We supply original Hitachi-HIKOKI spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Belt Sander SB8V2.
(modificale nel modulo Rassicurazioni cliente)
(modificale nel modulo Rassicurazioni cliente)
(modificale nel modulo Rassicurazioni cliente)
We supply original Hitachi-HIKOKI spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Belt Sander SB8V2.
In the following table, look for the model of the BELT SANDER and theirs spare part.
|
BELT SANDER SB8V2
|
||
| # | Part Num. | Description |
| 1 | 327742 | PULLEY (A) |
| 2 | 6000VV | BALL BEARING 6000VVCMPS2L |
| 3 | 327739 | DUST GUIDE |
| 4 | 360797E | ARMATURE 220V-230V |
| 5 | 608VVM | BALL BEARING 608VVC2PS2L |
| 6 | 953174 | HEX. HD. TAPPING SCREW D5X55 |
| 7 | 340700G | STATOR ASS'Y 220V-230V |
| 8 | 935196 | MACHINE SCREW (W/WASHERS) M4X12 (BLACK) |
| 9 | 931701 | BEARING LOCK |
| 10 | 328209 | DUST PLATE |
| 11 | 327738 | FAN GUIDE |
| 12 | 930703 | BRUSH TERMINAL |
| 14A | 328433 | BELT COVER |
| 15 | 316321 | TAPPING SCREW (W/FLANGE) D5X45 |
| 16 | 327740 | DUST COVER |
| 17 | 327760 | HANDLE COVER |
| 18 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 19 | 937631 | CORD CLIP |
| 20 | 958049 | CORD ARMOR D8.2 |
| 20 | 940778 | CORD ARMOR D10.7 |
| 21 | 327759 | HOUSING ASS'Y |
| 22 | 938477 | HEX. SOCKET SET SCREW M5X8 |
| 25 | 958900 | BRUSH HOLDER |
| 26 | 999043 | CARBON BRUSH (1 PAIR) |
| 27 | 945161 | BRUSH CAP |
| 28 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 29 | 325085 | SWITCH (E) (1P SCREW TYPE) W/LOCK |
| 30 | 959140 | CONNECTOR 50091 |
| 31 | 328432 | VARISTOR |
| 32 | 305499 | MACHINE SCREW (W/WASHER) M3.5X6 |
| 33 | 980063 | TERMINAL |
| 35 | 938108 | TERMINAL |
| 36 | 325566 | NOISE SUPPRESSOR |
| 37 | 953184 | WASHER (B) |
| 38 | 953175 | METAL D10X14X12 |
| 39 | 953160 | IDLE PULLEY ASS'Y |
| 40 | 305490 | TAPPING SCREW (W/FLANGE) D4X30 (BLACK) |
| 41 | 327744 | CLEAR COVER |
| 42 | 319258 | ADJUSTING SCREW |
| 43 | 948213 | WASHER (B) D19 |
| 44 | 953071 | SPRING |
| 45 | 327745 | BODY ASS'Y |
| 46 | 327746 | STRIKING GUIDE |
| 47 | 949216 | MACHINE SCREW M4X10 |
| 48 | 939540 | RETAINING RING FOR D10 SHAFT |
| 49 | 953162 | SHAFT (B) |
| 50 | 953163 | SPRING |
| 51 | 949218 | MACHINE SCREW M4X14 |
| 52 | 327756 | BELT TENSIONER (A) |
| 53A | 330690 | BELT |
| 54 | 327749 | PULLEY (B) |
| 55 | 327748 | GEAR COVER |
| 56 | 6200VV | BALL BEARING 6200VVCMPS2L |
| 57 | 327750 | PINION |
| 58 | 935522 | METAL |
| 59 | 939540 | RETAINING RING FOR D10 SHAFT |
| 60 | 953151 | GEAR |
| 61 | 953175 | METAL D10X14X12 |
| 62 | 327752 | SHOE CUSHION |
| 63 | 327751 | SHOE PLATE |
| 64 | 944109 | FEATHER KEY 3X3X8 |
| 65 | 327747 | DRIVE PULLEY |
| 501 | 323011 | DAST BUG |
| 502 | ABRASIVES PAPER | |
