Genuine Parts FIAC for piston Air Compressors and spare parts for the repair or replacement of components for Pump unit, VS 204 data validità - da 02/03/2011.
In the following table , look for the model of the pumping unit and the respective parts of the code.
| VS 204 data validità - da 02/03/2011 | ||
| # | Part Num. | Description |
| 2 | 7570090000 | Head |
| 3 | 7458340000 | Filter plate |
| 4 | 7210010000 | Filter element |
| 5 | 7210430000 | Filter cover |
| 6 | 7012010000 | Screw Ø3,9X19 UNI-6954 |
| 7 | 7090200000 | Cap 3/8 FIL.CILINDR.IN BRASS |
| 8 | 7081100000 | 3/8 " |
| 9 | 7231770000 | PIPE HEAD VS 204 / 254S COPPER D.10 SX |
| 10 | 7010120000 | Screw M6X25 UNI-5931 |
| 11 | 7089950000 | Collector |
| 12 | 7231760000 | PIPE HEAD VS 204 / 254S COPPER D.10 DX |
| 14 | 7459510000 | Kit valve plate |
| 15 | 7150370000 | Plastic Hood |
| 18 | 7575030000 | Cylinder |
| 19 | 7020070000 | Nut M8 UNI-5587 |
| 20 | 7015020000 | Prisoner M.8X35X14X16 |
| 21 | 5070160008 | Sump |
| 22 | 5041360008 | Crank |
| 23 | 7038070000 | Washer Ø20,1X26X2 UNI-6593 |
| 24 | 7011090000 | Screw M8x20 UNI-5739 |
| 26 | 7031010000 | Washer Ø8 UNI-3703 |
| 27 | 7060140000 | Bearing 6204-2RS2 / HT-22-C3 SKF |
| 30 | 7041010000 | Seeger Ø12 |
| 31 | 7050050000 | Pin Ø12 / 8,5X46 GMS |
| 32 | 7220300000 | Piston |
| 36 | 7151030000 | COVER CARTER GMVS |
| 37 | 7012020000 | Screw Ø3,9X12,7 DIN-7981 |
| 38 | 7210120000 | FILTER HOUSING COVER |
| 41 | 4280770000 | Rotor Kit |
| 42 | 4010810000 | HOUSING MOT GMVS 200 V220 / 50HZ S / MORS. |
| 43 | 7382340000 | Terminal cover |
| 44 | 7012020000 | Screw Ø3,9X12,7 DIN-7981 |
| 45 | 7310330000 | Condenser MF.30 V450 |
| 46 | 7329900000 | Cable Pressure / Motor |
| 47 | 7501060000 | Cable locks |
| 48 | 7501050000 | Cable locks |
| 49 | 7410460000 | Prot. Thermal ETA-3120-F521-P7T1-W09D-6A |
| 50 | 7410470000 | Prot. Thermal singl. 10A |
| 51 | 7060090000 | 6204-2RS1-bearing SKF |
| 52 | 7640010000 | Cover |
| 53 | 7015100000 | Guy M6X185 |
| 54 | 7200340000 | Fan |
| 55 | 7038020000 | Washer Ø8X30X3 UNI-6593 |
| 56 | 7196020000 | Start valve M1/ 4 "1.5 bar |
| 100 | 4020890000 | Kit head |
| 101 | 4191140000 | GR.Rod PIST.VS-BAND ONE-DSB |
| 103 | 4082090000 | Set of Gasket |
| 104 | 4190320000 | Rod kit |
| 105 | 4080043000 | Kit Rings |
| 041A | 4280810000 | Rotor Kit |
| 042A | 4010850000 | HOUSING MOT.GMVS 200 V240 / 50HZ S / MORS. |
| 042B | 4010980000 | HOUSING MOT.GMVS 200 V380 / 50HZ S / MORS. |
| 043A | 7382350000 | COVER Morset MEC90 GMV-E TRIFAS |
| 046A | 7329870000 | PR WIRE / MOTGMV25-30 3X1,5 + T PVC90CM |
