Hitachi Spare Parts for Grass Trimmer CG24EBDP (SL)
€2.04
Tax included
Hitachi Spare Parts for Grass Trimmer CG24EBDP (SL)
Hitachi original spare parts for to replace broken parts for to fix Grass Trimmer "SMART FIT" CG24EBDP (SL).Fix Your Engine Grass Trimmer "SMART FIT" CG24EBDP (SL). All Spares can be supplied at discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Grass Trimmer CG24EBDP (SL)
Hitachi original spare parts for to replace broken parts for to fix Grass Trimmer "SMART FIT" CG24EBDP (SL).
Fix Your Engine Grass Trimmer "SMART FIT" CG24EBDP (SL). All Spares can be supplied at discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Pole Saw and the respective parts of the code.
| MULTIFUNZIONE "SMART FIT" CG24EBDP (SL) pag.1 | ||
| # | Part Num. | Description |
| 1 | 6698950 | SEAL LOCK HEX. SOCKET HD. BOLT M5X30 |
| 2 | 6600319 | MUFFLER COVER |
| 3 | 6696326 | HEX. SOCKET HD. BOLT (W/FLANGE) M4X18 |
| 4 | 6698384 | HEX. SOCKET HD. BOLT M6X65 |
| 5 | 949432 | BOLT WASHER M6 (10 PCS.) |
| 6 | 6600004 | MUFFLER (B) |
| 7 | 6600320 | HEAT PROTECTION PANEL |
| 8 | 6698386 | HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X18 |
| 9 | 6699454 | CYLINDER COVER |
| 10 | 6600008 | COLLAR (B) |
| 12 | 6698844 | SEAL LOCK HEX. SOCKET BOLT (W/WASHERS)M5 |
| 14 | 6698468 | COVER PACKING |
| 15 | 6698469 | SCAVENGING COVER (A) |
| 16 | 6698385 | HEX. SOCKET HD. BOLT M4X12 |
| 17 | 6698700 | GLASS WASHER |
| 18 | 6698470 | SCAVENGING COVER (B) |
| 19 | 6698465 | CYLINDER |
| 20 | 6699437 | INTAKE PACKING |
| 21 | 6698387 | CARBURETOR INSULATOR |
| 22 | 6698405 | CARBURETOR PACKING |
| 23 | 6691337 | SWIVEL CAP |
| 24 | 6600321 | CARBURETOR ASS'Y WYC-36 |
| 25 | 6699287 | CABLE ADJUST STAY |
| 26 | 6696830 | SWIVEL INCLUD.25-39 |
| 27 | 6684696 | STOP RING |
| 28 | 6684692 | PUMP GASKET |
| 29 | 6684693 | PUMP DIAPHRAGM |
| 30 | 6691242 | PUMP PLATE |
| 31 | 6685222 | DIAPHRAGM COVER-METERING |
| 32 | 6691312 | SET SCREW |
| 33 | 6696829 | SET SCREW M3X12 |
| 34 | 6684695 | O-RING |
| 36 | 6691234 | CIRCUIT PLATE |
| 37 | 6696828 | PUMP BODY COMP. |
| 38 | 6685220 | DIAPHRAGM PACKING-METERING |
| 39 | 6684690 | METERING DIAPHRAGM |
| 40 | 307224 | MACHINE SCREW (W/WASHERS) M5X60 (BLACK) |
| 41B | 6601443 | FUEL PIPE |
| 42 | 6696832 | AIR CLEANER HOUSING |
| 43 | 6685139 | PRIMING PUMP COMP. |
| 44 | 6690347 | CLEANER ELEMENT |
| 45 | 6699185 | CLEANER COVER |
| 46 | 6699132 | AIR CLEANER (A) ASS'Y |
| 47 | 6684587 | CYLINDER GASKET |
| 48 | 6698404 | PISTON RING |
| 49 | 6699456 | PISTON INCLUD.42-45 |
| 50 | 6684590 | CIR CLIP |
