Kawasaki Spare Parts for Bruschcutter KBC 45
We are KAWASAKI original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Bruschcutter AMA Garden Powered Kawasaki KBC 45 – 84805.
In the following table, look for the model of the Bruschcutter and the respective parts of the code.
| AMA Garden Brushcutter Powered KBC 45 – 84805 | ||
| # | Part Num. | Description |
| 1 | 88676 | Clutch Drum Cpl. |
| 2.1 | 79954 | Drive Pipe |
| 3 | 88400 | Drive Shaft |
| 7 | 88401 | Handle Ass'y |
| 10.1 | 88404 | Clamp |
| 10.2 | 88403 | Harness Hook |
| 13 | 88402 | Front Grip Cpl. |
| 14 | 79950 | Stone Guard Support |
| 15.1 | 88405 | Stone Guard Support |
| 15.3 | 88406 | Stone Guard Protection |
| 17 | 88407 | Fgear Case |
| 11005 | 11005-2159 | Engine cylinder |
| 11061 | 11061-2173 | Cylinder gasket |
| 13271 | 13271-2262 | Plate |
| 14080 | 14080-2062 | Flywheel Side Cover |
| 14080A | 14080-2063 | Starter side cover |
| 34001 | 34001-2089 | Tank Guard |
| 92043 | 92043-1302 | Pin |
| 92045 | 92045-2279 | Ball Bearing 6201C3 |
| 92049 | 92049-2259 | Oil seal |
| 13001 | 13001-2166 | Piston |
| 13002 | 13002-2061 | Piston pin |
| 13008 | 13008-6067 | Piston Rings |
| 13033 | 13033-2063 | Needle Bearing |
| 49119 | 49119-2231 | Crank shaft |
| 92026 | 92026-2353 | Spacer 9x15x1.8 |
| 92033 | 92033-2058 | Circlip |
| 212 | 3915-2089 | Screw 5x16 |
| 49089 | 49089-2631 | Cylinder cover |
| 59066 | 59066-2797 | Clutch Cover |
| 92172 | 92172-2060 | screw M4x10 |
| 16073 | 16073-2220 | Spacer |
| 21050 | 21050-2313 | Flywheel Side Cover |
| 21130 | 21130-2072 | Spark-Plug Cap |
| 510 | 510A3100 | Woodruff key |
| 21169 | 21169-2051 | Terminal |
| 21171 | 21171-2250 | Ignition Coil Cpl. |
| 26011 | 26011-2113 | Wire Lead |
| 26011A | 26011-2361 | Wire Lead |
| 92070 | 92070-2107 | Spark plug BPMR7A (NGK) |
| 92153 | 92153-2135 | Screw UNl M4x20 |
| 92170 | 92170-2041 | Clamp |
| 92192 | 92192-2165 | Tube 6x6.6x80 |
| 92210 | 92210-2101 | Nut UNI M8 |
| 11049 | 11049-2006 | Bracket |
| 11060 | 11060-2111 | Gasket |
| 11061 | 11061-2054 | Gasket |
| 11061A | 11061-2175 | Carburetor gasket |
| 11061B | 11061-2176 | Cylinder gasket |
| 11061C | 11061-2178 | Gasket |
| 12022 | 12022-2059 | Valve reed |
| 14043 | 14043-2051 | Filter |
| 14090 | 14090-2017 | Primer Pump cover |
| 15004 | 15004-2050 | Carburetor Ass'y |
| 16030 | 16030-2078 | Valve-Float |
| 16055 | 16055-2051 | Lever |
| 16160 | 16160-2089 | Carburetor body |
| 16160A | 16160-2103 | Carburetor body |
| 21083 | 21083-2073 | Arm |
| 32085 | 32085-2105 | Stopper |
| 43028 | 43028-2067 | Diaphragm |
| 43028A | 43028-2096 | Diaphragm |
| 16073 | 16073-2236 | Insulator |
| 49043 | 49043-2067 | Priming pump |
| 92009 | 92009-2235 | Screw 5x20 |
| 92009A | 92009-2277 | Screw |
| 92009B | 92009-2336 | Screw |
| 92009C | 92009-2337 | Screw |
| 16002 | 16002-2056 | Adjuster Cable |
| 92015 | 92015-2145 | Bolt |
| 92033 | 92033-2078 | Snap Ring |
| 92043 | 92043-2094 | Pin |
| 92055 | 92055-2147 | oO-Ring |
| 92063 | 92063-2483 | Main-Jet |
| 92144 | 92144-2308 | Spring |
| 92172 | 92172-2091 | Screw 3x12 |
| 92200 | 92200-20744 | Washer |
| 11011 | 11011-2362 | Air Filter case |
| 11013 | 11013-2226 | Air Filter element |
| 11061 | 11061-2174 | Muffler gasket |
| 11065 | 11065-2123 | Air Filter element cover |
| 18020 | 18020-2091 | Baffle |
| 18077 | 18077-2137 | Spark Arrester |
| 49069 | 49069-2430 | Muffler Ass'y |
| 120 | 120CB0516 | Screw 5x16 |
| 242 | 242AA0512 | Screw 5x12 |
| 92153 | 92153-2128 | Knob |
| 14069 | 14069-2088 | Breather |
| 49019 | 49019-2114 | Fuel Filter |
| 51001 | 51001-2324 | Fuel Tank |
| 51048 | 51048-2083 | Tank cap ass'y |
| 92009 | 92009-2383 | Screw 5x20 |
| 92071 | 92071-2142 | Grommet |
| 92171 | 92171-2073 | Clamp |
| 92190 | 92190-2157 | Fuel Line |
| 92192 | 92192-2149 | Fuel Pipe |
| 99996 | 99996-6089 | Complete Line |
| 13165 | 13165-2103 | Pawl |
| 13169 | 13169-2386 | Recoil Starter Plate |
| 32099 | 32099-2419 | Recoil Starter Case |
| 46075 | 46075-2161 | Starter Knob |
| 49060 | 49060-2062 | Recoil Starter Cam |
| 49080 | 49080-2201 | Starter Pulley |
| 49088 | 49088-2566 | Recoil Starter |
| 59101 | 59101-2119 | Recoil Starter Reel |
| 59106 | 59106-2072 | Rope |
| 92033 | 92033-2010 | Snap Ring |
| 92144 | 92144-2054 | Starter spring |
| 92144A | 92144-2157 | Pawl spring |
| 92145 | 92145-2149 | Spring |
| 92172 | 92172-2061 | Screw 4x14 |
| 13081 | 13081-2220 | Cutch Ass'y |
| 49049 | 49049-2075 | Clutch Arm |
| 92022 | 92026-2125 | Wavy washer |
| 92043 | 92043-2210 | Clutch Pin |
| 92144 | 92144-2390 | Clutch Spring |
| 92200 | 92200-2064 | Wavy washer |
