Dolmar Spare Parts for Brusch Cutter MS335.4U - 33,5 cm³ 4T
€79.05
Tax included
Dolmar Spare Parts for Brusch Cutter MS335.4U - 33,5 cm³ 4T
Dolmar genuine spare parts or Replacement parts for to repair Brush Cutter Dolmar MS335.4U - 33,5 cm³ 4T.Fix Your Brush Cutter Dolmar MS335.4U. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Brusch Cutter MS335.4U - 33,5 cm³ 4T
Fix Your Brush Cutter Dolmar MS335.4U - 33,5 cm³ 4T. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Brush Cutter and the respective parts of the code.
>
| Brushcutter Dolmar MS335.4U - 33,5 cm³ 4T - Pag. 1 | ||
| # | Part Num. | Description |
| 1 | 961057-5 | RETAINERRING S17 |
| 2 | 922331-6 | HEXAGONAL BOLT TAGL. 6X20 |
| 3 | 318421-5 | CLUTCH CASE EBH341U |
| 4 | 451157-4 | SPACER EBH341U |
| 5 | 210126-2 | BEARING 6003LLU |
| 6 | 962153-2 | R35 RING |
| 7 | 165577-3 | CLUTCH DRUM FOR EBH341U |
| 8 | 195144-0 | SUPPORT EBH341U |
| 9 | 911218-7 | CYLINDRICAL HEAD SCREW M5X14 |
| 10 | 961151-3 | REYAINER RING S-32 EBH341U |
| 11 | 424204-4 | DAMPER EBH341U |
| 12 | 318453-2 | HOUSEING COVER EBH341U |
| 13 | 922231-0 | BOLT M5X20 |
| 14 | 318454-0 | ENGINE SUPPORT EBH341U |
| 15 | 922331-6 | HEXAGONAL BOLT TAGL. 6X20 |
| 16 | 922201-9 | HEXAGONAL HEAD SCREW M5X8 |
| 17 | 443146-3 | FELT RING 8 EBH341U |
| 18 | 922341-3 | SCREW M6X25 |
| 19 | 318422-3 | BASE SUPPORT SHAFT EBH341U |
| 20 | 318423-1 | SHAFT SUPPORT EBH341 |
| 21 | 233202-5 | COMPRESSION SPRING 20 |
| 22 | 318424-9 | HANDLEBAR SUPPORT EBH341UP |
| 23 | 318425-7 | HANDLEBAR SUPPORT EBH341 |
| 24 | 168524-3 | KNOB SX EBH252U |
| 25 | 922256-4 | SCREW M5 X 35 X AN901 |
| 26 | 266326-2 | SCREW 4X18 X MT601 |
| 27 | 188660-9 | HANDLE GRIP EBH341U |
| 29 | 331863-6 | HANDLEBAR 22 EBH341U |
| 31 | 922256-4 | SCREW M5 X 35 X AN901 |
| 32 | 451525-1 | EBH341U SUPPORT |
| 33 | 325675-7 | DRIVE SHAFT EBH341U |
| 34 | 810513-1 | LABEL MS335.4U |
| 35 | 819760-1 | ABEL EBH341U L |
| 36 | 140042-3 | ROD EBH341U |
| 41 | 125558-9 | HOOK EBH341U |
| 45 | 922233-6 | HEX SOCKET HD BOLT M5X20 X DCS230T |
| 47 | 452259-9 | PROTECTION EBH341U |
| 48 | 266326-2 | SCREW 4X18 X MT601 |
| 49 | 347050-7 | BLADE |
| 50 | 135753-3 | LOWER PROTECTION |
| 51 | 346072-4 | BASE SUPPORT PROTECTION EBH341U |
| 52 | 451090-0 | PROTECTION SUPPORT EBH341U |
| 53 | 922353-6 | SCREW M6 X30 X HM1202C |
| 54 | 922218-2 | SCREW M5X14 EBH341U |
