HIKOKI GM13Y Stone Grinder Parts
€1.94
Tax included
HIKOKI GM13Y Stone Grinder Spare Parts
Hitachi-HIKOKI-Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for GM13Y Stone Grinder.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
HIKOKI GM13Y Stone Grinder Spare Parts
Hitachi-HIKOKI-Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for GM13Y Stone Grinder.Open PDF File in thi page to chose Spare Parts for Polisher Sander SAT180
| HIKOKI GM13Y Stone Grinder Spare Parts | ||
| # | Part Num. | Description |
| 1 | 377379 | BOLT |
| 2 | 377383 | LOOP HANDLE |
| 3 | 377385 | GEAR COVER ASSY INCLUDING 4.5.8.9.13.20.22 |
| 4 | 377411 | PUSHING BUTTON |
| 5 | 372944 | SPRING (A) |
| 6 | 377378 | CLUTCH DISC |
| 8 | 377410 | O-RING |
| 9 | 372946 | LOCK PIN |
| 10 | 377386 | GEAR+SPINDLE SET INCLUDING 11.12.14.44.45 |
| 12 | 377380 | PCKING GLAND |
| 14 | 377376 | SPINDLE M14 |
| 15 | 377397 | V-RING |
| 16 | 937907Z | WHEEL WASHER (C) |
| 18 | 377334 | NUT M14X2 |
| 19 | 372908 | WASHER 7.05X19. 5X0.2 |
| 20 | 372907 | BALL BEARING 8X22X7 |
| 21 | 372906 | WASHER 8.05X17X0.4 |
| 22 | 372942 | RETAINING RING |
| 23 | 377328 | ARMATURE ASSY 230-240V INCLUDING 24 |
| 24 | 372938 | FAN |
| 25 | 372904 | BALL BEARING 6X19X6 |
| 26 | 372905 | RUBBER BUSHING |
| 27 | 372947 | MAGNET |
| 28 | 372901 | BAFFLE |
| 29 | 372900 | FAN GUIDE |
| 30 | 377329 | STATOR 230-240V |
| 31 | 377363 | BRUSH HOLDER SET (2PCS) + BRUSHES INCLUDED 32.33 |
| 32 | 377404 | BRUSH HOLDER SET |
| 33 | 372939 | CARBON BRUSHES SET (1 PAIR) |
| 34 | 377015 | HOUSING |
| 35 | 377369 | CONTROLLER ASSY INCLUDED 36 |
| 36 | 377366 | SWITCH |
| 38 | 377381 | SWITCH SPRING |
| 39 | 372894 | CORD ARMOR |
| 40 | 714500 | CORD 5M 2 X 1.0 WITH PLUG |
| 41 | 377371 | HANDLE SET A+B |
| 42 | 377372 | SWITCH TRIGGER |
| 43 | 371271 | CORD CLIP |
| 44 | 377384 | BEVEL GEAR PINION SET |
| 45 | 377374 | GASKET |
| 48 | 377382 | WHEEL GUARD ASSY INCLUDED 49-57 |
| 49 | 377394 | WHEEL GUARD |
| 50 | 377393 | PIN |
| 51 | 377396 | WASHER |
| 52 | 377395 | TORX SCREW |
| 53 | 377100 | BRUSH |
| 54 | 377391 | PROTECT PLATE |
| 55 | 377389 | COVER |
| 56 | 377390 | WIRE STRAP |
| 57 | 377392 | SPRING |
| 58 | 377375 | TORX SCREW |
| 501 | 377018 | BLOW CASE |
| 503 | 377098 | SPANNER |
| 604 | 372960 | GREASE (B) 100G |
| 605 | 371300 | GREASE (SF011) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
HIKOKI GM13Y
