FIAC Parts for Petrol Engine Air Compressor AGRI 515-24
€378.31
Tax included
FIAC Parts for Petrol Engine Air Compressor AGRI 515-24
Genuine Parts FIAC for Engine Air Compressor FIAC AGRI 515-24 - 1121440665 01/04/2016 for use where there is no available electric power supply. Designed with wide-track gauge to facilitate their transport, they have large all-terrain tyres to make it easier to move them.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Parts for Petrol Engine Air Compressor AGRI 515-24
Genuine Parts FIAC for Engine Air Compressor FIAC AGRI 515-24 - 1121440665 01/04/2016 for use where there is no available electric power supply. Designed with wide-track gauge to facilitate their transport, they have large all-terrain tyres to make it easier to move them.
In the following table, look for the type of the air compressor and the respective parts of the code .
| Engine Air Compressor FIAC AGRI 515-24 - 1121440665 01/04/2016 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 3020041000 | PUMP UNIT AB515-415 |
| 2 | X | BASE PLATE |
| 3 | 1125150267 | TANK |
| 4 | SCREW | |
| 5 | SCREW | |
| 6 | SCREW | |
| 7 | SCREW | |
| 8 | SCREW | |
| 9 | SCREW | |
| 10 | SCREW | |
| 11 | SCREW | |
| 12 | SCREW | |
| 13 | SCREW | |
| 14 | NUT | |
| 15 | NUT | |
| 16 | NUT | |
| 17 | NUT | |
| 18 | WASHER | |
| 19 | WASHER | |
| 20 | WASHER | |
| 21 | GUDGEON PIN | |
| 22 | 7062680000 | BUSHING |
| 23 | 7080010000 | FITTING |
| 24 | 7080160000 | FITTING |
| 25 | 7080770000 | ELBOW |
| 26 | 1127080210 | FITTING |
| 27 | 7082140000 | FITTING |
| 28 | 7084250000 | ELBOW |
| 29 | 7084270000 | FITTING |
| 30 | 7085020000 | FITTING |
| 31 | 7085190000 | FITTING |
| 32 | 7101640000 | KNOB |
| 33 | 7110240000 | PRESSURE GAUGE |
| 34 | 7110430000 | PRESSURE GAUGE |
| 35 | 7130160000 | DISCHARGE TAP |
| 36 | 7130570000 | TAP |
| 37 | 1127150257 | SPACER |
| 38 | 7192010000 | RELIEF VALVE |
| 39 | 7195170000 | AUTOMATIC UNLOADING VALVE |
| 40 | 7230010000 | RILSAN TUBE |
| 41 | 7230030000 | RILSAN TUBE |
| 42 | 7237291000 | INFEED HOSE |
| 43 | 4170030000 | BELT GUARD KIT |
| 44 | 7280030000 | KNOB |
| 45 | 7360250000 | RUBBER FOOT |
| 46 | 7364180000 | VIBRATION-DAMPING |
| 47 | 7371890000 | BELT |
| 48 | 1125010164 | I.C. ENGINE |
| 49 | 7398640000 | HANDLE |
| 50 | 7407130000 | PULLEY |
| 51 | 1127450820 | BELT GUARD SUPPORT |
| 52 | 7459670000 | BELT GUARD SUPPORT |
| 53 | 1127450994 | SUPPORT |
| 54 | 9102360000 | PNEUMATIC THROTTLE |
| 55 | X | WHEEL |
| 56 | 7100770000 | KIT |
| 57 | 5165800008 | SUPPORT |
| 100 | 1120001835 | SCREWS KIT |
| 101 | 4083780000 | RUBBER FOOT KIT |
| 102 | 1124080377 | KIT |
| Gruppo Pompante AB515-415 Pag.2 |
||
| # | Part Num. | Description |
| 1 | 9105450240 | CONNECTING ROD AB415 |
| 2 | X | SCREW |
| 3 | X | SCREW |
| 4 | X | SCREW |
| 5 | X | SCREW |
| 6 | X | SCREW |
| 7 | X | SCREW |
| 8 | X | SCREW |
| 9 | X | SCREW |
| 10 | X | SCREW |
| 11 | 4080070000 | PISTON RING KIT |
| 12 | X | WASHER |
| 13 | X | WASHER |
| 14 | 7041410000 | INTERNAL SNAP RING |
| 15 | 7050110000 | GUDGEON PIN |
| 16 | 7051510000 | KEY ROUND 5x7,5 |
| 17 | 7060060000 | BEARING |
| 18 | 7060150000 | BEARING |
| 19 | O RING | |
| 20 | O RING | |
| 21 | O RING | |
| 22 | OIL SEAL | |
| 23 | GASKET | |
| 24 | GASKET | |
| 25 | GASKET | |
| 26 | 7090090000 | PLUG |
| 27 | 9700000408 | OIL SIGHT GLASS |
| 29 | 7201030000 | FLYWHEEL |
| 30 | 7210680000 | FILTER ELEMENT |
| 31 | 7220090000 | PISTON 65MM |
| 31A | 9700002940 | PISTON KIT 65MM |
| 32 | 9100270270 | COOLER |
| 33 | O RING | |
| 34 | 9105450010 | CRANKCASE |
| 35 | 9105450250 | CRANKSHAFT |
| 36 | 9105450060 | CYLINDER |
| 37 | 9105450070 | FRONT COVER |
| 38 | 9105450080 | REAR COVER |
| 39 | 9105450090 | CASING COVER |
| 42 | GASKET | |
| 44 | 9105450180 | HEAD |
| 45 | 7153140000 | CONVEYOR |
| 46 | 9700001377 | OIL FILLER NECK KOMPLETT |
| 100 | 4231260000 | VALVE PLATE KIT |
| 101 | 4291070000 | CON ROD-PISTON KIT |
| 102 | 4250130000 | INTAKE FILTER KIT |
| 103 | 4081990000 | GASKETS KIT |
| 104 | 4080480000 | SCREWS KIT |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
