FIAC Silenced Compressor SCS 598-300 Spare Parts
€525.72
Tax included
FIAC Silenced Compressor SCS 598-300 Spare Parts
Fiac Genuine spare parts or replacement parts for to fix Silenced Compressor SCS 598-300 - SCS598 - AB598S - 1121690366.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Silenced Compressor SCS 598-300 Spare Parts
Fiac Genuine spare parts or replacement parts for to fix Silenced Compressor SCS 598-300 - SCS598 - AB598S 400V - 1121690366.
In the following table, look for the type of the Compressor and the respective parts of the code.
| SCS 598-300 - SCS598 - AB598S 400V - 1121690366 WURTH W-PS270/5,5 Pag.1 |
||
| Pos. | Part Num. | Description |
| 1 | 5167290008 | UPPER PANEL |
| 2 | 7014420000 | SCREW |
| 3 | 5198940008 | REAR PANEL |
| 4 | 1120005332 | SIDE PANEL |
| 5 | 1125160063 | FRONT PANEL |
| 6 | 5160950008 | CONVEYOR |
| 7 | 1120005182 | SIDE PANEL |
| 8 | 1125160735 | INTERNAL PANEL |
| 9 | 5167360008 | BASE PLATE |
| 10 | 1123020106 | PUMP UNIT |
| 11 | 5167370008 | BASE PLATE |
| 12 | 7011120000 | SCREW |
| 13 | 1127010136 | SCREW |
| 14 | 7364420000 | VIBRATION-DAMPING |
| 15 | 7020070000 | NUT |
| 16 | 7371020000 | BELT SPZX 1562 |
| 17 | 7405290000 | PULLEY |
| 18 | 7380850000 | THREE PHASE MOTOR |
| 19 | 7011170000 | SCREW |
| 20 | 7030040000 | WASHER |
| 21 | 7020080000 | NUT |
| 22 | 7111030000 | PRESSURE GAUGE |
| 23 | 7080890000 | FITTING |
| 24 | 7566190000 | HOUR COUNTER |
| 25 | 7085700000 | FITTING |
| 26 | 7326650000 | CABLE |
| 27 | 7328690000 | CABLE |
| 28 | 7328700000 | POWER CABLE |
| 29 | 7251211000 | PRESSURE SWITCH |
| 30 | 7230010000 | RILSAN TUBE |
| 31 | 7084220000 | FITTING |
| 32. | X | PLUG |
| 33. | X | PLUG |
| 34 | 7511530000 | BRACKET |
| 35 | 7155631000 | DASHBOARD |
| 36. | X | CABLE GLAND |
| 37 | 7500440010 | LOCK NUT |
| 38 | 7012240000 | SCREW |
| 39 | 7014450000 | SCREW |
| 40 | 7010500000 | SCREW |
| 41 | SCREW | |
| 42 | 5167430008 | FOOT |
| 43 | 7360400000 | RUBBER FOOT |
| 44 | 5156280008 | TANK - DISCONTINUED |
| 45 | 7190150000 | CHECK VALVE |
| 46 | 7192010000 | RELIEF VALVE |
| 47 | 7080780000 | FITTING |
| 48 | 7080160000 | FITTING |
| 49 | 7234530000 | INFEED HOSE |
| 50 | 7085080000 | FITTING |
| 51 | 7080810000 | FITTING |
| 52 | 7081311150 | FITTING |
| 53 | 7231010000 | INFEED HOSE |
| 54 | 7236720000 | RUBBER HOSE |
| 55 | 5160031148 | SUPPORT |
| Pos. | Codice | Description Pag.2 |
| 1 | 5071020008 | CRANKCASE |
| 2 | 7650080000 | COVER |
| 3 | 0502210600 | BEARING |
| 4 | 5041490008 | CRANKSHAFT - DISCONTINUED |
| 5 | 7060060000 | BEARING |
| 6 | 7650070000 | COVER |
| 7 | 7090090000 | PLUG |
| 8 | 9700000408 | OIL SIGHT GLASS |
| 9 | 7051520000 | FEATHER |
| 10 | 7575460000 | CYLINDER |
| 11 | 4231230000 | VALVE PLATE |
| 11.1 | X | PLATE |
| 11.2 | X | VALVE HP |
| 11.3 | X | BP |
| 11.4 | X | GASKET |
| 12 | 5030610008 | HEAD |
| 13 | 4086830000 | BREATHER PIPE PLUG KIT |
| 14 | 7232330000 | COOLER |
| 15 | 5130110008 | AFTERCOOLER |
| 16 | 7458910000 | BRACKET |
| 17 | 7192350000 | RELIEF VALVE |
| 18 | 7081190000 | FITTING |
| 19 | 7201050000 | FLYWHEEL |
| 20 | 7650090000 | LOWER COVER |
| 21 | 4082280000 | GASKETS KIT |
| 21.1 | X | GASKET |
| 21.2 | X | GASKET |
| 21.3 | X | GASKET |
| 21.4 | X | GASKET |
| 21.5 | X | OIL SEAL |
| 21.6 | X | GASKET |
| 21.7 | X | GASKET |
| 22 | 4080920000 | SCREWS KIT |
| 22.1 | X | SCREW |
| 22.2 | X | SCREW |
| 22.3 | X | SCREW |
| 22.4 | X | WASHER |
| 22.5 | X | SCREW |
| 22.6 | X | WASHER |
| 22.7 | X | SCREW |
| 22.8 | X | SCREW |
| 22.9 | X | SCREW |
| 23 | 4080290000 | INTAKE FILTER KIT |
| 23.1 | X | FILTER COVER |
| 23.2 | X | BASE PLATE |
| 23.3 | 7210690000 | FILTER ELEMENT |
| 23.4 | X | SCREW |
| 24 | 4080850000 | CON ROD-PISTON KIT LP |
| 24.1 | 4080840000 | PISTON RING KIT |
| 24.2 | X | PISTON |
| 24.3 | X | GUDGEON PIN |
| 24.4 | X | INTERNAL SNAPRING |
| 24.5 | X | CONNECTING ROD |
| 25 | 4080860000 | CON ROD-PISTON KIT HP |
| 25.1 | 4080080000 | PISTON RING KIT |
| 25.2 | X | PISTON |
| 25.3 | X | CONNECTING ROD |
| 25.4 | X | GUDGEON PIN |
| 25.5 | X | INTERNAL SNAPRING |
| 26 | 7083550000 | FITTING |
| Pos. | Codice | Description Pag.3 |
| 100 | 7471780000 | TANK |
| 101 | 7192010000 | RELIEF VALVE |
| 102 | 7130150000 | BALL COCK |
| 103 | 7082820000 | FITTING |
| 104 | 7230080000 | RILSAN TUBE |
| 105 | 7080970000 | FITTING |
| 106 | 7130170000 | BALL COCK |
| 107 | 7082050000 | FITTING |
| 108 | 7090090000 | PLUG |
| 109 | 7090030000 | PLUG |
| 110 | 7239220000 | INFEED HOSE |
| 111 | 7080160000 | FITTING |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