| 55 | 123835-3 | GEAR BOX ASSEMBLY |
| 56 | 213459-4 | GASKET 32 X HR3850B |
| 57 | 188865-1 | GEARS CASE EBH341U |
| 58 | 210059-1 | BEARING 6000 HR2010 |
| 59 | 211062-5 | BEARING 6000 X9524NB |
| 60 | 961006-2 | RETAINER RING S10 |
| 61 | 962105-3 | RING R26 |
| 62 | 922353-6 | SCREW M6 X30 X HM1202C |
| 63 | 265590-2 | SCREW M8X10 EBH341U |
| 64 | 210081-8 | BEARING 629ZZ EBH341U |
| 68 | 210116-5 | BEARING 6201LLU EBH341U |
| 69 | 962151-6 | R32 RING |
| 70 | 332114-0 | INTERNAL FLANGE X EM4350RH |
| 71 | 346355-2 | EXTERNAL FLANGE |
| 72 | 168526-9 | CUP EBH341U |
| 73 | 264025-0 | NUT M10-17 EBH341U |
| Brushcutter Dolmar MS335.4U - 33,5 cm³ 4T - Pag. 2 | ||
| 74 | 125545-8 | CONTROLS LEVER EBH341U |
| 75 | 183A09-4 | EVER CASE EBH341U |
| 76 | 233540-5 | TORSION SPRING 11 EBH341U |
| 77 | 451084-5 | THROTTLE LEVER EBH341U |
| 78 | 233541-3 | SPRING TUBE 7 EBH341U |
| 79 | 451083-7 | UNLOCKING LEVER EBH341U |
| 80 | 451213-0 | PIPE EBH341U |
| 81 | 168539-0 | CABLE CONTROL EBH341U |
| 82 | 451081-1 | CABLE SUPPORT EBH341U |
| 83 | 451082-9 | SWITCH LEVER EBH341U |
| 84 | 232251-9 | SPRING PLATE EBH341U |
| 85 | 455722-1 | SWITCH COVER EBH341UP03 |
| 86 | 638663-8 | CABLE EBH341U |
| 88 | 266326-2 | SCREW 4X18 X MT601 |
| 233 | 638671-9 | CABLE EBH341U |
| Brushcutter Dolmar MS335.4U - 33,5 cm³ 4T - Pag. 3 | ||
| 89 | 318614-4 | FLYWHEEL CARCASS EBH341U |
| 90 | 922223-9 | SCREW M5X16 EBH341U EX2650LH |
| 93 | 267424-5 | WASHER 8 EBH341U |
| 94 | 267832-0 | WASHER WASHER 10 EBH341U |
| 95 | 266571-9 | SCREW M8X23 EBH341U |
| 96 | 125757-3 | CLUTCH CPL X EM3400L |
| 97 | AN02010C00 | TENSION SPRING 9 |
| 98 | 265577-4 | SCREW M6X16 EBH341U |
| 99 | 318611-0 | FLYWHEEL EBH341U |
| 100 | 168816-0 | IGNITION COIL EBH341U |
| 101 | 922138-0 | SCREW M4X20 |
| 102 | 324891-8 | SPARK PLUG SPRING COVER EBH341 |
| 103 | 424105-6 | SPARK PLUG COVER EBH252L |
| 104 | 638664-6 | CABLE EBH341U |
| 105 | 638665-4 | CABLE EBH341U |
| 106 | 424313-9 | RUBBER EBH341U |
| 107 | 345963-6 | HOOK EBH341U |
| 109 | 451876-2 | SPARK PLUG COVER EBH341U |
| 110 | 266572-7 | SCREW M5X8 EBH341U |
| 111 | 808633-3 | LABEL 4T EH252L |
| 112 | 911213-7 | SCREW M5X12 X 5143R EBH252L |
| 113 | 451884-3 | CYLINDER COVER MS335.4U |
| 114 | 266440-4 | SCREW M5X40 EBH341U |
| 115 | 265184-3 | SCREW M5X55 EBH341U |
| 116 | 345915-7 | MUFFLER COVER EBH341U |
