Castelgarden Spare Parts for Chaisaw XC 3700

Name: Castelgarden Spare Parts for Chaisaw XC 3700
Brand: GGP Italy
SKU: XC3700 - 228116003/10-2011
Price: 1.56 EUR
Availability: InStock

€1.56

Tax included

Castelgarden Spare Parts for Chaisaw XC 3700

Distribution and Sale at attractive prices of CASTELGARDEN Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Chaisaw XC 3700/228116003/10-2011.

ITEM CODE: 2135030

118800185/0
123044213/0
112728124/0
118800243/0
118800188/0
123120004/0
118550584/0
118800246/0
118800249/0
118800191/0
123753000/0
118550587/0
118550590/0
118800252/0
118800194/0
123878020/0
123878023/0
118550593/0
118800255/0
118800197/0
118800200/0
323208402/0
118550596/0
118800258/0
118800204/0
383315051/0
118550599/0
118800263/0
118550602/0
118800278/0
2135180
118800207/0
118550605/0
118800745/0
2432040
118800210/0
3657050
118800213/0
118550608/0
118800748/0
112154320/0
118800216/0
118800183/0
118803925/0
118800186/0
123044214/0
118550582/0
118800244/0
118800189/0
123430572/0
118550585/0
118800247/0
118550588/0
118800250/0
118800192/0
123753001/0
118550591/0
118800253/0
118800195/0
123878021/0
118800198/0
123878025/0
118550594/0
118800256/0
118800201/0
323315067/0
118550597/0
118800260/0
118800264/0
2135030
118800205/0
118550600/0
118550603/0
118800742/0
2312090
118800208/0
118550606/0
118800746/0
3112030
118800211/0
3748880
118800214/0
118550609/0
118801745/0
118804231/0
112581500/0
118800242/0
118800184/0
118800187/0
123072005/0
118550583/0
118800245/0
118800190/0
123657007/0
118550586/0
118800248/0
118550589/0
118800251/0
118800193/0
123878017/0
118550592/0
118800254/0
118800196/0
123878022/0
118800199/0
323109525/0
118550595/0
118800257/0
118800202/0
323670001/0
118550598/0
118800262/0
118550601/0
118800266/0
2135050
118800206/0
118550604/0
118800744/0
2321050
118800209/0
118800212/0
118550607/0
118800747/0
3210024
8724091
118800215/0
118800128/0
118802952/0

Quantity

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Description
Product Details
Attachments

Castelgarden Spare Parts for Chaisaw XC 3700

Chaisaw XC 3700/228116003/10-2011
Engine Pag.1
#	Part Num.	Description
1	118800242/0	Cylinder assembly
2	2432040	Nut
3	112581500/0	Grower
4	2312090	Washer
5	123878022/0	Screw
6	118800243/0	Plate
7	118550582/0	Silencer
8	118550583/0	Silencer gasket
9	118550584/0	Screw
10	2135030	Screw
11	3210024	Spark Plug
12	118550585/0	Cylinder Manifold Gasket
13	118550586/0	Intake manifold
14	118550587/0	Carburettor gaskets
15	118550588/0	Cylinder Base Gasket
16	118550589/0	Piston Ring
17	118800244/0	Piston pin
18	118550590/0	Circlip
19	118800245/0	Piston
20	118800246/0	Bearing
21	118550591/0	Needle Bearing
22	118800247/0	Crank Shaft
23	123072005/0	Flywheel key
24	118800248/0	Crankcase, starter side
25	3112030	Ball bearing
26	118800249/0	Crankcase, Gasket
27	118800250/0	Crankcase, clutch side
29	118550592/0	Sealing ring
30	2135050	Screw
31	118550593/0	Screw
34	118550596/0	Spiked Bamper
35	2135180	Screw
36	118550597/0	catcher
37	118800251/0	Screw
38	118550598/0	Bar Base Sheet
39	123878020/0	Screw
40	118550599/0	Sealing ring
41	118550600/0	Analog Ignition coil
41	118803925/0	Digital Ignition coil + Digital Flywheel
42	123878021/0	Screw
43	2321050	Washer
44	118550601/0	Ground cable
45	123120004/0	Nut
46	118550602/0	Flywheel ASS'Y- FOR ANALOG IGNITION COIL
46	118804677/0	Flywheel Assy
51	118550603/0	Clutch assembly
55	118800252/0	Washer
56	118550604/0	Clutch Drum Assembly
57	118550605/0	Needle Bearing
58	118550606/0	Worm Screw
59	118800253/0	Oil pump cover
60	118550607/0	Oil Pump Assembly
61	118800254/0	Tube
62	118550608/0	Washer
63	118800255/0	Oil intake hose
65	118800256/0	joint
66	118550609/0	Oil Filter Assembly
67	118802952/0	Oil nozzle Supply
70	8724091	Carb Membrane-Gasket Kit.
71	118800210/0	Carburetor
72	118800211/0	Intake manifold
73	118800212/0	Screw
74	118804231/0	Primer
75	118800204/0	hose
76	3657050	Spark Plug Spring
77	3748880	Spark Plug Cap
Body Pag.2
1	118800183/0	Clutch Cover Assembly Black
2	123878017/0	Screw
3	123044213/0	Bushing
4	123044214/0	Bushing
5	118800184/0	Handle Guard
6	118800748/0	Counterweight
7	123430572/0	Spring
8	118800747/0	Spring
9	123657007/0	Washer
10	112154320/0	Nut
11	323670001/0	plate
12	118800745/0	Spring
13	118800257/0	Bar Base Sheet
14	123753001/0	Plug
15	383315051/0	Brake Release Lever
17	123753000/0	roll
18	323315067/0	Brake Link Lever
19	118800746/0	Brake Spring
20	118800185/0	Brake tape
21	123878023/0	Screw
22	323109525/0	Brake Spring Cover
25	118800186/0	Nut
26	118800187/0	Nut
27	118800258/0	Washer
28	118800260/0	filter cover Red
29	118800188/0	Air filter
30	118800262/0	cylinder cover Red
31	118800742/0	grommet
34	118800189/0	Screw
35	118800263/0	grommet
37	118800264/0	Air lever rubber
38	118800190/0	Throttle rod
40	118800191/0	Starter Assembly Black
44	118800192/0	Starter Pulley
46	118800278/0	Starter Spring
47	118800193/0	Starter handle
50	123878025/0	Screw
51	118800266/0	Shok Absorber rubber
52	123878022/0	Screw
53	118800194/0	Shok Absorber
54	118800195/0	Shok Absorber cap
55	118800196/0	Spring
56	118800197/0	Grip-Handrail
59	323208402/0	plate
60	118800198/0	Vent Valve Assembly
64	118800744/0	grommet
65	112728124/0	Screw
66	118800255/0	Oil Intake Tube
67	118800214/0	Fuel filter
68	118800200/0	Handle assembly
69	118800201/0	Spring
72	118800199/0	Fuel filter
76	118800202/0	Switch
79	118800205/0	Safety Lever
80	118800206/0	Spring
81	118800207/0	Throttle lever
82	118800208/0	Spring
83	118800209/0	Grip cover
88	118800213/0	Stop cable
91	118800215/0	Fuel Cap Assembly
92	118800216/0	Oil Cap Assembly
93	118550594/0	Chain tensioner anchor
94	118550595/0	Screw
95	118800128/0	Guide Bar 16 "-3/8" -0.050 "
96	118801745/0	Chain 16 "-3/8" -0.050 "-57E
