DeWalt Spare Parts for Pressure Washer DXPW002CE
DeWalt original replacement parts for to replace broken parts for to fix Pressure Washer DXPW002CE - 26773.
In the following table, look for the model of the Pressure Washer and the respective parts of the code.
| Cofano DXPW 002CE -26773 | ||
| Pag.1 | ||
| # | Part Num | Description |
| 1 | 3961200 | Handle |
| 2 | 2100300 | Screw |
| 3 | 880280 | Screw |
| 4 | 3961210 | Protection |
| 5 | 3800250 | Screw |
| 6 | 3961260 | Knob |
| 7 | 3961290 | Protection |
| 8 | 3961160 | Hood |
| 9 | 3960830 | Protection |
| 10 | 3961230 | Protection |
| 11 | 4240590 | Screw |
| 12 | 1260780 | Screw |
| 13 | 3961220 | Protection |
| 14 | 3961240 | Support |
| 15 | 3961180 | Support |
| 16 | 3961250 | Clamp |
| 17 | 3961170 | Base |
| 18 | 4240540 | Rubber |
| 19 | 3960260 | Black Knob |
| 20 | 3961190 | Protection |
| 21 | 41851 | Pressure Gauge |
| 22 | 1270960 | Detergent Tube |
| 23 | 1341030 | Filter |
| 24 | 3082130 | Water Connection Kit |
| Pump Pag.2 | ||
| 1 | 26854 | Pump pre-assembly |
| 2 | 46065 | Head pre-assembly |
| 3 | 4140650 | Head |
| 4 | 740290 | OR-seal |
| 5 | 4140570 | Connection |
| 6 | 2849051 | Complete valve |
| 7 | 2841520 | OR-seal |
| 8 | 2840130 | Cap |
| 9 | 2900350 | Cap |
| 10 | 2101770 | OR-seal |
| 11 | 2761511 | Shutter |
| 12 | 2760200 | Spring |
| 13 | 2761550 | Injector |
| 14 | 1470210 | OR-seal |
| 15 | 2760270 | OR-seal |
| 16 | 394280 | OR-seal |
| 17 | 2761150 | Connection |
| 18 | 3700250 | OR-seal |
| 19 | 1560520 | Spring |
| 20 | 1250280 | Ball |
| 21 | 480480 | OR-seal |
| 22 | 1344620 | Connection |
| 23 | 480560 | OR-seal |
| 24 | 2320180 | Hose holder |
| 25 | 4140140 | Washer |
| 26 | 1345180 | Screw |
| 27 | 2760260 | Cap |
| 28 | 3700250 | OR-seal |
| 29 | 2841800 | Cap |
| 30 | 46935 | Regulation valve kit |
| 31 | 1470210 | OR-seal |
| 32 | 2841080 | Seat |
| 33 | 3800230 | Piston |
| 34 | 820510 | OR-seal |
| 35 | 740290 | OR-seal |
| 36 | 3800970 | Piston guide |
| 37 | 2500550 | Cotter pin |
| 38 | 2760210 | Ring |
| 39 | 660190 | OR-seal |
| 40 | 2260100 | OR-seal |
| 41 | 4140170 | Piston |
| 42 | 1980220 | Plate |
| 43 | 4140620 | Spring |
| 44 | 3800960 | Screw |
| 45 | 3800200 | Nut |
| 46 | 3961360 | Screw |
| 47 | 3720750 | OR-seal |
| 48 | 3721210 | Seat |
| 49 | 1682800 | OR-seal |
| 50 | 3720730 | Cap |
| 51 | 46936 | TSS Retrofit Kit |
| 52 | 1120681 | Gasket OR |
| 53 | 4140420 | Rod |
| 54 | 2260460 | Spring |
| 55 | 2021650 | Washer |
| 56 | 1260820 | OR Seal |
| 57 | 3740050 | Ring |
| 58 | 600180 | OR Seal |
| 59 | 4140640 | Cap |
| 60 | 2841910 | Water Seal |
| 61 | 2840550 | Bushing |
| 62 | 770590 | OR Seal |
| 63 | 2841390 | Bushing |
| 64 | 1683500 | Oil Seal |
| 65 | 4140010 | Pump Body |
| 66 | 4140210 | Cap |
| 67 | 3700250 | OR Seal |
| 68 | 2841800 | Cap |
| 69 | 4140060 | Piston |
| 70 | 4140080 | Connecting Rod |
| 71 | 4140070 | Pin |
| 72 | 4140090 | OR Seal |
| 73 | 4140030 | Cover |
| 74 | 4140270 | Screw |
| 75 | 4140110 | Bearing |
| 76 | 4140360 | Ring |
| 77 | 4140150 | Cover |
| 78 | 4140310 | Shaft |
| 79 | 1380520 | Key |
| 80 | 4140190 | Ring |
| 81 | 4140100 | Bearing |
| 82 | 4140360 | Ring |
| 83 | 4140200 | Oil Seal |
| 84 | 3201960 | Flange |
| 85 | 880280 | Screw |
| A | 43478 | Valve Kit |
| B | 43479 | Piston Kit |
| C | 43480 | Oil Seal Kit |
| E | 47536 | Water Seal Kit |
| F | 43482 | Gasket Kit |
| Motor Pag.3 | ||
| 1 | 45074 | Motor |
| 2 | 1260300 | Fan |
| 3 | 1340350 | Seal |
| 4 | 1345180 | Screw |
| 5 | 1345140 | Shield |
| 6 | 1340340 | Bearing |
| 7 | 1269100 | Clamp |
| 8 | 1340780 | Gasket |
| 9 | 2000210 | Screw |
| 10 | 2901920 | Switch |
| 11 | 3780170 | Box |
| 12 | 1261560 | Screw |
| 13 | 2021480 | Cable gland |
| 14 | 1982190 | Capacitor |
| 15 | 1982550 | Clamp |
| 16 | 1462900 | Cable gland |
| 17 | 2029803 | TSS box pre-assembly |
| 18 | 2022201 | Fork |
| 19 | 3780630 | Cable |
| Accessories Pag.4 | ||
| 1 | 41842 | Gun |
| 2 | 391000 | OR gasket |
| 3 | 43955 | Lance (Adjustable jet) |
| 4 | 2000570 | OR gasket |
| 5 | 3960920 | Hose |
