Flex original spare parts for to replace broken parts for to fix Vacuum Cleaner VC 21 L MC.
In the following table, look for the model of the Vacuum Cleaner and the respective parts of the code.
| Vacuum Cleaner VC 21 L MC | ||
| # | Part Num. | Description |
| 1 | 410683 | Cover VC 21 |
| 2 | 410691 | Screw 5x18 VCE |
| 3 | 410705 | Cable Hook for cable VC 21 |
| 4 | 410713 | Switch 1-0-Wkzg. VC 21 |
| 5 | 385786 | Socket 230 / CEE VC21 + VCE26 |
| 6 | 410721 | Screw 3.5x18, VC21 + VCE26 |
| 7 | 385808 | Plate |
| 8 | 410748 | Button VC 21 |
| 9 | 410756 | Housing VC 21 |
| 10 | 410764 | Lever VC 21 |
| 11 | 410772 | Capacitor VC21 + VCE26 |
| 12 | 410780 | Terminal VC21 + VCE26 |
| 13 | 410799 | Power Cable 230 / CEE VC 21 |
| 14 | 410802 | Electronic Board 230 / EEC VC 21 |
| 15 | 410810 | Clamp VC21 + 26 |
| 16 | 410829 | Engine cover VC 21 + 26 |
| 17 | 410837 | Motor 230V VC21 + VCE26 |
| 18 | 410845 | Upper motor seal VC21 + VCE26 |
| 19 | 410853 | Lower motor seal VC21 + VCE26 |
| 20 | 385891 | Spring |
| 21 | 410861 | Board VC21 + VCE26 |
| 22 | 410888 | Base plate VC21 + VCE26 |
| 24 | 410918 | Filter seal VC21 + VCE26 |
| 25 | 410926 | Deflector VC21 + VCE26 |
| 26 | 385085 | Filter |
| 27 | 410934 | Filter support VC21 + VCE26 |
| 28 | 410942 | Tank cpl VC 21 |
| 29 | 410950 | Wheel, Ø130, VC21 + VCE26 |
| 30 | 386022 | Adhesive label> Class L powder < |
| 32 | 410985 | Kit wheels VC21 + VCE26 |
| 33 | 385646 | Circular brush |
| 34 | 410993 | Support VC21 + VCE26 |
| 35 | 385549 | Cushion nozzle |
| 37 | 385530 | Nozzle for joints |
| 38 | 385565 | Combined floor nozzle |
| 39 | 385506 | Suction attachment |
| 40 | 385484 | Suction pipe with manifold |
| 41 | 385093 | Filter bags |
| 42 | 385107 | Garbage Bag |
| 43 | 411132 | Box VC 21 |
