Hitachi Spare Parts for Petrol Hedge Trimmer CH66EB3
Hitachi-HIKOKI Tanaka Original spare parts at attractive and competitive prices on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Engine Hedge Trimmer CH 66EB3.
In the following table, look for the model of Trimmer and the respective parts of the code.
| Petrol Hedge Trimmer CH66EB3 | ||
| # | Part Num. | Description |
| 1 | 6684597 | INSULATOR TUBE 50L |
| 2 | 6688050 | GROMMET |
| 8 | 6684604 | GEAR SHAFT SHIM 0.20 |
| 8 | 6684605 | GEAR SHAFT SHIM 0.30 |
| 9 | 6686208 | CRANK SHAFT COMP |
| 10A | 6696944 | PISTON PIN |
| 11 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 12A | 6699319 | SPARK PLUG ASS'Y BPMR6A |
| 13 | 6687476 | SPARK PLUG CAP |
| 14 | 6685480 | CYLINDER ASS'Y |
| 15 | 6685744 | CYLINDER GASKET |
| 16 | 6686118 | PISTON RING |
| 17 | 6684590 | CIR CLIP |
| 18 | 6685892 | PISTON SET |
| 19B | 6699079 | FRONT HANDLE |
| 20 | 6695054 | HEX. HOLE BOLT 5X40 |
| 21 | 6684834 | SPRING WASHER 5 |
| 22 | 6684918 | WASHER M5 (BLACK) |
| 23 | 6695441 | BOLT 4X12PS |
| 24 | 6688494 | CLUTCH |
| 25 | 6688570 | CLUTCH DRUM COMP. |
| 26 | 6695538 | BALL BEARING #6002Z, 32MM/OD |
| 27 | 6695285 | STOP RING C-15, OUTER |
| 28 | 6684786 | HEX. SOCKET HD. BOLT M5X30 S |
| 30 | 6684607 | OIL SEAL TB 12227 |
| 31 | 6684608 | BALL BEARING 6001 C3 |
| 32 | 6686720 | CRANK CASE GASKET |
| 34 | 6686771 | STUD BOLT 6X22 |
| 35 | 6686574 | CRANK CASE ASS'Y |
| 36 | 6693237 | STARTER HANDLE |
| 37 | 6693172 | ROPE 3X890 |
| 40 | 6695502 | HEX.HOLE BOLT 4X18PS |
| 41 | 6687014 | FAN CASE COMP. |
| 43 | 6684675 | RECOIL SPRING |
| 44 | 6693072 | STARTER ROPE REEL |
| 45 | 6684677 | DAMPER SPRING |
| 46 | 6684678 | CAM PLATE |
| 47 | 6684679 | SET SCREW |
| 48 | 6684685 | STARTER PAWL |
| 49 | 6684684 | STARTER PAWL SPRING |
| 50 | 6685101 | D4E RETAINING RING |
| 51 | 6684681 | STARTER PULLEY ASS'Y |
| 52 | 6687209 | DEFLECTOR |
| 53 | 6684612 | HEX. NUT M8 |
| 54 | 6687396 | MAGNETO ROTOR COMP. |
| 55A | 6698868 | HANDLE A |
| 56 | 6696350 | EARTH TERMINAL |
| 57 | 696352 | TAPPING SCREW D3X6 |
| 58 | 6696344 | TRIGGER LOCKOUT |
| 59 | 6696345 | THROTTLE LEVER SPRING |
| 60 | 6696355 | TAB TERMINAL |
| 61 | 6684913 | SCREW 3X10 |
| 62 | 6688366 | BUTTON STOP |
| 63 | 6694588 | STOP BUTTON MARK |
| 64 | 6696348 | SPRING (A) |
| 65 | 6696346 | LOCK LEVER |
| 66 | 6696349 | SPRING (B) |
| 67 | 6696343 | THROTTLE LEVER |
| 68A | 6698784 | CLICK SPRING |
| 69 | 6696347 | RELEASE LEVER |
| 70A | 6698828 | THROTTLE WIRE |
| 71 | 6687524 | PROTECTION TUBE 150L |
| 72 | 6696354 | STOP SWITCH ASS'Y (A) |
| 73A | 6698869 | HANDLE B |
| 74 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 75 | 6696363 | FRAME |
| 76 | 6688412 | DAMPER B |
| 77 | 6689680 | BRAKE SHAFT WASHER |
| 78 | 6684786 | HEX. SOCKET HD. BOLT M5X30 S |
| 79 | 6688485 | DAMPER COLLAR B |
| 80 | 6686111 | HANDLE SUPPORT COMP. |
| 81 | 6696359 | CLIP |
