FIAC Spare Parts for Piston Air Compressor Airsplash 24
€180.53
Tax included
FIAC Spare Parts for Piston Air Compressor Airsplash 24
Genuine Parts FIAC for piston Air Compressors and spare parts for the repair or replacement of components of the type Airsplash 24.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Spare Parts for Piston Air Compressor Airsplash 24
Genuine Parts FIAC for piston Air Compressors and spare parts for the repair or replacement of components of the type Airsplash 24.
In the following table, look for the type of the air compressor and the respective parts of the code .
| Compressor Airsplash 24 | ||
| # | Part NUm. | Description |
| 1 | 7012240000 | Screw M5X15 UNI-8112 |
| 2 | 7151450000 | CASING AIR SPLASH BLACK |
| 3 | 7570620000 | Head |
| 4 | 7011880000 | Lives |
| 5 | 7078670000 | Gasket |
| 6 | 7199160000 | Valve |
| 7 | 7459360000 | Valve Plate |
| 8 | 7070420000 | O-Ring 476 |
| 9 | 5062040008 | Cylinder - DISCONTINUED |
| 10 | 7670110000 | Sump |
| 11 | 7018500000 | PIVOT ROD 203 F. |
| 12 | 4082910000 | KIT ROD GM-203 X AIRSLASH - DISCONTINUED |
| 13 | 7060570000 | Bearing 6301-2RS |
| 14 | 7181180000 | OIL CAP AIRSPLASH OR GREEN + |
| 15 | 7585030000 | Crank BRASS GM 203-AIRSPLASH |
| 16 | 7151460000 | COVER CARTER AIRSPLASH |
| 17 | 7020200000 | Nut M6 UNI-5587 |
| 18 | 7060010000 | Bearing 6203 ZZ 17:40:12 QE6 |
| 19 | 7584000000 | GROUP TREE + ROTOR F-203-H 60- |
| 20 | 4012910000 | Stator |
| 21 | 7310590000 | Condenser MF.25 V450 |
| 22 | 7640130000 | Cover |
| 23 | 7012240000 | Screw M5X15 UNI-8112 |
| 24 | 7013060000 | Screw M4X8 UNI-8112 |
| 25 | 7459390000 | SUPPORT CARENAT.AIRCLIK-ZINC |
| 26 | 7199170000 | Valve |
| 27 | 7012240000 | Screw M5X15 UNI-8112 |
| 28 | 7201280000 | Fan Raff. |
| 29 | 7011400000 | Screw M6X100 UNI-5737 |
| 30 | 7459400000 | Support |
| 31 | 7078700000 | Gasket |
| 32 | 7060230000 | Bearing 6203 RS 2 - SKF |
| 33 | 7012240000 | Screw M5X15 UNI-8112 |
| 50 | 5152830008 | Tank 24lt |
| 51 | 7091240000 | Plastic Stopper |
| 52 | 7360020000 | Rubber Ø16 |
| 53 | 7130160000 | Bleeding Tap M3 / 8 " |
| 54 | 7260380000 | Wheel Ø125X35 F10 |
| 55 | 7012780000 | Screw M10x60 UNI-5737 |
| 56 | 7327540000 | Alimentation Cable |
| 57 | 7020080000 | Nut M10 UNI-5588 |
| 58 | 7090030000 | Cap 1/2 |
| 59 | 7190240000 | Check Valve M3 / 8 "-Pipe Ø8 |
| 60 | 7230010000 | Rilsan Tube Ø6X4 |
| 61 | 7230670000 | Tube Feeding |
| 62 | 7192020000 | Valve Sic. M1 / 4-8,5Bar |
| 63 | 7250740000 | Pressure Switch |
| 64 | 7023040000 | Nut 1/4 " |
| 65 | 7081140000 | Fitting 1/4 "MM |
| 66 | 7110300000 | Ø50-1 Gauge / 4 " |
| 67 | 7100640000 | Pressure Reducer |
| 68 | 7130010000 | Tap M1 / 4 " |
| 69 | 7081090000 | Fitting 1/4 "MM |
| 70 | 7110240000 | Manometer Ø40-1 / 8 " |
| 71 | 7210810000 | Suction Filter |
| 100 | 4230150000 | GR.TESTA-PLATE F-203 / GM-203 |