| 117 | 168469-5 | MUFFLER EBH341U |
| 118 | 345916-5 | MUFFLER GASKET EBH341U |
| 119 | 324980-9 | GUARD EBH341U |
| 120 | 266495-9 | SCREW M5X14 |
| 121 | 140419-2 | VALVE COVER EBH341U |
| 122 | 162307-3 | BROWN COVER GASKET |
| 123 | 168534-0 | SPARK PLUG NGKCMR4A EBH341U |
| 124 | 162274-2 | CAM GEAR COVER GASKET ER2650LH EBH341 |
| 125 | 318443-5 | SIDE COVER EBH341U |
| 126 | 922212-4 | SCREW M5X12 |
| 127 | 450565-6 | OIL CAP EBH341U |
| 128 | 424100-6 | GASKET OIL CAP EBH341U |
| 129 | 282020-8 | CLAMP EBH341U |
| 130 | 424202-8 | OIL TUBE EBH341U |
| 131 | 325666-8 | FITTING EBH341U |
| 132 | 162308-1 | OIL CUP GASKET EBH341U |
| 133 | 318612-8 | OIL CUP EBH341U |
| 134 | 266495-9 | SCREW M5X14 |
| 135 | 266573-5 | SCREW M5X33 EBH341U |
| 136 | 266570-1 | SCREW M5X16 EBH341U |
| 137 | 266569-6 | SCREW M4X10 EBH341U |
| 138 | 318440-1 | CHECK PLATE EBH341U |
| 139 | 346083-9 | PLATE EBH341U |
| 140 | 424201-0 | CONTROL VALVE EBH341U |
| 141 | 135373-3 | CYLINDER EBH341U |
| 142 | 125554-7 | BALANCER EBH341U |
| 143 | 325912-9 | EBH341U SPRING COVER |
| 144 | 234181-0 | COMPRESSION SPRING 13 EBH341U |
| 145 | 256200-2 | PIN 5 FOR 2704 |
| 146 | 256866-8 | PIN 2.5 EBH341U |
| 147 | 424200-2 | SPACER EBH341U |
| 148 | 268239-3 | PIN 4 EBH341U |
| 149 | 313169-4 | BALANCER CAM EBH341U |
| 150 | 325913-7 | DISCHARGE VALVE EBH341U |
| 151 | 325914-5 | SUCTION VALVE EBH341U |
| 152 | 125552-1 | CAM GEAR EBH341U |
| 153 | 268238-5 | PIN 5 EBH341U |
| 154 | 195141-6 | PISTON RING SET EBH341U |
| 155 | 318613-6 | PISTON EBH341U |
| 156 | 257796-6 | PISTON PIN EBH341U |
| 157 | 233983-1 | PISTON PIN CIRCLIP EBH341 |
| 158 | 254040-2 | KEY 3 EBH341U |
| 159 | 213537-0 | OIL SEAL 12 EBH341U |
| 160 | 267425-3 | WASHER 26 EBH341U |
| 161 | 125756-5 | CRANK SHAFT EBH341U |
| 162 | 213769-9 | OIL SEAL 10 |
| 163 | 125472-9 | TANK CAP CPL. |
| 164 | 140435-4 | TANK CAP EBH341U |
| 165 | 140436-2 | ROD EBH341U |
| 166 | 810455-9 | COLLAR PLATE EBH341U |
| 167 | 424104-8 | DAMPER EBH341U |
| 168 | 451877-0 | FUEL TANK EBH341U |
| 169 | 163447-0 | FUEL FILTER X DCS230T |
| 170 | 345920-4 | CLAMP EBH341U |
| 171 | 424103-0 | DAMPER EBH341U |
| 172 | 424102-2 | DAMPER EBH341U |
| 173 | 162309-9 | FUEL TUBE EBH341U |
| 174 | 195142-4 | RECOIL STARTER CPL EBH341U |
| 175 | 165606-2 | STARTER PULLEY EBH341U |
| 176 | 266580-8 | SCREW M5X10 EBH341U |