| 51 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 52 | 6684591 | PISTON PIN |
| 53 | 6684606 | CRANK CASE ASS'Y |
| 54 | 6684609 | CRANK CASE GASKET |
| 55 | 6684607 | OIL SEAL TB 12227 |
| 56 | 6684608 | BALL BEARING 6001 C3 INCLUD.54-56,59 |
| *57 | 6696946 | SHIM T0.2 |
| *57 | 6696945 | SHIM T0.3 |
| 58 | 6696533 | CRANK SHAFT COMP. |
| 59 | 6696947 | KNOCK PIN 4X12 |
| 60 | 6684681 | STARTER PULLEY ASS'Y |
| 61 | 6685101 | D4E RETAINING RING |
| 62 | 6684684 | STARTER PAWL SPRING |
| 63 | 6684685 | STARTER PAWL INCLUD.61-63 |
| 64A | 6601570 | RECOIL STARTER BODY ASS'Y |
| 65 | 6684679 | SET SCREW |
| 66 | 6699996 | CAM PLATE |
| 67 | 6684677 | DAMPER SPRING INCLUD.65-69,71,72 |
| 68 | 6699997 | STARTER ROPE REEL |
| 69 | 6684675 | RECOIL SPRING |
| 70 | 6684673 | CARTER AVVIAMENTO |
| 71 | 6684674 | STARTER ROPE 3.5X860 |
| 72 | 6684680 | STARTER HANDLE |
| 74 | 6698921 | TANK MARK LABEL (50:1) |
| 75A | 6600422 | MUFFLER HEAT COVER |
| 76 | 6600325 | TAPPING SCREW D4X10 |
| 77 | 6600327 | MARK PLATE (T) |
| 78 | 6699000 | PRIMER LABEL |
| MULTIFUNZIONE "SMART FIT" CG24EBDP (SL) pag.2 | ||
| 12 | 6698844 | VITE M5X25 |
| 59 | 6696947 | KNOCK PIN 4X12 |
| 91 | 6699195 | MACHINE SCREW M5X20 (BLACK) |
| 92 | 6699194 | P TITE SCREW D4X20 (BLACK) |
| 93 | 6699197 | SWITCH WIRE SET |
| 94 | 6699196 | NUT M5 |
| 95 | 6699192 | STOP LEVER |
| 96 | 6699191 | LONG LEVER |
| 97 | 6699193 | RETURN SPRING |
| 98 | 6699190 | STAY SET |
| 99 | 6699133 | THROTTLE LEVER (A) ASS'Y INCLUD.91-98 |
| 100 | 6699176 | HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X12 |
| 101 | 6695492 | HEX. HOLE BOLT 5X22/S |
| 102 | 6696963 | ANTI VIBE RUBBER (A) |
| 103 | 6698643 | PIPE HOLDER (A) |
| 104 | 6698644 | PIPE HOLDER (B) |
| 105 | 6696964 | ANTI VIBE RUBBER (B) |
| 106 | 939542 | RETAINING RING FOR D12 SHAFT (10 PCS.) |
| 107 | 6699457 | FAN CASE (A) |
| 108 | 6699435 | BALL BEARING 6301ZZC3 |
| 109 | 322813 | RETAINING RING 37MM |
| 110 | 6699434 | CLUTCH SHAFT |
| 111 | 6696469 | STEP BOLT |
| 112 | 6684648 | BENT WASHER 8 |
| 113 | 6696546 | CLUTCH PLATE (A) |
| 114 | 6699130 | CLUTCH |
| 115 | 6699131 | CLUTCH WASHER (B) |
| 116 | 6685337 | FLYWHEEL NUT |
| 117 | 323212 | BOLT WASHER M8 (BLACK) |
| 118 | 6698388 | HEX. SOCKET HD. BOLT (W/WASHERS) M4X18 |
| 119 | 6699458 | IGNITION COIL ASS'Y INCLUD.120A,121 |
| 120A | 6601421 | PLUG CAP |
| 121 | 6699933 | METAL FITTING OF PLUG CAP |
| 122 | 6696544 | CORD |
| 123 | 6696545 | EARTH CORD |
| 124 | 6699289 | MAGNETO ROTOR |
| 125 | 6698716 | FUEL PIPE |
| 126A | 6699014 | FUEL PIPE L70 |
