Hitachi Spare Parts for Engine Brush Cutter CG22EAS
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Engine Brush Cutter CG22EAS.
In the following table, look for the model of the chainsaw and ripettivo spare part.
| ENGINE BRUSH CUTTER CG22EAS | ||
| # | Part Num. | Description |
| 2A | 6600338 | MUFFLER PROTECTOR |
| 2A | 6600337 | MUFFLER PROTECTOR FROM PRODUCTION NOVEMBER YEAR 2013 |
| 3 | 6684638 | HEX. HOLE BOLT M6X55 |
| 4 | 949432 | BOLT WASHER M6 |
| 5 | 6696570 | MUFFLER |
| 5 | 6696554 | MUFFLER |
| 6 | 6696553 | HEAT PROTECTION PANEL |
| 6A | 6600320 | HEAT PROTECTION PANEL |
| 7 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 8 | 887021 | SCREW (W/WASHERS) M5X16 (BLACK) |
| 9 | 6684600 | WASHER T1.6 |
| 10 | 6684595 | HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 |
| 11 | 6696536 | INTAKE COVER (B) |
| 12 | 6696534 | COVER PACKING |
| 13 | 6696527 | CYLINDER |
| 14A | 6699155 | CYLINDER COVER |
| 15 | 307606 | MACHINE SCREW (W/WASHERS) M4X20 (BLACK) |
| 17A | 6699322 | SPARK PLUG ASS'Y CJ6 |
| 17A | 6699316 | SPARK PLUG ASS'Y BMR7A |
| 18 | 6696535 | INTAKE COVER (A) |
| 19 | 6696548 | INTAKE PACKING |
| 20 | 6696943 | CARBURETOR INSULATOR |
| 21A | 6698844 | SEAL LOCK HEX. SOCKET BOLT (W/WASHERS)M5 |
| 22 | 6684616 | CARBURETOR PACKING |
| 23 | 6684628 | SWIVEL CAP |
| 24 | 6696550 | CARBURETOR ASS'Y WYC-22 |
| 25 | 6699287 | CABLE ADJUST STAY |
| 26 | 6696830 | SWIVEL |
| 27 | 6684696 | STOP RING |
| 28 | 6684692 | PUMP GASKET |
| 29 | 6684693 | PUMP DIAPHRAGM |
| 30 | 6691242 | PUMP PLATE |
| 31 | 6685222 | DIAPHRAGM COVER-METERING |
| 32 | 6691312 | SET SCREW |
| 33 | 6696829 | SET SCREW M3X12 |
| 34 | 6684695 | O-RING |
| 36 | 6691234 | CIRCUIT PLATE |
| 37 | 6696828 | PUMP BODY COMP. |
| 38 | 6685220 | DIAPHRAGM PACKING-METERING |
| 39 | 6684690 | METERING DIAPHRAGM |
| 40 | 307224 | MACHINE SCREW (W/WASHERS) M5X60 (BLACK) |
| 41A | 6698720 | FUEL PIPE |
| 42 | 6696832 | AIR CLEANER HOUSING |
| 43 | 6685139 | PRIMING PUMP COMP. |
| 44 | 6690347 | CLEANER ELEMENT |
| 45 | 6696831 | AIR CLEANER COVER |
| 46 | 6696549 | AIR CLEANER ASS'Y |
| 48 | 6696530 | CYLINDER PACKING |
| 49 | 6696532 | PISTON RING |
| 50 | 6696531 | PISTON |
| 51 | 6684590 | CIR CLIP |
| 52 | 6696944 | PISTON PIN |
| 53 | 6696538 | CRANK CASE (B) COMP |
| 54 | 6696539 | CRANK CASE PACKING |
| 55 | 6684607 | OIL SEAL TB 12227 |
| 56 | 6684608 | BALL BEARING 6001 C3 |
| 57 | 6696946 | SHIM T0.2 |
| 58 | 6696945 | SHIM T0.3 |
| 59 | 6696533 | CRANK SHAFT COMP. |
| 60 | 6696537 | CRANK CASE (A) ASS'Y |
| 61 | 6695521 | KNOCK PIN 4X12 |
| 62A | 6699995 | RECOIL STARTER BODY ASS'Y |
| 63 | 6684679 | SET SCREW |
| 64A | 6699996 | CAM PLATE |
| 65 | 6684677 | DAMPER SPRING |
| 66A | 6699997 | STARTER ROPE REEL |
| 67 | 6684675 | RECOIL SPRING |
| 68 | 6684673 | RECOIL STARTER BODY COMP. |
| 69 | 6684674 | STARTER ROPE 3.5X860 |
| 70 | 6684680 | STARTER HANDLE |
| 72 | 993539 | MACHINE SCREW (W/WASHERS) M4X16 |
| 77 | 6684681 | STARTER PULLEY ASS'Y |
| 82 | 6600339 | MUFFLER REAR COVER |
| 83 | 6600325 | TAPPING SCREW D4X10 |
| 84 | 6600340 | MUFFER HEAT COVER |
| 85 | 6600327 | MARK PLATE (T) |
| 86 | 6699000 | PRIMER LABEL |
| 87 | 6699691 | CAMPLATE ASS'Y |
| 91 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 92 | 305583 | HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X20 |
