DeWalt Spare Parts for Pressure Washer DXPW007E

DeWalt genuine spare parts for to repair Pressure Washer DXPW007E - 25159.

In the following table, look for the model of the Pressure Washer and the respective parts of the code.
DeWalt

Casing DXPW007E - 25159 Pag.1
1 3960810 CASING
2 2100300 SCREW
3 2360760 KNOB
4 3960790 SUPPORT
5 3960800 CASING
6 180030 SCREW
7 3960260 KNOB
8 2060200 SCREW
9 2360580 BOLT
10 1270960 DETERGENT HOSE
11 1341030 FILTER
12 1269114 PRE ASSEMBLY HOSE SA
13 380240 NUT
14 1340260 FILTER
15 3960300 GUARD
16 3960280 HANDLE
17 3960150 GUARD
18 3960160 GUARD
19 3960490 CARRIER
20 3960290 GUARD
21 3969004 KNOB
22 3960830 GUARD
23 3960400 GUARD
24 3600180 WASHER
25 3600140 WHEEL
26 3960270 FRAME
27 1060120 NUT
28 3960350 GUARD
29 3960340 GUARD
30 3960360 DAMPER
31 3960330 GUARD
Pump DXPW007E - 25159 Pag.2
1 960090 PLUG
2 960160 O RING
3 1389051 VALVE
4 800860 SCREW
5 1381850 WASHER
6 3220020 HEAD SA
7 180101 O RING
8 820361 PLUG
9 740290 O RING
10 1980740 PLUG
11 1381580 PRESSURE GAUGE
12 200390 RING
13 1780140 RING
14 1780720 SEAL
15 3200250 RING
16 3220130 PISTON GUIDE
17 3200142 GASKET
18 3200260 RING
19 770260 O RING
20 3220120 PISTON GUIDE
21 1260110 NUT
22 1260100 WASHER
23 1780080 PISTON
24 1260091 PLATE
25 1260460 SEAL
26 3220010 BODY PUMP SA
27 880130 PLUG
28 480480 O RING
29 3220060 PISTON
30 3220070 PIN
31 3220040 CON ROD
32 651540 O RING
33 3220030 COVER
34 3200220 SCREW
35 820510 O RING
36 880581 PLUG
37 3220280 RING
38 3200070 SUPPORT
39 880830 O RING
40 1981210 BEARING
41 3229603 PRE ASSEMBLY LEVEL OIL
42 650560 O RING
43 200390 RING
44 1981210 BEARING
45 1080550 RING
46 42714 PRE ASSEMBLY HEAD SA
47 23507 PUMP SA
48 3220310 CRANKSHAFT
49 3200230 KEY
A 2864 VALVE KIT
B 2746 PISTON KIT
C 42547 SEALS KIT
E 42549 SEALS KIT
F 42550 GASKET SET
G 2745 RING
Pump DXPW007E - 25159 Pag.3
1 24791 VALVE CPL
2 2840970 SCREW
3 1060120 NUT
4 2029800 PRE ASSEMBLY BOX TSS
5 2500540 INSERT
6 2500550 PIN
7 1980220 PLATE
8 2760410 SPRING
9 2760400 PISTON
10 2260100 O RING
11 660190 O RING
12 2760210 RING
13 2760570 GUIDE
14 1200690 O RING
15 394280 O RING
16 2260070 SHUTTER
17 2760980 SEAT
18 770140 O RING
19 2760640 RING
20 390080 O RING
21 1540272 SCREW
22 2320180 CONNECTOR
23 480480 O RING
24 1250280 BALL
25 1560520 SPRING
26 2260190 O RING
27 3740010 VALVE BODY
28 1120681 O RING
29 1540630 O RING
30 3740020 BODY
31 880270 O RING
32 2260420 SCREW
33 2101770 O RING
34 2760131 SHUTTER
35 2760200 SPRING
36 2760120 INSERT
37 1470210 O RING
38 2760270 O RING
39 2760230 COUPLING
40 2260480 RING
41 2260470 PIN
42 2260460 SPRING
43 2021650 WASHER
44 1260821 O RING
45 3740050 RING
46 600180 O RING
47 3740040 CONNECTOR
48 2022201 FORK
49 480440 O RING
50 1122260 COUPLING
51 480560 O RING
52 1344620 CONNECTOR
53 3600760 COUPLING
54 3961000 EXTENSION
F 42780 GASKET SET
Motor DXPW007E - 25159 Pag.4
1 3960740 BOX
2 2560720 SCREW
3 2360950 CONTACT
4 2021480 GLAND
5 2900420 SWITCH
6 2000210 SCREW
7 3960650 O RING
8 1269100 CLAMP
9 1700640 CABLE
10 3961090 GASKET
11 3960730 PLATE
12 3960980 SCREW
13 1700100 GASKET
14 44716 MOTOR
15 3960640 GLAND
16 3960990 GUIDE
17 2360590 BOARD
Accessories DXPW007E - 25159 Pag.5
1 41843 HANDLE SA
2 40826 EXTENSION
3 2000570 O RING
4 3961050 HOSE
5 391000 O RING
6 3086 NOZZLE
