Castor Spare Parts for Chain Saw TR 270
Castor Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair broken parts for Chain Saw TR 270/223010001-06-2012.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| Chain Saw TR 270/223010001-06-2012 Engine Pag.1 |
||
| # | Part Num. | Description |
| 1 | 6995173 | Nut |
| 2 | 6995207 | Flywheel Assy |
| 3 | 6995224 | Screw |
| 4 | 6995208 | Flywheel Starter Hook |
| 5 | 6995250 | Flywheel Spring |
| 6 | 6995225 | Washer |
| 7 | 6995247 | Seal Ring |
| 8 | 6995170 | Ball Bearing |
| 10 | 6995202 | Crankshaft |
| 11 | 6995169 | Washer |
| 12 | 6995237 | Needle Bearing |
| 13 | 6995200 | Piston |
| 14 | 6995172 | Piston Pin |
| 15 | 6995171 | Circlip |
| 16 | 6995201 | Piston Ring |
| 17 | 6995245 | Cylinder Assy |
| 18 | 6995186 | Stabilizer |
| 19 | 6995252 | Screw |
| 20 | 6995248 | Seal Ring |
| 21 | 6995229 | Screw |
| 22 | 6995185 | Muffler Gasket |
| 23 | 6995246 | Muffler |
| 24 | 6995251 | Plate |
| 25 | 6995182 | Screw |
| 26 | 6995210 | Earth Cable |
| 27 | 6995227 | Stop Wire |
| 28 | 6995234 | Screw |
| 29 | 6995209 | Electronic Ignition Coil |
| 30 | 6995022 | Spark Plug Spring |
| 31 | 6995066 | Spark Plug Cover |
| 32 | 6995238 | Bushing |
| 34 | 6995183 | Intake Manifold Assy |
| 36 | 6995212 | Gasket |
| 37 | 6995244 | Carburettor |
| 38 | 6995214 | Grommet |
| 39 | 6995213 | Choke Lever Rod |
| 40 | 6995243 | Air Filter Support |
| 41 | 6995211 | Plate |
| 41 | 6995168 | Screw |
| 43 | 6995217 | Air Filter |
| 44 | 6995216 | Air Cleaner Cover |
| 51 | 123878008/0 | Screw |
| 52 | 6995175 | Front Cover |
| 53 | 6995239 | Crankase Ass.Y |
| 54 | 6995187 | Screw |
| 55 | 183875001/0 | Breather Valve Assy |
| 56 | 6995232 | Grommet |
| 57 | 6995193 | Cap Ass’Y |
| 58 | 6995228 | Air Purge |
| 59 | 6995188 | Grommet Ass.Y |
| 60 | 6995189 | Grommet |
| 61 | 6995174 | Fuel Pickup Assy |
| 62 | 6995190 | Tube |
| 63 | 123878008/0 | Screw |
| 64 | 6995249 | Upper Cover |
| 65 | 6995194 | Guard |
| 66 | 6995180 | Chain Guard |
| 67 | 6995179 | Screw |
| 71 | 6995204 | Gasket |
| 72 | 6995223 | Washer |
| 73 | 6995191 | Filter Intank Assy With Pipe |
| 76 | 6995205 | Tube |
| 77 | 6995008 | Screw |
| 78 | 6995206 | Cover Pump |
| 79 | 123878008/0 | Screw |
| 80 | 6995230 | Needle Bearing |
| 81 | 6995176 | Drum Ass’Y, Clutch 3/8” |
| 81 | 6995178 | Drum Ass’Y, Clutch 1/4” |
| 82 | 6995203 | Sprocket Washer |
| 83 | 6995177 | Clutch Ass.Y |
| 84 | 6995241 | Plate |
| 85 | 6995220 | Valve |
| 86 | 6995192 | Gasket |
| 87 | 323275005/0 | Shock Absorber |
| 88 | 123878007/0 | Screw |
| 89 | 323790006/0 | Cap |
| 90 | 6995219 | Clamp |
| 91 | 123878009/0 | Screw |
| 92 | 6995231 | Fair Led |
| 93 | 6995184 | Tube |
| 94 | 6995235 | Tube Connection |
| 95 | 6995181 | Screw |
| Chain Saw TR 270/223010001-06-2012 Housing Pag.2 |
||
| 1 | 383058007/0 | Starter Assy Yellow |
| 1 | 383058008/0 | Starter Assy Red |
| 3 | 3750067 | Starter Handle |
| 5 | 323604001/0 | Starter Pulley |
| 6 | 123657002/0 | Washer |
| 7 | 123878010/0 | Screw |
| 8 | 323107501/0 | Air Conveyor |
| 9 | 123878008/0 | Screw |
| 10 | 323275004/0 | Grommet |
| 11 | 6995240 | Handle Assy |
| 12 | 6995114 | Spring |
| 13 | 6995134 | Throttle Lever |
| 14 | 6995016 | Elastic Pin |
| 15 | 6995196 | Cap |
| 16 | 323275005/0 | Shock Absorber |
| 17 | 123878007/0 | Screw |
| 18 | 323790006/0 | Cap |
| 19 | 6995226 | Switch |
| 20 | 6995198 | Tube |
| 21 | 6995199 | Tube Connection |
| 22 | 6995197 | Tube |
| 23 | 6995218 | Rear Cover |
| 24 | 6995215 | Throttle Rod |
| 25 | 6995135 | Safety Lever |
| 26 | 6995195 | Handle, Upper Part |
| 27 | 123878008/0 | Screw |
| 28 | 123878008/0 | Screw |
| 31 | 323790006/0 | Cap |
| 32 | 123878007/0 | Screw |
| 33 | 323275005/0 | Shock Absorber |
| 34 | 323105000/0 | Handle |
| 35 | 123878010/0 | Screw |
| 37 | 123878010/0 | Screw |
| 41 | 123878009/0 | Screw |
| 42 | 323311003/0 | Bar Plate |
| 43 | 123796004/0 | Nut |
| 44 | 123878005/0 | Screw |
| 45 | 123510093/0 | Pin |
| 46 | 323448001/0 | Brake Band |
| 49 | 323315061/0 | Lever |
| 51 | 123120000/0 | Nut |
| 52 | 123657003/0 | Washer |
| 54 | 323455005/0 | Hand Guard |
| 56 | 383315050/0 | Chain Brake Lever |
| 60 | 323080000/0 | Balance Weigth |
| 61 | 123878006/0 | Screw |
| 62 | 123878009/0 | Screw |
| 63 | 323109515/0 | Brake Cover |
| 64 | 323059008/0 | Clutch Cover Yellow |
| 64 | 323059009/0 | Clutch Cover Red |
| 65 | 3641380 | Bushing |
| 66 | 2670120 | Nut |
| 73 | 323085000/0 | Chain Cover |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Castor websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Castor brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