| 93B | 6699159 | FAN CASE (VERMILION) |
| 94A | 6699199 | CLUTCH SHAFT |
| 95 | 6696469 | STEP BOLT |
| 96 | 6684648 | BENT WASHER 8 |
| 97 | 6696546 | CLUTCH PLATE (A) |
| 98 | 6696948 | CLUTCH |
| 99 | 6696547 | CLUTCH WASHER (B) |
| 100 | 6685337 | FLYWHEEL NUT |
| 101 | 323212 | BOLT WASHER M8 (BLACK) |
| 102B | 6699464 | IGNITION COIL ASS'Y |
| 103 | 6684599 | HEX.HOLE BOLT M4X18/WS |
| 106 | 6696544 | CORD |
| 107 | 6696545 | EARTH CORD |
| 108 | 6696928 | MAGNETO ROTOR COMP. |
| 108A | 6699289 | MAGNETO ROTOR ASS'Y |
| 109 | 6696963 | ANTI VIBE RUBBER (A) |
| 110 | 6696542 | PIPE HOLDER (A) |
| 112 | 6696543 | PIPE HOLDER (B) |
| 113 | 6696964 | ANTI VIBE RUBBER (B) |
| 114 | 939542 | RETAINING RING FOR D12 SHAFT |
| 115 | 6684636 | TAPPING SCREW D4.5X16 |
| 117 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 118 | 6696942 | HANDLE (B) |
| 118 | 6696487 | HANDLE (B) |
| 119 | 6696490 | LOCK LEVER |
| 120 | 6696488 | LEVER |
| 121 | 6696489 | SPRING (A) |
| 122 | 6696940 | STOP SWITCH |
| 126 | 6696941 | HANDLE (A) |
| 126 | 6696486 | HANDLE (A) |
| 127 | 6696569 | TANK |
| 128 | 6684620 | PUMP FILTER BODY COMP. |
| 129 | 6696949 | CLIP |
| 131 | 6696574 | BOLT (W/FLANGE) L17.8 |
| 132A | 6698716 | FUEL PIPE |
| 133 | 6696476 | FUEL PIPE (PINK) |
| 134A | 6697846 | RETURN GROMMET |
| 135A | 6698732 | TANK CAP CHAIN |
| 136A | 6698402 | FUEL TANK CAP ASS'Y |
| 145 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 146 | 6699463 | MAGNETO KEY SET |
| 151 | 323837 | TAPPING SCREW (W/FLANGE) D4X30 |
| 152 | 6696591 | HANDLE (B) |
| 152 | 6696590 | HANDLE (B) |
| 153 | 323041 | MACHINE SCREW M5X30 (BLACK) |
| 154 | 6696585 | HANDLE RIGHT |
| 155 | 6696577 | HANDLE HOLDER (B) |
| 156 | 6696578 | HANDLE HOLDER (C) |
| 157 | 6684714 | HEX. HOLE BUTTON SCREW 6X25S |
| 158 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 159 | 6696576 | HANDLE HOLDER (A) |
| 160 | 6696589 | HANDLE (A) |
| 160 | 6696588 | HANDLE (A) |
| 161 | 302012 | NUT M5 (BLACK) |
| 162 | 6696595 | HANDLE LEFT |
| 164 | 6696973 | BARRIER |
| 165 | 6696974 | BOLT (BLACK) M6 |
| 166 | 949556 | NUT M6 |
| 167 | 6696975 | LOOP HANDLE |
| 168A | 6699402 | GEAR CASE ASS'Y 3BB(A) |
| 169 | 6684737 | BOLT (W/PLUS) M6X8 |
| 176 | 6696977 | CUTTER HOLDER (A) |
| 180 | 6695414 | SCREW 5X12/W.S |
| 181 | 949664 | HEX. SOCKET HD. BOLT M5X30 |
| 186 | 6696494 | COVER BRACKET |
| 187 | 6684714 | HEX. HOLE BUTTON SCREW 6X25S |
| 194 | 6684851 | LEVEL MARK |
| 195 | 6696558 | MAIN PIPE COMP. |
| 196A | 6698514 | DRIVE SHAFT |
| 198 | 6698794 | COVER |
| 200 | 6698795 | SET SCREW |
| 201 | 6698796 | REEL |
| 202 | 6698797 | RETURN SPRING |
| 203 | 6698798 | BUTTON |
| 204 | 6698799 | CORD GUIDE |
| 205 | 6698800 | CASE |
| 206 | 6696454 | NYLON HEAD ASS'Y |
| 207 | 6696950 | COVER GUARD |
| 208 | 6684751 | TAPPING SCREW 4X14 |
| 209 | 6684750 | KNIFE |
| 210 | 6696951 | GUARD HOLDER |
| 211 | 6696980 | COVER |
| 212 | 949554 | NUT M4 |
| 213 | 6696584 | KNIFE |
| 215 | 323210 | BOLT WASHER M4 (BLACK) |
| 216 | 6685068 | MACHINE SCREW (W/SP. WASHER) M4X12 |
| 217 | 6685308 | FUEL GROMMET (A) |
| 225 | 6699187 | PLUG CAP |
| 226 | 6699186 | PLUG CAP METAL |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