| 177 | 451923-9 | STARTER REEL EBH341U |
| 178 | 232257-7 | SPIRAL SPRING EBH341U |
| 179 | 424317-1 | STARTER KNOB EBH341U |
| 180 | 444018-5 | STARTER ROPE EBH341U |
| 181 | 911218-7 | CYLINDRICAL HEAD SCREW M5X14 |
| 182 | 816453-1 | LABEL MS334.4U |
| 183 | 162310-4 | EBH341U TANK PROTECTION |
| 184 | 911218-7 | CYLINDRICAL HEAD SCREW M5X14 |
| Brushcutter Dolmar MS335.4U - 33,5 cm³ 4T - Pag. 4 | ||
| 185 | 325915-3 | SUCTION TUBE EBH341U |
| 186 | 413120-5 | INSULATING GASKET EBH341U |
| 187 | 213063-9 | GASKET 10 X HR2000 |
| 188 | 451874-6 | INSULATOR EBH341U |
| 190 | 346261-1 | CARBURETTOR INSULATOR EBH341 |
| 191 | 922228-9 | SCREW M5X18 EBH341U |
| 192 | 413138-6 | CARBURETOR GASKET EBH341 |
| 193 | 450562-2 | CLAMP EBH341U |
| 194 | 922213-2 | SCREW M5X12 EBH341U |
| 195 | 168561-7 | CARBURATOR EBH341U |
| 196 | 325922-6 | CARBURETOR SCREW EBH341U |
| 197 | 413140-9 | WASHER EBH341U |
| 198 | 257964-1 | RETAINER RING E3 EBH341U |
| 199 | 266581-6 | SCREW M3X8 EBH341U |
| 200 | 213538-8 | RING 2 EBH341U |
| 201 | 325921-8 | JET EBH341H |
| 202 | 234183-6 | SPRING 65-9 EBH341U |
| 203 | 442155-9 | PUMP GASKET EBH341U |
| 204 | 168575-6 | EBH341U PUMP DIAPHRAGM |
| 205 | 266582-4 | SCREW 3X24 EBH341U |
| 206 | 346270-0 | EBH341U PUMP COVER |
| 207 | 424314-7 | EBH341 PRIMING PUMP |
| 208 | 140438-8 | BODY EBH341U |
| 209 | 168574-8 | DIAPHRAGM CPL EBH341U |
| 210 | 442154-1 | DIAPHRAGM GASKET EBH341U |
| 211 | 140437-0 | PUMP BODY EBH341U |
| 212 | 352010-6 | FILTER EBH252L |
| 213 | 345918-1 | FASCETTA EBH341U |
| 214 | 422055-9 | BREATHER TUBE EBH341U |
| 215 | 422042-8 | TUBE EBH341U |
| 216 | 125468-0 | FILTER PLATE EBH341U |
| 217 | 451925-5 | CHOKE LEVER EBH341U |
| 218 | 213540-1 | RING 15 EBH341U |
| 219 | 424316-3 | CHECK VALVE EBH341U |
| 220 | 213539-6 | RING 14 EBH341U |
| 221 | 451924-7 | RETURN VALVE PLATE |
| 222 | 424315-5 | CONTROL VALVE EBH341U |
| 223 | 168577-2 | SEPARATOR GASKET EBH341U |
| 224 | 168576-4 | SEPARATOR EBH341U |
| 225 | 450560-6 | AIR LEVER PLATE EBH341U |
| 226 | 423376-2 | GASKET EBH341U |
| 227 | 345919-9 | FIXING PLATE EBH341U |
| 228 | 265188-5 | SCREW M5X68 EBH341U |
| 229 | 443140-5 | PRE-FILTER EBH341U |
| 230 | 443141-3 | FILTER EBH341U |
| 231 | 450561-4 | AIR FILTER COVER EBH341U |
| 232 | 911218-7 | CYLINDER HEAD SCREW M5x14 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
