Rurmec Spare Parts for Vacuum Cleaner 35/1100 P

Vacuum Cleaner 35/1100 P - 309.500.P
#	Part Num.	Description
1	308.206	RED ON / OFF SWITCH
2	309.500.02	HANDLE
3	309.500.03	HANDLE
4	309.500.04	COVER AS7 BLUE F + FIREFLEX
5	309.500.05	SCREW TCC 5X16
6	309.500.06	REAR AXLE AS7 GRAY
7	309.500.07	FRONT AXLE AS7 GRAY
8	309.500.08	FIREFLEX DX INTERNAL RING
9	309.500.09	SCREW TCC 2.9 X 9.5
10	309.500.10	ROPE WITH TIMER
11	309.500.11	THROTTLE X THERMOSTAT
12	309.500.12	THERMOSTAT 80 °
13	309.500.13	INTERNAL RING + GASKET
14	309.500.24	ELECTRONIC BOARD
15	309.500.P15	INTERMEDIATE GASKET
16	309.500.P16	UPPER GASKET
17	309.500.P17	MOTOR 35/1100 P
18	309.500.P18	LOWER GASKET
19	309.500.23	AIR DISCHARGE FILTER
20	309.500.28	REAR GRID
21	309.500.26	FIREFLEX REAR COCHLEA AS7 CURVE
22	309.500.27	FIREFLEX LEFT INNER RING AS7
23	309.500.34	YELLOW AUTO / MAN SWITCH
24	309.500.31	WIRED CLAMP
25	309.500.30	SCREW TCC 3X20
26	309.500.32	CABLE PROTECTION
27	309.500.33	CABLE CLAMP
28	308.239	POWER CABLE
29	309.500.36	FIREFLEX BUGNATO MOTOR BASE
30	309.500.37	FIREFLEX POLIET. ENGINE BASE
31	309.500.38	MOTOR BASE
32	309.500.39	BASIC GASKET WS1 ENGINE
33	309.500.40	COMPLETE FLOAT
34	309.500.41	FLOATING BASKET
35	309.500.14	SCREW TSCC 3,9X16
38	309.500.44	TANK
39	309.500.45	HOCK TANK
40	309.500.46	SCREW TCC 5X13
41	308.245	SCREW TCC 5X22
42	309.500.48	NYLON WASHER
43	309.500.50	WASHER D.6X24X1
44	309.500.51	SPRING X SOCKET
45	309.500.52	BUTTON KEY
46	309.500.53	FILLER
47	309.500.55	GASKET
48	309.500.62	CART
49	309.500.61	GEMINI WHEEL D.50
50	309.500.60	AXLE WHEELS D.12
51	309.500.59	SCREW TCC 5X32
52	309.500.58	WHEEL D.150
53	309.500.56	STARLOCK PLAIN D.12
54	309.500.57	SATINED STUD
55	309.500.15	WIRED SOCKET
56	309.500.16	SEAL GASKET
57	309.500.17	CARTER SOCKET TOOL
58	309.500.66	RUBBER SLEEVE
60	309.500.64	ABS SLEEVE
68	309.500.54	COMPLETE FILLER
69	309.500.29	5X16 BLACK SCREW
70	309.500.22	AS9 WASHER PROTECTION
72	309.500.25	FIREFLEX REAR COCHLEA AS9
	309.500.63	FLEXIBLE HOSE 4MT AS59
	308.269	AS59 4MT FLEX. HODE LANCE
