Kawasaki Spare Parts for Bruschcutter TOP 35 – TJ035E - 62056
We have the original Spares Kawasaki for Bruschcutter TOP 35 – TJ035E - 62056 the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Kawasaki Spare Parts for Bruschcutter TOP 35 – TJ035E - 62056
We have the original Spares Kawasaki for Bruschcutter TOP 35 – TJ035E - 62056 the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Fix Your Bruschcutter TOP 35 – TJ035E. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following table, look for the model of the Bruschcutter and the respective parts of the code.
| Kawasaki TOP 35 – TJ035E - 62056 | ||
| 1 | 63729 | ENGINE 35cc |
| 2 | 55620 | CLUTHC DRUM ASS.BLY |
| 3 | 13586 | SCREW |
| 4 | 55440 | VIBRATION BEARING |
| 5 | 55441 | BEARING |
| 6 | 13580 | DRIVE SHAFT |
| 7 | 62019 | THROTTLE HANDLE |
| 8 | 62031 | HOOK |
| 9 | F32002 | NUT |
| 10 | 75539 | COMPLETE HANDLE |
| 11 | 13588 | SCREW |
| 12 | 55353 | ENGINE FLANGE |
| 13 | 55617 | HANDLE ANTI-VIBRATION |
| 14 | 73826 | COMPLETE PIPE D.28 |
| 15 | 13571 | GUARD BRACKET |
| 16 | 37944 | COMPLETE BLACK GUARD |
| 17 | 13610 | GEAR BOX |
| 18 | 13532 | UPPER FLANGE |
| 19 | 13533 | LOWER FLANGE |
| 20 | 13576 | FLANGED NUT |
| 21 | 55608 | EASY CHARGE NYLON HEAD |
| 22 | 13599 | HARNESS |
| 11005 | 11005-2160 | CYLINDER-ENGINE |
| 11061 | 11061-2192 | GASKET |
| 11065 | 11065-2130 | CAP |
| 13272 | 13272-2009 | PLATE |
| 14080 | 14080-2064 | CRANKCASE |
| 14080A | 14080-2065 | CRANKCASE |
| 34001 | 34001-2090 | STAND |
| 92043 | 92043-1302 | PIN |
| 92045 | 92045-2058 | BEARING-BALL,6201C3 |
| 92049 | 92049-2253 | SEAL-OIL,ISCD12X22X4.5 |
| 92049A | 92049-2267 | SEAL-OIL,ISCD 12X22X4.5F |
| 120 | 120CB0520 | BOLT-SOCKET,5X20 |
| 214 | 214AA0408 | SCREW-PAN+-,4X8 |
| 221 | 221AA0408 | SCREW-CSK-CROSS,4X8 |
| 225 | 225AA0530 | SCREW-PAN-WSP-CROS,5X30 |
| 13001 | 13001-2170 | PISTON-ENGINE |
| 13002 | 13002-2101 | PIN-PISTON |
| 13008 | 13008-6045 | RING-SET-PISTON |
| 13033 | 13033-2065 | BEARING-SMALL END |
| 13033A | 13033-2067 | BEARING-SMALL END |
| 49119 | 49119-2243 | CRANKSHAFT-ASSY |
| 92026 | 92026-2355 | SPACER,9X15X1.8 |
| 92033 | 92033-2061 | RING-SNAP |
| 39156 | 39156-2089 | PAD,SHROUD |
| 49089 | 49089-2643 | SHROUD-ENGINE |
| 59066 | 59066-2800 | HOUSING-FAN |
| 92172 | 92172-2060 | SCREW,4X10 |
| 233 | 233AA0516 | SCREW-PAN-WP+-,5X16 |
| 16073 | 16073-2220 | INSULATOR |
| 21050 | 21050-2317 | FLYWHEEL |
| 21130 | 21130-2074 | CAP-SPARK PLUG |
| 21130A | 21130-2077 | CAP-SPARK PLUG |
| 21169 | 21169-2051 | TERMINAL |
| 21171 | 21171-2257 | COIL-ASSY-IGNITION |
| 26011 | 26011-2113 | WIRE-LEAD |
| 26011A | 26011-2361 | WIRE-LEAD,L=230 |
| 92070 | 92070-2107 | PLUG-SPARK,BPMR7A(NGK),SOLID |
| 92153 | 92153-2134 | BOLT,4X20 |
| 92170 | 92170-2041 | CLAMP |
| 92192 | 92192-2165 | TUBE,6X6.6X80 |
| 92210 | 92210-2094 | NUT,M8 |
| 510 | 510A3100 | KEY-WOODRUFF |
