Castor Spare Parts for Chain Saw CP 660 20 (2006) 126220001
€2.61
Tax included
Castor Spare Parts for Chain Saw CP 660 20 (2006) 126220001
Castor Original spare parts at attractive prices never seen on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Chain Saw CP 660 20 (2006) 126220001.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Castor Spare Parts for Chain Saw CP 660 20 (2006) 126220001
Castor Original spare parts at attractive prices never seen on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Chain Saw CP 660 20 (2006) 126220001.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| ST. S.P.A. CP 660 20 (2006) 126220001 pag.1 | ||
| # | Part Num. | Description |
| 1 | 2412100 | Nut |
| 2 | 2321060 | Washer |
| 3 | 4152920 | Flywheel Assy |
| 4 | 2652260 | Screw |
| 5 | 3748440 | Flywheel Hook |
| 6 | 3653030 | Spring |
| 7 | 4152937 | Oil Tank Cap |
| 8 | 3744810 | Oil Tank Grommet |
| 9 | 2135130 | Screw |
| 10 | 3744100 | Anti-vibration Grommet |
| 11 | 2652640 | Screw |
| 15 | 8520740 | Crankcase Assy |
| 16 | 3640090 | Tube |
| 17 | 4251530 | Oil Vent Assy |
| 18 | 3723810 | Crankcase Gasket |
| 19 | 3180060 | Plug |
| 20 | 2112350 | Screw |
| 21 | 2135130 | Screw |
| 22 | 3781330 | Oil filter |
| 23 | 3744550 | Oil intake Hose |
| 24 | 3745400 | Oil Intake Grommet |
| 24 | 3745410 | Oil Delivery Grommet |
| 24 | 8152910 | Oil Pump Assy |
| 25 | 3180230 | Screw |
| 26 | 2321150 | Washer |
| 27 | 2135060 | Screw |
| 28 | 2370050 | Washer |
| 29 | 8652300 | Chain tensioner Assy |
| 30 | 4611560 | Plate |
| 31 | 2370050 | Washer |
| 32 | 2135060 | Screw |
| 33 | 3114070 | needle bearing |
| 34 | 2122090 | Screw |
| 35 | 4121390 | Clutch Drum - DISCONTINUED |
| 36 | 4150711 | Clutch Assy |
| 37 | 323026000/0 | Spike |
| 38 | 2135010 | Screw |
| 39 | 2370050 | Washer |
| 40 | 3121120 | Seal ring |
| 41 | 3112040 | Ball bearing |
| 42 | 4152740 | Crankshaft |
| 43 | 3151050 | Flywheel Key |
| 44 | 3114080 | Needle Bearing |
| 45 | 3723770 | Cylinder gasket |
| 46 | 3356020 | Circlip |
| 47 | 3158080 | Piston pin |
| 48 | 3123140 | Piston Ring |
| 49 | 383590000/0 | Piston Ø 47 Assy |
| 50 | 383070000/0 | Cylinder - Piston Assy |
| 51 | 2360060 | Washer |
| 52 | 3L4252080/2 | Decompressor |
| 53 | 2135030 | Screw |
| 54 | 2461030 | Square Nut |
| 55 | 1L3723780/1 | Washer |
| 56 | 4122200 | Muffler |
| 57 | 2370050 | Washer |
| 58 | 2135010 | Screw |
| 59 | 2135040 | Screw |
| 60 | 1L3210600/1 | Electronic coil |
| 61 | 2132550 | Screw |
| 62 | 2321150 | Washer |
| 63 | 2317110 | Washer |
| 64 | 3210024 | Spark Plug |
| 66 | 3748880 | Spark Plug cap |
| 67 | 3745130 | Grommet |
| 68 | 3657050 | Spark Plug Spring |
| 69 | 3657350 | Hose clamp |
| 70 | 4250100 | Intake Manifold Assy |
| 71 | 3612410 | Bushing |
| 72 | 4152940 | Carburetor Support |