| 91 | 6684636 | TAPPING SCREW D4.5X16 |
| 92 | 6692795 | MUFFLER PROTECTOR |
| 93 | 6685114 | HEX. SOCKET HD. BOLT M5X50 |
| 94 | 6684661 | WASHER 5 |
| 95 | 6692477 | MUFFLER ASS'Y |
| 96 | 6687252 | HEAT SHIELD |
| 97 | 6692744 | MUFFLER GASKET |
| 98 | 6689891 | INTAKE PIPE GASKET |
| 99 | 6689966 | CARB. INSULATOR SET,SPARE |
| 100 | 6695515 | HEX. HOLE BOLT M5X25WS |
| 101 | 6689839 | CARBURETOR GASKET |
| 102 | 6690487 | CARBURETOR SET, WYL120 |
| 102 | 6690482 | CARBURETOR SET WYL112 |
| 105 | 6690119 | CLEANER BODY COMP. |
| 106 | 6690804 | COLLAR 7.5 |
| 107 | 6691274 | CHOKE VALVE |
| 107 | 6691272 | CHOKE VALVE |
| 108 | 6684658 | WAVE WASHER 8 |
| 109 | 6690843 | BLOW OVER CHECK BOARD |
| 110 | 6684662 | S.WASHER 5 |
| 111 | 6684660 | SCREW M5X60 |
| 112 | 6690364 | CLEANER SPONGE |
| 113 | 6690415 | CLEANER COVER ASS'Y |
| 114 | 6689737 | SPECIAL SCREW |
| 115 | 6684697 | SWIVEL |
| 116 | 6684696 | STOP RING |
| 117 | 6684695 | O-RING |
| 119 | 6684700 | INLET SCREEN |
| 121 | 6685222 | DIAPHRAGM COVER-METERING |
| 122 | 6691312 | SET SCREW |
| 123 | 6684698 | THROTTLE SET SCREW |
| 124 | 6684883 | THROTTLE VALVE |
| 125 | 6691457 | PUMP GASKET |
| 126 | 6684693 | PUMP DIAPHRAGM |
| 127 | 6685220 | DIAPHRAGM PACKING-METERING |
| 128 | 6690827 | METERING DIAPHRAGM COMP. |
| 129 | 6685139 | PRIMING PUMP COMP. |
| 130 | 6692347 | FUEL PIPE 2.5X4X80 |
| 131 | 6692244 | COLLAR 5.8 |
| 132 | 6695505 | HEX. HOLE BOLT 5X18PS |
| 133 | 6696360 | TANK |
| 133 | 6696361 | TANK - DISCONTINUED |
| 134 | 6691389 | AIR VENT ASS'Y |
| 136 | 6692171 | AIR VENT VALVE ASS'Y |
| 137 | 6684625 | TANK CAP CHAIN |
| 138 | 6691763 | TANK CAP D ASS'Y, BLACK |
| 138 | 6691714 | TANK CAP ASS'Y |
| 139 | 6692346 | FUEL PIPE 2.5X4X70 |
| 140A | 6697846 | RETURN GROMMET |
| 141 | 6684619 | CLIP,6.3 DIA. |
| 142A | 6698874 | PUMP FILTER |
| 143A | 6698715 | FUEL PIPE |
| 144 | 6687302 | CUTTER COVER |
| 145 | 6687275 | GUARD PLATE |
| 146 | 6695170 | FLANGE NUT 6 |
| 147A | 6601209 | PROTECTION PLATE |
| 148 | 6690762 | SUPPORT PLATE |
| 149 | 6695175 | LOCK NUT 6 UPS-P |
| 150 | 6684639 | BOLT WASHER 6 |
| 151 | 6688684 | GEAR CASE COMP. |
| 152 | 6688643 | GREASE NIPPLE COMP. |
| 153 | 6695475 | SPRING NUT 6 |
| 154 | 6695495 | HEX. HOLE BOLT 6X18/S |
| 155 | 6687147 | CUTTER GUIDE 734L M6 |
| 156 | 6686612 | GUIDE PLATE |
| 157 | 6686811 | CAM ROD |
| 158 | 6687086 | CUTTER BLADE A (696.5L) |
| 159A | 6698773 | GEAR 2 COMP. |
| 160 | 6688909 | GEAR CASE GASKET |
| 161 | 6692101 | GEAR CASE COVER |
| 162 | 6695547 | BALL BEARING 608 ZZ C3 |
| 163 | 6688846 | GEAR CASE B |
| 164 | 6684595 | HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 |
| 165 | 6695075 | HEX. HOLE FLUSH BOLT 6X25 |
| 166 | 6686654 | GREASE SEAL A |
| 167 | 6687187 | WASHER 7 BLACK |
| 168 | 6687158 | FIXING BOLT A M6 |
| 169 | 6695484 | HEX. HOLE BOLT 4X10S |
| 170 | 6698931 | FUEL GROMMET |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