| 11049 | 11049-2006 | BRACKET |
| 11060 | 11060-2111 | GASKET |
| 11061 | 11061-2054 | GASKET |
| 11061A | 11061-2208 | GASKET,CARBURETOR/INSULATOR |
| 11061B | 11061-2209 | GASKET,CYLINDER/INSULATOR |
| 12021 | 12021-2055 | VALVE-ASSY-REED |
| 12022 | 12022-2060 | VALVE-REED |
| 14043 | 14043-2051 | FILTER |
| 14090 | 14090-2017 | COVER,PRIMER PUMP |
| 15004 | 15004-2049 | CARBURETOR-ASSY |
| 16030 | 16030-2078 | VALVE-FLOAT |
| 16055 | 16055-2051 | LEVER |
| 16160 | 16160-2089 | BODY |
| 16160A | 16160-2141 | BODY |
| 21083 | 21083-2073 | ARM |
| 32085 | 32085-2106 | STOPPER |
| 43028 | 43028-2067 | DIAPHRAGM |
| 43028A | 43028-2096 | DIAPHRAGM |
| 43049 | 43049-2062 | PACKING |
| 49043 | 49043-2067 | PUMP-PRIMING |
| 92009 | 92009-2249 | SCREW,5X20 |
| 92009A | 92009-2277 | SCREW |
| 92009B | 92009-2336 | SCREW |
| 92009C | 92009-2337 | SCREW |
| 92009D | 92009-2354 | SCREW |
| 92015 | 92015-2145 | NUT |
| 92033 | 92033-2078 | RING-SNAP |
| 92043 | 92043-2094 | PIN |
| 92055 | 92055-2147 | RING-O |
| 92063 | 92063-2393 | JET-MAIN,#37 |
| 92144 | 92144-2308 | SPRING |
| 92172 | 92172-2091 | SCREW,3X12 |
| 92200 | 92200-2074 | WASHER |
| 234 | 234AA0560 | SCREW-PAN-WSP+-,5X60 |
| 11011 | 11011-2366 | CASE-AIR FILTER |
| 11013 | 11013-2229 | ELEMENT-AIR FILTER |
| 11061 | 11061-2193 | GASKET,MUFFLER |
| 11065 | 11065-2125 | CAP |
| 18020 | 18020-2091 | BAFFLE |
| 18077 | 18077-2139 | ARRESTER-SPARK |
| 49069 | 49069-2435 | MUFFLER-ASSY |
| 92009 | 92009-2411 | SCREW |
| 92153 | 92153-2128 | BOLT |
| 120 | 120CB0516 | BOLT-SOCKET,5X16 |
| 242 | 242AA0512 | SCREW-PAN-WSP+-,5X12 |
| 14069 | 14069-2088 | BREATHER |
| 49019 | 49019-2114 | FILTER-FUEL |
| 51001 | 51001-2336 | TANK-COMP-FUEL |
| 51048 | 51048-2083 | CAP-ASSY-TANK |
| 92009 | 92009-2383 | SCREW,5X20 |
| 92071 | 92071-2142 | GROMMET,FUEL TANK |
| 92171 | 92171-2073 | CLAMP |
| 92191 | 92191-2102 | TUBE,3X5X182 |
| 92192 | 92192-2117 | TUBE,3X6X90 |
| 99996 | 99996-6089 | CAP-TANK & BREATHER,ASSY |
| 13165 | 13165-2103 | PAWL |
| 13169 | 13169-2386 | PLATE,RECOIL STARTER |
| 32099 | 32099-2419 | CASE,STARTER-RECOIL |
| 46075 | 46075-2161 | GRIP,STARTER-RECOIL |
| 49060 | 49060-2062 | CAM,STARTER-RECOIL |
| 49080 | 49080-2201 | PULLEY-STARTING |
| 49088 | 49088-2566 | STARTER-RECOIL |
| 59101 | 59101-2119 | REEL,STARTER-RECOIL |
| 59106 | 59106-2072 | ROPE,3.5X850 |
| 92033 | 92033-2010 | RING-SNAP |
| 92144 | 92144-2054 | SPRING |
| 92144A | 92144-2157 | SPRING |
| 92145 | 92145-2149 | SPRING |
| 92172 | 92172-2061 | SCREW,4X14 |
| 92172A | 92172-2065 | SCREW |
| 13081 | 13081-2220 | CLUTCH-ASSY |
| 13081A | 13081-2236 | CLUTCH-ASSY |
| 49049 | 49049-2075 | SHOE-CLUTCH |
| 49049A | 49049-2104 | SHOE-CLUTCH |
| 92026 | 92026-2125 | WASHER |
| 92043 | 92043-2210 | PIN,CLUTCH |
| 92144 | 92144-2390 | CLUTCH SPRING |
| 92145 | 92145-2178 | SPRING |
| 92200 | 92200-2064 | WASHER,SPRING,10.5X14.5X0.3 |
