FIAC ABT 500-1716 Spare Parts
€2,408.11
Tax included
FIAC ABT 500-1716 Spare Parts
Fiac Genuine spare parts or replacement parts fo to repair Piston Air Compressor ABT ABT 500-1716 - 1121570900.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC ABT 500-1716 Spare Parts
Fiac Genuine spare parts or replacement parts fo to repair Piston Air Compressor ABT ABT 500-1716 - 1121570900.
In the following table, look for the type of the Air Compressor and the respective parts of the code.
| FIAC ABT 500-1716 - 1121570900 Spare Parts Pag.1 |
||
| # | Part Num. | Description |
| 1 | 1124300050 | TANK KIT RAL 3000S |
| 2 | 7090050000 | PLUG |
| 3 | 7130160000 | DISCHARGE TAP |
| 4 | 7085390000 | FITTING |
| 5 | 7130460000 | BALL COCK |
| 6 | 7231110000 | INFEED HOSE |
| 7 | 7085070000 | FITTING |
| 8 | 7232070000 | PIPE |
| 9 | 7190150000 | CHECK VALVE |
| 10 | 7080070000 | FITTING |
| 11 | 7191010000 | SINGLE-ACTING VALVE |
| 12 | 7080560000 | FITTING |
| 13 | 7230010000 | RILSAN TUBE |
| 14 | 7250740000 | PRESSURE SWITCH |
| 15 | 7110250000 | PRESSURE GAUGE |
| 16 | 7090070000 | PLUG |
| 17 | 7082040000 | FITTING |
| 18 | 7192090000 | RELIEF VALVE |
| 19 | 7085010000 | FITTING |
| 20 | 7430640000 | ELECTRIC CABINET |
| 21 | 4150520000 | MOTOR/PULLEY KIT |
| 22 | 7370140000 | BELT |
| 23 | 1123020111 | PUMP UNIT |
| 24 | 7458990000 | BELT GUARD SUPPORT |
| 25 | 5010450008 | BASE PLATE |
| 26 | 5010460008 | BASE PLATE |
| 27 | 4170210000 | BELT GUARD KIT |
| 28 | 4170200000 | BELT GUARD KIT |
| 29 | 7458900000 | SUPPORT |
| 30 | 7194200000 | SOLENOID VALVE |
| 31 | 7080200000 | FITTING |
| 32 | 7082060000 | FITTING |
| 33 | 4080530000 | SCREWS KIT |
| AB858 Pump Unit Spare Parts Pag.2 |
||
| # | Part Num. | Description |
| 1 | 4080870000 | LP CON ROD-PISTON KIT |
| 1.1 | 4080090000 | LP PISTON RING KIT |
| 1.2 | 7220140000 | LP PISTON |
| 1.3 | 7050150000 | GUDGEON PIN |
| 1.4. | SEEGER RING | |
| 1.5 | 4190370008 | CONNECTING ROD |
| 1.6. | NUT | |
| 1.7 | 7062170000 | BEARING |
| 2 | 4080880000 | CON ROD-PISTON KIT |
| 2.1 | 4080080000 | PISTON RING KIT |
| 2.2 | 7220120000 | PISTON HP |
| 2.3 | 4190370005 | CONNECTING ROD |
| 2.4 | 7050130000 | GUDGEON PIN |
| 2.5. | SEEGER RING | |
| 2.6. | NUT | |
| 2.7 | 7062170000 | BEARING |
| 3 | 4080910000 | SCREWS KIT |
| 3.1. | SCREW | |
| 3.2. | SCREW | |
| 3.3. | SCREW | |
| 3.4. | SCREW | |
| 3.5. | SCREW | |
| 3.6. | SCREW | |
| 3.7. | SCREW | |
| 3.8. | WASHER | |
| 3.9. | WASHER | |
| 4 | 4081900000 | GASKETS KIT |
| 4.1. | O RING | |
| 4.2. | OIL SEAL | |
| 4.3. | GASKET | |
| 4.4. | GASKET | |
| 4.5. | GASKET | |
| 4.6. | GASKET | |
| 5 | 4231240000 | VALVE PLATE KIT |
| 5.1. | VALVE PLATE | |
| 5.2. | GASKET | |
| 5.3. | VALVE | |
| 5.4. | VALVE | |
| 6 | 5030620008 | HEAD |
| 7 | 5041150008 | CRANKSHAFT |
| 8 | 5060720008 | CYLINDER |
| 9 | 5070270008 | CRANKCASE |
| 10 | 5082050008 | SUPPORT |
| 11 | 5082090008 | SUPPORT |
| 12 | 5130010008 | COOLER |
| 13 | 7051520000 | FEATHER |
| 14 | 0502210600 | BEARING |
| 15 | 7060160000 | BEARING |
| 16 | 7070110000 | GASKET |
| 17 | 7090090000 | PLUG |
| 18 | 9700001377 | PLUG |
| 19 | 7153050000 | CONVEYOR |
| 20 | 9700000408 | OIL LIGHT |
| 21 | 7192350000 | RELIEF VALVE |
| 22 | 7201240000 | FLYWHEEL |
| 23 | 7230040000 | PIPE |
| 24 | 7232700000 | COOLER |
| 25 | 7458910000 | BRACKET |
| 26 | 9700002979 | FILTER |
| 26.1. | BASE PLATE | |
| 26.2 | 9103760330 | FILTER ELEMENT |
| 26.3. | FILTER COVER | |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
