HIKOKI Spare Parts for Mixer UM22VYST
€14.73
Tax included
HIKOKI Spare Parts for Mixer UM22VYST
We are Dealers of Hitachi-HIKOKI original spare parts at low at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Mixer UM22VYST.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
HIKOKI Spare Parts for Mixer UM22VYST
We are Dealers of Hitachi-HIKOKI original spare parts at low at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Mixer UM22VYST.
In the following table, look for the model of the Mixer and the respective parts of the code.
| HIKOKI Mixer UM22VYST - Spare Parts List Pag.1 | ||
| # | Part Num. | Description |
| 1 | 375046 | HANDLE ASS'Y (L) |
| 2 | 375047 | HANDLE ASS'Y (R) |
| 3 | 375067 | SWITCH |
| 4 | 333609 | CLAMP |
| 6 | 375058 | INDUCTANCE UNIT |
| 8 | 375068 | CIRCUITRY BOARD |
| 14 | 375083 | SLEEVE (R) |
| 15 | 375084 | SLEEVE (L) |
| 16 | 375091 | SHAFT RING D40 |
| 17 | 375092 | DUST COVER |
| 18 | 375094 | BEARING 6203RS |
| 19 | 333620 | PIN |
| 20 | 375086 | SPINDLE |
| 21 | 375087 | KEY |
| 22 | 375093 | BEARING 6002Z |
| 23 | 375088 | SHAFT RING D17 |
| 24 | 375089 | SPINDLE GEAR |
| 25 | 375090 | SHAFT RING D12 |
| 26 | 375075 | SHAFT RING D9 |
| 27 | 375077 | SHAFT |
| 28 | 375078 | SHAFT RING D26 |
| 29 | 375079 | GEAR |
| 30 | 375080 | BEARING 6000Z |
| 31 | 375102 | SECOND PINION ASS'Y |
| 32 | 375085 | BEARING COVER ASS'Y |
| 33 | 375095 | PINION |
| 34 | 375096 | PARALLEL KEY |
| 35 | 375097 | DOUBLE GEAR |
| 36 | 375098 | WASHER M16 |
| 37 | 375076 | GEAR BOX ASS'Y |
| 40 | 375057 | HOB |
| 41 | 375081 | ARMATURE ASS'Y |
| 42 | 375055 | CABLE COVER ASS'Y |
| 44 | 375069 | CONTROLLER |
| 45 | 333634 | PROTECTIVE GUARD |
| 46 | 333635 | REAR COVER |
| 48 | 375072 | CARBON BRUSH (2 PCS.) |
| 49 | 333632 | BRUSH CAP (2 PCS.) |
| 52 | 375071 | MOTOR BOX ASS'Y |
| 54 | 375101 | STATOR (UM22VYST) |
| 55 | 375054 | AIRGUIDE SHIM |
| 56 | 375082 | LEVER ASS'Y |
| 57 | 375099 | PIVOT D6X90 |
| 58 | 375100 | COULISSE |
| 59 | 333636 | SLEEVE |
| 60 | 714500 | CORD |
| STANDARD ACCESSORIES Pag.2 | ||
| 501 | 375615 | STIRRER SET (R/L) |
