Alpina Spare Parts for Brushcutter B33
We are Dealers of ALPINA original spare parts at low at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Brushcutter B33 - 280220000-12-2015.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| Brushcutter B33/280220000-12-2015 Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118801251/0 | Screw |
| 2 | 118801250/0 | Hub |
| 4 | 118801249/0 | Starter Pulley |
| 5 | 118801252/0 | Starter Cord |
| 6 | 118801253/0 | Spring |
| 9 | 118801263/0 | Starter Handle |
| 10 | 118801264/0 | Retainer |
| 11 | 118801262/0 | Starter Ass.Y Black |
| 12 | 2135030 | Screw |
| 13 | 118801254/0 | Starter Cup Ass.Y |
| 17 | 119035159/0 | Seal Ring |
| 18 | 123685026/0 | Crank Case |
| 19 | 123280047/0 | Crankcase Gasket |
| 20 | 114215218/0 | Ball Bearing |
| 21 | 123020025/0 | Crankshaft |
| 22 | 123072002/0 | Flywheel Key |
| 24 | 123685027/0 | Crank Case |
| 25 | 2135060 | Screw |
| 26 | 123880018/0 | Flywheel REPLACED BY 123880009/0 BUY WITH COIL |
| 29 | 112154200/0 | Nut |
| 30 | 123044018/0 | Electronic Coil REPLACED BY 123044011/0 BUY WIYH FLYWHEEL |
| 32 | 2135030 | Screw |
| 34 | 123430583/0 | Clutch Ass.Y |
| 35 | 123430583/0 | Clutch Unit |
| 37 | 123878058/0 | Screw |
| 53 | 123235007/0 | Needle Bearing |
| 54 | 123202009/0 | Circlip |
| 55 | 123760007/0 | Piston Pin |
| 56 | 123590008/0 | Piston |
| 57 | 123204010/0 | Piston Ring |
| 58 | 123280045/0 | Cylinder Gasket |
| 59 | 123071024/0 | Cylinder |
| 60 | 112760475/0 | Screw |
| 63 | 118801258/0 | Spark Plug Cover |
| 64 | 123275023/0 | Grommet |
| 65 | 118801459/0 | Cylinder Cover White |
| 67 | 118801462/0 | White Cover |
| 68 | 112788910/0 | Screw |
| 69 | 123280041/0 | Intake Manifold Gasket |
| 70 | 123073509/0 | Intake Manifold |
| 71 | 2135030 | Screw |
| 72 | 118801227/0 | Carburetor Gasket |
| 73 | 123054025/1 | Carburetor |
| 74 | 118801229/0 | Lever |
| 75 | 118801228/0 | Air Filter Support + Cover |
| 76 | 123190000/0 | Shutter |
| 78 | 2132160 | Screw |
| 79 | 123220011/0 | Air Filter |
| 80 | 118801257/0 | Filter Cover White |
| 81 | 118801267/0 | Muffler Gasket |
| 83 | 183740022/0 | Muffler |
| 85 | 118801256/0 | White Cover |
| 88 | 2122210 | Screw |
| 89 | 123280060/0 | Rubber Gasket |
| 90 | 112788910/0 | Screw |
| 91 | 118801265/0 | Fuel Tank |
| 92 | 118801266/0 | Lower Guard |
| 93 | 2135030 | Screw |
| 94 | 2135200 | Screw |
| 95 | 118801319/0 | Fuel Pipe |
| 96 | 118801318/0 | Grommet |
| 97 | 118801313/0 | Fuel Line |
| 98 | 183520005/0 | Intake Filter |
| 99 | 118801243/0 | Fuel Tank-Cap Ass.Y |
| Brushcutter B33/280220000-12-2015 Trasmission Pag.2 | ||
| 1 | 123050012/0 | Clutch Drum Assy |
| 2 | 2122080 | Screw |
| 3 | 118801261/0 | Guard |
| 4 | 112610800/0 | Seeger |
| 5 | 119216048/0 | Bearing |
| 6 | 112609200/0 | Seeger |
| 7 | 118801259/0 | Clutch Case |
| 8 | 112760475/0 | Screw |
| 9 | 118801260/0 | Button |
| 10 | 118801316/0 | Reduction |
| 11 | 118801311/0 | Reduction |
| 12 | 118801310/0 | Support |
| 13 | 118801309/0 | Support |
| 14 | 2135020 | Screw |
| 15 | 2135030 | Screw |
| 21 | 183869073/0 | Assy Transm. Tube+Flex |
| 22 | 123020038/0 | Drive Shaft |
| 31 | 118801337/0 | Clamp |
| 32 | 112789000/0 | Screw |
| 33 | 118801335/0 | Safety Lever, Red |
| 34 | 118801336/0 | Throttle Lever, Red |
| 35 | 118801334/0 | Spring |
| 36 | 118801332/0 | Right Handgrip,White |
| 37 | 112735105/0 | Screw |
| 38 | 118801354/0 | Throttle Cable |
| 40 | 118801333/0 | Spring |
| 41 | 118801329/0 | Stop Knob,Red |
| 43 | 118801330/0 | Stop Plate |
| 44 | 118801338/0 | Spring |
| 45 | 118801328/0 | Stop Wire |
| 46 | 118801331/0 | Left Handgrip,White |
| 50 | 118801322/0 | Earth Cable |
| 51 | 183780002/0 | Harness Support |
| 52 | 123170004/0 | Spacer |
| 55 | 118801339/0 | Front Handle Assy, White |
| 71 | 118801327/0 | Harness |
| Brushcutter B33/280220000-12-2015 Gear - Accessories Pag.3 | ||
| 1 | 183820507/0 | Gear Case Assy |
| 6 | 112727801/0 | Screw |
| 7 | 112789000/0 | Screw |
| 8 | 112727794/0 | Screw |
| 10 | 123670002/0 | Guard |
| 15 | 123250002/0 | Upper Ring Nut |
| 16 | 123250003/0 | Lower Ring Nut |
| 18 | 123120015/0 | Nut |
| 21 | 123784012/0 | Support |
| 22 | 2135050 | Screw |
| 23 | 2135180 | Screw |
| 24 | 118801341/0 | Safety Cover, Black |
| 25 | 112735654/0 | Screw |
| 26 | 118801342/0 | Guard, Black |
| 27 | 112728099/1 | Screw |
| 28 | 123311013/0 | Line Cutter Blade |
| 31 | 118801124/0 | 2 Hedges Nylon Head M10x1,25 Female |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
