Femi Spare Parts for Mitre Saws GOLD3 - 8436033
€3.05
Tax included
Femi Spare Parts for Mitre Saws GOLD3 - 8436033
We are FEMI original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Mitre Saws GOLD3 - 8436033.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Mitre Saws GOLD3 - 8436033
We are FEMI original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Mitre Saws GOLD3 - 8436033.
In the following table, look for the model of Mitre Saws and the respective parts of the code.
| Wood Mitre Saw GOLD3-8436033 | ||
| # | Part Num. | Description |
| 1 | 0320826 | SOCKET HEAD SCREW |
| 2 | 0120308 | WASHER |
| 3 | 0120714 | PLAIN WASHER |
| 4 | 5190299 | WHEEL FLANGE |
| 5 | 5061037 | BLADE BUSHING |
| 8 | 7130585 | LEVER AND PROTECTION GROUP |
| 10 | 5100146 | NUT |
| 11 | 5182878 | ARM PROTECTION |
| 12 | 5170001 | PROTECTION LOCKING PIN |
| 13 | 5080129 | SPRING |
| 14 | 5100147 | NUT |
| 17 | 5120655 | SPACER |
| 18 | 0536203 | BALL BEARING |
| 19 | 5000742 | BLADE SHAFT |
| 21 | 5154501 | CABLE LOCKING DEVICE |
| 23 | 5171046 | HEAD PIN |
| 24 | 0221106 | O-RING SEAL |
| 26 | 0151116 | SNAP RING |
| 27 | 7130606 | HEAD RELEASE LINKAGE ASS'Y |
| 28 | 5100143 | SPACER |
| 29 | 5080130 | SPRING |
| 30 | 0802611 | SWITCH |
| 31 | 5214400 | WHEEL |
| 33 | 5137946 | BELT SUPPORT |
| 34 | 0536202 | BALL BEARING |
| 35 | 0215111 | BELT |
| 37 | 5182871 | SWITCH COVER |
| 38 | 5133579 | RUBBER FOOT |
| 40 | 5182557 | COVER |
| 43 | 5050145 | RIGHT HANDLE |
| 44 | 5142071 | LEVER |
| 45 | 5143015 | RELEASE BUTTON |
| 46 | 5143016 | SAFETY BUTTON |
| 47 | 5143014 | SAFETY BUTTON |
| 48 | 5050146 | LEFT HANDLE |
| 49 | 5081022 | SPRING |
| 50 | 5042790 | MITRE-SAW BODY |
| 51 | 0803617 | SWITCH |
| 52 | 0894009 | LIGHT PILOT |
| 53 | 5181682 | UPPER PROTECTION |
| 54 | 5130798 | REAR GUIDE |
| 56 | 5130858 | REAR GUIDE |
| 57 | 5137945 | MOTOR SUPPORT |
| 58 | 0606202 | BALL BEARING |
| 60 | 5871068 | CABLE |
| 62 | 5152066 | BRAKE PIN |
| 63 | 5081024 | SPRING |
| 65 | 5182879 | MOTOR COVER |
| 66 | 5112027 | MOTOR FAN |
| 67 | 0526201 | BALL BEARING |
| 70 | 7801083 | MOTOR BODY |
| 71 | 7013147 | ROTOR |
| 74 | 0840202 | TRANSFORMER |
| 75 | 5130457 | SWITCH BOX SUPPORT |
| 76 | 5182880 | SWITCH BOX |
| 77 | 0811001 | MINI-CONTACTOR |
| 78 | 5171044 | SWIVEL SUPPORT PIN |
| 79 | 5181668 | LEFT PROTECTION |
| 80 | 5182541 | COVER |
| 81 | 5137894 | SWIVEL SUPPORT |
| 82 | 0140084 | KNOB |
| 83 | 5170504 | BASE LOCKING PIN |
| 84 | 5130837 | BASE EXTENSION |
| 85 | 5170503 | BASE GUIDE PIN |
| 86 | 7133625 | REST BASE SPARE PARTS |
| 88 | 5159513 | BASE INDEX |
| 89 | 5137793 | REST FOOT |
| 90 | 5137902 | ANGULAR BRACKET |
| 91 | 0140078 | WING NUT |
| 92 | 5142072 | LEVER |
| 93 | 5171023 | SWIVEL SUPPORT PIN |
| 94 | 0152330 | ELASTIC PIN |
| 95 | 5081012 | SPRING |
| 96 | 0106115 | SELF-LOCKING RING NUT |
| 97 | 0080260 | SPRING WASHER |
| 98 | 5401417 | GRADUATE PLATE |
| 99 | 5133691 | MITRE SAW BASE |
| 102 | 0150635 | CYLINDRIC PIN |
| 103 | 0152630 | SPRING PIN |
| 104 | 5130434 | CAGE |
| 105 | 0174012 | NEEDLE |
| 106 | 5064028 | FIFHT WHEEL |
| 109 | 5171045 | JOINT PIN |
| 111 | 5181669 | RIGHT PROTECTION |
| 112 | 5063038 | BUSHING |
| 113 | 0120708 | PLAIN WASHER |
| 115 | 5080151 | SPRING |
| 116 | 0064002 | BEARING FIFTH WHEEL |
| 117 | 0711528 | CAGE BEARING |
| 119 | 5124063 | WASHER |
| 120 | 0147002 | HAND LEVER |
| 121 | 0140083 | WING NUT |
| 122 | 5081024 | SPRING |
| 123 | 5155157 | RUBBER DAMPER |
| 124 | 5137930 | JOINT |
| 125 | 0596002 | BALL BEARING |
| 126 | 5001566 | SHAFT |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi GOLD3 - 8436033
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM CODE OR S/N FEMI:
- FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
New
