Spare Parts for Pump Unit FIAC GM 300
€477.05
Tax included
Spare Parts for Pump Unit FIAC GM 300
We are Dealers of FIAC original spare parts for piston Air Compressors, at low at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for direct driven lubricared pump unit GM 300 validity date - from 10/03/2008.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Spare Parts for Pump Unit FIAC GM 300
We are Dealers of FIAC original spare parts for piston Air Compressors, at low at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for direct driven lubricared pump unit GM 300 validity date - from 10/03/2008.
In the following table , look for the model of the pumping unit and the respective parts of the code .
| GM 300 validity date - from 10/03/2008 | ||
| # | Part NUm. | Description |
| 1 | 5165000008 | AIR CONVEYOR, RED-GM 300 |
| 2 | 7012740000 | Screw M6 X 20 |
| 3 | 7012010000 | Screw Ø3,9X19 UNI-6954 |
| 4 | 7210430000 | filter cover |
| 5 | 7210010000 | filter element |
| 6 | 7458340000 | filter plate |
| 7 | 7011290000 | Screw M6X35 UNI-5739 |
| 8 | 7084190000 | Fitting "L" 3 / 8-1 / 2 MM |
| 9 | 7570090000 | Head |
| 11 | 7458370000 | plate portavalvole |
| 13 | 4081040000 | FLAP VALVE KIT DELIVERY TR 255 |
| 15 | 5060160008 | Cylinder |
| 17 | 4080240000 | Piston Ring Kit |
| 18 | 7050030000 | Pin Ø 13 |
| 19 | 7041030000 | Seeger Ø13 |
| 20 | 5050160008 | Conrod |
| 21 | 7030320000 | Washer Ø6,3 UNI-6594 |
| 22 | 7015020000 | Stud M.8X35X14X16 |
| 23 | 7181160000 | CAP D.20 C / VENT + AUCTION |
| 24 | 7060060000 | bearing 6205 |
| 25 | 5041190008 | crankshaft |
| 26 | 7040040000 | And Seeger 20 |
| 27 | 7650020000 | crankcase cover |
| 28 | 7011430000 | Screw M6X16 UNI-8112 |
| 29 | 7012100000 | screw Ø3,9X16 |
| 30 | 7078460000 | gasket |
| 31 | 7071020000 | Oil seal 2452/10 |
| 32 | 5070320000 | sump |
| 33 | 5090370008 | Rotor |
| 34 | 7170660000 | BASE TR-255 |
| 35 | 4012930000 | stator |
| 36 | 7060010000 | Bearing 6203 ZZ 17:40:12 QE6 |
| 37 | 5110061008 | cover |
| 38 | 7015130000 | guy M6X167 |
| 39 | 7038020000 | Washer Ø8X30X3 UNI-6593 |
| 40 | 7011090000 | Screw M8x20 UNI-5739 |
| 41 | 7012290000 | Screw M5X20 TAP-TITE |
| 42 | 7200060000 | Fan |
| 43 | 7013060000 | Screw M4X8 UNI-8112 |
| 44 | 7015390000 | Stud |
| 45 | 7310360000 | Capacitor 60 uF 400V Repla. by 7310550000 |
| 46 | 7220050000 | Piston |
| 47 | 7020070000 | Nut M8 UNI-5587 |
| 48 | 7150361000 | Motor Cover Plastic |
| 49 | 7196220000 | Start valve M3 / 8 "2.2 bar |
| 100 | 4082810000 | Valve plate kit |
| 101 | 4191040000 | CONROD-PISTON-RINGS KIT D.55 / VX 304 |
| 102 | 4280680000 | CRANKCASE + CRANKSHAFT + ROTOR GM 300 |
| 103 | 4082940000 | GASKET KIT GM 300 |
| 013A | 4081030000 | FLAP VALVE KIT 10PZ SP.0,20 STEEL |
