Metabo genuine spare parts or replacements parts for to repair Cordless Drill BS 18 LTX Quick/02193000.
In the following table, look for the model of the Cordless Drill and the respective parts of the code.
| Cordles Drill BS 18 LTX Quick/02193000 | ||
| # | Part Num. | Description |
| 3 | 31101179 | Field coil compl.,4 pol. |
| 7 | 34343247 | Housing w.cover |
| 8 | 34339479 | Switch slide |
| 9 | 34339477 | Pressure plate |
| 10 | 34202167 | Spring clip |
| 11 | 34343325 | Switch slide,R/L |
| 12 | 31605165 | Switch slide compl. |
| 13 | 14111318 | Self-tap. fill. h. screw |
| 14 | 31605139 | Gear-box compl.,Quick |
| 15 | 31001116 | Armature compl.,18 V |
| 17 | 33805937 | Rating plate |
| 22 | 33812450 | Indication label,Ultra M |
| 30 | 31400103 | Side support handle compl. |
| 31 | 31605212 | Hook |
| 32 | 31605213 | Bit holding sleeves right |
| 40 | 34300118 | Brush holder compl.,4 pol. |
| 41 | 34308361 | Selector wheel compl. |
| 42 | 34340970 | Switch Ass'y = New Part Num. 31605384 |
| 43 | 14316012 | Toroidal Ferrite |
