DeWalt Spare Parts for Pressure Washer DXPW005E

€22.01
Tax included

DeWalt Spare Parts for Pressure Washer DXPW005E

DeWalt genuine spare parts for to repair Pressure Washer DXPW005E - 25157.
ITEM CODE: 2186
Quantity
Usually Ships in: 10/15 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

DeWalt Spare Parts for Pressure Washer DXPW005E

DeWalt genuine spare parts for to repair Pressure Washer DXPW005E - 25157.

In the following table, look for the model of the Pressure Washer and the respective parts of the code.
DeWalt DXPW005E - 25157

Pressure Washer DXPW005E - 25157 Spare Parts List
Casing DXPW005E - 25157 Pag.1
# Part Num. Description
1 3960810 CASING
2 2100300 SCREW
3 2360760 KNOB
4 3960790 SUPPORT
5 3960800 CASING
6 180030 SCREW
7 3960260 KNOB
8 3961030 SPACER
9 2360340 COLUMN
10 1270960 HOSE DEGETERGENT
11 1341030 FILTER
12 1269114 PRE ASSEMBLY HOSE SA
13 380240 NUT
14 1340260 FILTER
15 3960300 GUARD
16 3960280 HANDLE
17 3960150 GUARD
18 3960160 GUARD
19 3960490 CARRIER
20 3960290 GUARD
21 3969004 KNOB
22 3960830 GUARD
23 3960400 GUARD
24 3600180 WASHER
25 3600140 WHEEL
26 3960270 FRAME
27 1060120 NUT
28 3960350 GUARD
29 3960340 GUARD
30 3960360 DAMPER
31 3960330 GUARD
32 2060200 SCREW
Pump DXPW005E - 25157 Pag.2
1 3200110 PLUG
2 1200690 O RING
3 2769050 VALVE
4 800410 SCREW
5 1381550 WASHER
6 3200020 HEAD
7 180101 O RING
8 820361 PLUG
9 740290 O RING
10 1980740 PLUG
11 1780140 RING
12 1780720 SEAL
13 3200130 GUIDE
14 3200142 GASKET
15 3200260 RING
16 770590 O RING
17 3200120 GUIDE
18 3200010 BODY
19 1780490 BEARING
20 1260790 RING
21 1780550 RING
22 395081 O RING
23 3209615 PRE ASSEMBLY LEVEL
24 3201860 RING
25 3200070 SUPPORT
26 1200430 SCREW
27 880130 PLUG
28 1260110 NUT
29 1260100 WASHER
30 1260210 PISTON
31 1260091 PLATE
32 1260460 SEAL
33 480480 O RING
34 3200060 PISTON
35 3200040 CON ROD
36 1780050 PIN
37 2760280 O RING
38 3200030 COVER
39 820510 O RING
40 880581 PLUG
41 3200220 SCREW
42 3200270 CRANKSHAFT
43 3200230 KEY
44 1321190 BEARING
45 1260750 RING
46 42948 PRE ASSEMBLY HEAD SA
47 23081 PRE ASSEMBLY PUMP SA
48 3200430 PLUG
49 3230 PRESSURE GAUGE
A 2186 VALVE KIT
B 42467 PISTON KIT
C 42468 SEALS KIT
E 42469 SEALS KIT
F 42470 GASKET SET
G 2745 KIT RING
Pomp DXPW005E - 25157 Pag.3
1 25712 VALVE CPL
2 2840970 SCREW
3 1060120 NUT
4 2029800 PRE ASSEMBLY TSS BOX
5 2500540 INSERT
6 2500550 PIN
7 1980220 PLATE
8 2760410 SPRING
9 2760400 PISTON
10 2260100 O RING
11 660190 O RING
12 2760210 RING
13 2760570 GUIDE
14 1200690 O RING
15 394280 O RING
16 2260070 SHUTTER
17 2760980 SEAT
18 770140 O RING
19 2760640 RING
20 390080 O RING
21 1540272 SCREW
22 2320180 CONNECTOR
23 480480 O RING
24 1250280 BALL
25 1560520 SPRING
26 2260190 O RING
27 3740010 VALVE BODY
28 1120681 O RING
29 1540630 O RING
30 3740020 BODY
31 880270 O RING
32 2260420 SCREW
33 2101770 O RING
34 2760131 SHUTTER
35 2760200 SPRING
36 2760240 INSERT
37 1470210 O RING
38 2760270 O RING
39 2760230 COUPLING
40 2260480 RING
41 2260470 PIN
42 2260460 SPRING
43 2021650 WASHER
44 1260821 O RING
45 3740050 RING
46 600180 O RING
47 3740040 CONNECTOR
48 2022201 FORK
49 1560600 CONNECTOR
50 480560 O RING
51 1344620 CONNECTOR
52 3961000 EXTENSION
53 480440 O RING
54 1122260 COUPLING
F 42780 GASKET SET
Motor DXPW005E - 25157 Pag.4
1 3960740 BOX
2 2560720 SCREW
3 2360950 CONTACT
4 2021480 GLAND
5 2900420 SCREW
6 2000210 O RING
7 3960650 CLAMP
8 1269100 CABLE
9 1700640 POWER CABLE
10 3961090 GASKET
11 3960730 PLATE
12 3960980 SCREW
13 1700100 GASKET
14 44715 MOTOR
15 3960640 GLAND
16 3960990 GUIDE
Accessories DXPW005E - 25157 Pag.5
1 41842 HANDLE SA
2 41930 EXTENSION
3 2000570 O RING
4 3960970 HOSE
5 391000 O RING
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s DeWalt websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to DeWalt brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
DeWalt DXPW005E - 25157
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
New

Download

Diagram DeWalt DXPW005E

Diagram DeWalt DXPW005E

Download (674.53KB)
