH WR EBH341U |
| 209 | 922341-3 | HEX. SOCKET HEAD BOLT M6X25 |
| EM3400L - BRUSHCUTTER 34CC MAKITA pag.4 | ||
| 128 | 168864-9 | CARBURETOR X EM3400L |
| 211 | 266704-6 | PAN HEAD SCREW M3X10RBC2510 |
| 213 | 346588-9 | BRACKET,CABLE |
| 214 | 325922-6 | CARBURETOR SWIVEL EBH341U |
| 215 | 413140-9 | WASHER EBH341U |
| 216 | 257964-1 | STOP RING E3 EBH341U |
| 218 | 424444-4 | PACKING RING RBC2510 |
| 219 | WJ00016104 | O-RING X DCS230T |
| 220 | WJ00112288 | JET X EM3400L |
| 221 | 442155-9 | PUMP GASKET EBH341U |
| 222 | 168575-6 | PUMP DIAPHRAGM EBH341U |
| 223 | 140989-1 | PUMP BODY ASSEMBLY RBC2510 |
| 224 | 352010-6 | INLET SCREEN EBH252L |
| 225 | 442154-1 | METERING DIAPHRAGM GASKET EBH341U |
| 226 | 168620-7 | METERING DIAPHRAGM FOR BHX2501 |
| 227 | 140988-3 | AIR PURGE BODY ASSEMBLY RBC2510 |
| 228 | 424314-7 | PRIMER PUMP EBH341 |
| 229 | 346270-0 | PRIMER PUMP COVER EBH341U |
| 230 | 266582-4 | TAPPING SCREW 3X24 EBH341U |
| 231 | WJ00096424 | SCREW X DCS230T |
| 232 | WJ00014477 | METERING LEVER PIN X DCS230T |
| 233 | WJ00016648 | LEVER X DCS230T |
| 234 | WJ00008282 | INLET NEEDLE VALVE X DCS230T |
| 235 | WJ00983160 | SPRING X DCS230T |
| Pag.5 | ||
| 500 | 384224503 | HEAD TAP&GO M10X1,25 + 12X1,5 |
| 501 | 1911-9227-01 | HEAD TAP&GO M10X1,25 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