| 73 | 3724350 | Carburetor Flange Seal |
| 74 | 3612670 | Carburetor flange |
| 75 | 3723870 | Carburetor Gasket |
| 76 | 8782590 | Pulse tube Assy |
| 77 | 3657140 | Cable tie |
| 80 | 123303500/0 | Repair Kit |
| 80 | 4253870 | Tillotson carburetor |
| 80 | 8723300 | Kit Membrane-Gaskets Carburator |
| 81 | 2382150 | Bushing |
| 82 | 2382140 | Bushing |
| 83 | 3612361 | Throttle shutter |
| 84 | 3781660 | Air Filter Support |
| 85 | 2321150 | Washer |
| 86 | 2135110 | Screw |
| 87 | 3781650 | Air filter |
| 89 | 8723710 | Gaskets Kit |
| ST. S.P.A. CP 660 20 (2006) 126220001 pag.2 | ||
| 1 | 2123030 | Screw |
| 2 | 4152860 | Recoil Starter Assy yellow |
| 2 | 4152863 | Assy Red Starter |
| 3 | 2172090 | Screw |
| 4 | 2123090 | Screw |
| 5 | 3749437 | Starter handle |
| 6 | 4250060 | Starter rope |
| 7 | 4150120 | Starter spring |
| 8 | 4561150 | Starter Pulley |
| 9 | 3613420 | Washer |
| 10 | 112154330/0 | Nut |
| 11 | 4253880 | Bulb |
| 12 | 4152887 | Fuel Cap Assy |
| 13 | 3786090 | Tube |
| 14 | 3786070 | Tube |
| 15 | 3210531 | Earth cables |
| 16 | 3210970 | Stop switch |
| 17 | 383300006/0 | Gray Handle Assy |
| 18 | 3653980 | Spring |
| 19 | 3743247 | Throttle lever |
| 20 | 3653580 | Spring |
| 22 | 3743257 | Safety Lever |
| 23 | 3655240 | Throttle rod |
| 24 | 2123090 | Screw |
| 25 | 2312180 | Washer |
| 26 | 3743277 | External Air Lever |
| 27 | 3743267 | Internal Air Lever |
| 28 | 3655170 | Air Lever |
| 29 | 3750230 | Fast Idle Lever |
| 30 | 3654460 | Spring |
| 31 | 4251040 | Intake Oil Assy |
| 32 | 3786080 | Venting Tube |
| 33 | 2123060 | Screw |
| 34 | 4152871 | Fuel Tank - OBSOLETE - NO LONGER AVAILABLE |
| 35 | 2123030 | Screw |
| 36 | 3745320 | Grommet |
| 37 | 2123140 | Screw |
| 39 | 2123110 | Screw |
| 40 | 2123030 | Screw |
| 41 | 4152817 | Handrail |
| 42 | 2123110 | Screw |
| 43 | 4564110 | Cylinder Yellow |
| 43 | 4564113 | cylinder cover Red |
| 44 | 4564120 | filter cover Yellow |
| 44 | 4564123 | filter cover Red |
| 45 | 3356030 | Elastic ring |
| 46 | 4152980 | Knob |
| 47 | 3612370 | Plate |
| 48 | 2123060 | Screw |
| 49 | 2123140 | Screw |
| 50 | 2321150 | Washer |
| 51 | 3749250 | Chain catcher |
| 52 | 2123060 | Screw |
| 53 | 2123140 | Screw |
| 53 | 2312090 | Washer |
| 53 | 2321150 | Washer |
| 53 | 3314080 | Plug |
| 53 | 3612390 | Brake band |
| 53 | 3641250 | Brake Tie |
| 53 | 3653720 | Brake Spring |
| 54 | 3612400 | plate |
| 55 | 2432040 | Nut |
| 55 | 2652890 | Screw |
| 55 | 3660350 | Brake connection |
| 56 | 2652880 | Screw |
| 57 | 3641260 | Washer |
| 58 | 4152897 | Handle Guard Assy |
| 58 | 4152950 | Brake Hook |
| 59 | 4252740 | Clutch Carter Assy Yellow |
| 59 | 4252743 | Clutch Carter Assy Red |
| 60 | 2670120 | Nut |
| 61 | 4112190 | 20inch guide bar |
| 62 | 4113373 | 20inch chain |
| 63 | 4181497 | 18 " Bar cover |
