FIAC Spare Parts for Pumping Unit AB 851-901-951-981
€30.62
Tax included
FIAC Spare Parts for Pump Unit AB 851-901-951-981
Distribution and Sale at attractive prices of FIAC Air Compressors Original Spare Parts, low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Piston Air Compressors Pump Unit AB 851 - AB 901 - AB 951 - AB 981 per SA/SSA.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Spare Parts for Pump Unit AB 851-901-951-891
Distribution and Sale at attractive prices of FIAC Air Compressors Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Piston Air Compressors Pump Unit AB 851 - AB 901 - AB 951 - AB 981 per SA/SSA.
In the following table, look for the type of the Pumping Unit and the respective parts of the code.
| AB 851 - AB 901 - AB 951 - AB 981 for SA/SSA | ||
| # | Part Num. | Description |
| 1 | 7079610000 | Gasket |
| 2 | 7199130000 | Flap Valve HP |
| 3 | 7199140000 | Flap Valve LP |
| 4 | 7458910000 | Clamp |
| 5 | 7011460000 | Screw |
| 6 | 7650130000 | Cover |
| 7 | 7079600000 | Gasket |
| 8 | 7012090000 | Screw |
| 9 | 7040140000 | Ring |
| 10 | 7079590000 | Gasket |
| 10A | 7079710000 | Gasket (AB951) |
| 11 | 4080090000 | Low pres. piston ring (AB851) |
| 11A | 4080220000 | Low pres. piston ring D.110 mm |
| 12 | 7220140000 | Low pres. Piston D. 105 mm (AB851) |
| 12A | 7220250000 | Low pres. piston D.110 mm |
| 13 | 7040140000 | Clip |
| 14 | 7050150000 | Piston pin (AB851) 18x94 |
| 14A | 7050200000 | Piston pin 18x99 (AB851) |
| 15 | 4080080000 | High pres. piston ring |
| 15A | 4080030000 | High pres. piston ring |
| 16 | 7220120000 | High pres. Piston (AB851) |
| 16A | 7220240000 | HP Piston 55 mm + Kit Piston Rings |
| 17 | 7011040000 | Screw |
| 18 | 7050130000 | Piston pin (AB851) |
| 18A | 7050190000 | Piston pin |
| 19 | 7085110000 | Joint |
| 19A | 7080160000 | Joint (per SA) |
| 20 | 7062170000 | Bearing (AB851) |
| 20A | 7060530000 | Bushing |
| 21 | 4190370008 | Con rod Assy (AB851) |
| 21A | 4190390008 | Con rod Kit |
| 22 | 5060720008 | Cylinder (AB851) |
| 22A | 5060760008 | Cylinder |
| 23 | 7011160000 | Screw |
| 24 | 7079410000 | Gasket |
| 25 | 5070310008 | Carter |
| 26 | 7153050000 | Air Baffle |
| 27 | 7091120000 | Plug |
| 28 | 7011090000 | Screw |
| 29 | 5082090008 | Support |
| 30 | 7070290000 | Gasket |
| 31 | 7060160000 | Bearing |
| 32 | 7180060000 | Oil level sight glass |
| 33 | 7130440000 | Oil discarge Tap |
| 34 | 7022040000 | Selflocking nut |
| 35 | 5041150008 | Crankshaft AB850 Worked |
| 35A | 5041340008 | Crankshaft (AB951 x SA HP) |
| 36 | 7051520000 | Key |
| 37 | 7060150000 | Bearing |
| 38 | 7071130000 | Mim ring |
| 39 | 5082050008 | Support |
| 40 | 7201240000 | Flywheel |
| 41 | 7030270000 | Washer |
| 42 | 7031010000 | Toothed washer |
| 43 | 7011110000 | Screw |
| 44 | 7230750000 | Cooler ----> 1124080806 ex 1127230025 ex 7230750000 |
| 45 | 7024150000 | Nut |
| 46 | 7031030000 | Washer |
| 47 | 7210270000 | Filter Holder Assy ----> 425010000 |
| 48 | 7210280000 | Filtering element |
| 49 | 7210260000 | Filter |
| 50 | 7210290000 | Sleeve |
| 51 | 7015160000 | Tension rod |
| 52 | 5130070008 | Manifold |
| 53 | 7010050000 | Screw |
| 54 | 7458460000 | Stop plate |
| 55 | 7070260000 | OR ring |
| 56 | 5030590008 | Head |
| 57 | 7010060000 | Screw |
| 58 | 7085210000 | Joint |
| 59 | 7230020000 | Rilsan hose |
| 60 | 7192350000 | Safety valve |
| 61 | 7079250000 | Gasket |
| 62 | 5130090008 | Refrigerator |
| 63 | 7010220000 | Screw |
| 64 | 7458420000 | Stop plate |
| 65 | 7070140000 | O-Ring 4200 |
| 66 | 5131030008 | Reduction |
| 68 | 7080970000 | Joint |
| 69 | 7090090000 | Plug |
| 70 | 7078730000 | Gasket |
| 71 | 7018270000 | Pin |
| 72 | 7078720000 | Gasket |
| 73 | 7018280000 | Pin |
| 74 | 5131210008 | Tank |
| 75 | 7062750000 | Spacer |
| 76 | 7079490000 | Gasket |
| 77 | 7432200000 | Switch |
| 78 | 7025040000 | Nut |
| 79 | 7010350000 | Screw |
| 80 | 7087920000 | Joint |
| 81 | 7023040000 | Blocker nut |
| 100 | 7459540000 | Valve plate group |
| 101 | 4291110000 | Low pres. Piston Set |
| 102 | 4291150000 | High pres. piston Set |
| 103 | 4250100000 | Filter group |
| 104 | 4251150000 | Refrigerator group |
| 105 | 4082480000 | Gaskets Kit |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
AB 851 901 951 981 SA/SSA