| 127 | 6697846 | RETURN GROMMET TILL 7.2015 |
| 128 | 6698402 | FUEL TANK CAP ASS'Y INCLUD.129 |
| 129 | 6698732 | TANK CAP CHAIN |
| 130 | 6698931 | FUEL GROMMET TILL 7.2015 |
| 130A | 6600358 | FUEL GROMMET SINCE 8.2015 |
| 131 | 6699558 | SPACER |
| 132 | 6699459 | SPACER (B) |
| 133 | 6600317 | TANK (B) TILL 7.2015 |
| 133A | 6600354 | TANK © SINCE 8.2015 |
| 134A | 6600351 | PUMP FILTER |
| 135 | 6696949 | CLIP |
| 136 | 6694787 | STAND |
| 137 | 6698991 | BOLT (W/FLANGE) L27.8 |
| MULTIFUNZIONE "SMART FIT" CG24EBDP (SL) pag.3 | ||
| 151 | 6684824 | HEX. BOLT 6X50 |
| 152 | 6684823 | HANDLE KNOB |
| 153 | 6684822 | SPECIAL WASHER B |
| 154 | 6684829 | HEX. SOCKET HD. BOLT M5X12 |
| 155 | 6698884 | SPRING WASHER M5 |
| 156 | 6684825 | HEX. SOCKET HD. BOLT (W/BUTTON) M6 |
| 157 | 949455 | SPRING WASHER M6 (10 PCS.) |
| 158 | 949425 | WASHER M6 (10 PCS.) |
| 159 | 6689139 | SPACER 1.6 |
| 160 | 6684819 | SPACER |
| 161 | 6684820 | PULLEY WASHER |
| 162 | 939540 | RETAINING RING FOR D10 SHAFT (10 PCS.) |
| 163 | 6699460 | MAIN PIPE (A) |
| 164 | 6684852 | LEVEL MARK |
| 165 | 6699462 | DRIVE SHAFT (A) |
| 166 | 6600504 | HANGER |
| 167 | 6699448 | LOOP HANDLE (W/BARRIER) |
| 168 | 6684828 | CAP NUT 6 |
| 169 | 6684817 | JOINT CASE INCLUD.171-180 FOR (SL) |
| 170 | 6699439 | GEAR CASE ASS'Y (4BB) |
| 171 | 949664 | HEX. SOCKET HD. BOLT M5X30 (10 PCS.) |
| 172 | 6695414 | SCREW 5X12/W.S |
| 173 | 6600005 | CAP |
| 174 | 6600006 | SPRING |
| 175 | 6684737 | BOLT (W/PLUS) M6X8 |
| 176 | 6600007 | LOCK PIN |
| 177 | 6699441 | CUTTER HOLDER (A) |
| 178 | 6698659 | CUTTER HOLDER (B) |
| 179 | 6699188 | NUT COVER |
| 180 | 335759 | U-NUT (LEFT HAND) M10 |
| 181 | 6698794 | COVER |
| 183 | 6698795 | SET SCREW |
| 184 | 6698796 | REEL |
| 185 | 6698797 | RETURN SPRING |
| 186 | 6698798 | BUTTON |
| 187 | 6698799 | CORD GUIDE |
| 188 | 6698800 | CASE INCLUD.181-188 FOR (SL) |
| 189 | 6696454 | NYLON HEAD ASS'Y |
| 190 | 6684714 | HEX. HOLE BUTTON BOLT M6X25 |
| 191 | 6699442 | COVER BRACKET |
| 192 | 6684833 | BUSHING |
| 193 | 6697625 | CAUTION MARK |
| 194 | 6684851 | LEVEL MARK |
| 195 | 6699461 | MAIN PIPE (A) |
| 196 | 6684832 | DRIVE SHAFT B 783L |
| 197 | 6696980 | GUARD |
| 198 | 6696951 | GUARD HOLDER |
| 199 | 6696950 | COVER GUARD |
| 200 | 6684751 | TAPPING SCREW 4X14 |
| 201 | 6684750 | KNIFE |
| 202 | 6600328 | CAUTION LABEL (HEDGE) |
| 504A | 6601420 | SHOULDER BELT SINGLE |
| STANDARD ACCESSORIES Pag.4 | ||
| 2 | 6695736 | FLYWHEAT EXTRACTOR |
| 3 | 6695737 | FLYWHEEL EXTRACTOR BOLT |
| 5 | 6695740 | PISTON PIN EXTRACTOR |
