Bosch Spare Parts for Electric Chain Saw GKE 40 BC

€1.65
Tax included

Bosch Spare Parts for Electric Chain Saw GKE 40 BC

Bosch genuine replacement parts for to replace broken parts for to fix Electric Chain Saw GKE 40 BC - 0601586803.

Bosch GKE 40 BC - 0601586803
ITEM CODE: 1600101023
Quantity
Usually Ships in: 10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Bosch Spare Parts for Electric Saw GKE 40 BC

Bosch genuine replacement parts for to replace broken parts for to fix Electric Chain Saw GKE 40 BC - 0601586803.

In the following table, look for the model of the Electric Saw and the respective parts of the code.
<Bosch GKE 40 BC - 0601586803

Electric Chain Saw GKE 40 BC/0 601 586 803
# Part Num. Description
1 3605108103 Motor Housing BLUE
2 1604220357 Field 220-240V
6 1600703025 Grommet Ø9,6-Ø10,2x70 MM
7 2601035001 Cable Clip
9 1601110483 Manufacturer's nameplate
12 1607328028 Suppression Filter
13 3600905135 Deep Groove Ball Bearing 607-2Z
14 3600905136 groove ball bearing
16 1604336024 Brush Holder
20 2603410001 Socket head cap screw M3x6,5-4.8
23 3605500084 Sealing cap BLACK
24 3602311018 Protective Shield
26 3605500037 Protective Cover
27 3601012000 Cover Strip
28 1600502011 Intermediate Ring
30 3600591003 Air-Deflector Ring
32 3600190007 Conical Spring Washer
33 1600206026 Intermediate Ring
34 1600290016 Rotary shaft lip seal
35 1600300090 Intermediate Ring
36 3606317021 Cylindrical Gear Z=41
37 1600910018 Needle bearing Ø8xØ12x8 MM
38 3603124011 Drive Shaft
39 3600323000 Headed Bush - DISCONTINUED
41 2916650903 Spring retaining ring DIN 471-12x1-FSTM
42 3600283034 Rotary shaft lip seal 8X12X3
43 3607030320 Oil Reservoir
47 3603121004 Stud bolt
48 3601990001 Swivelling Lever
55 3604651002 Coiled Spring
56 3604431018 Connecting Cable L=420 MM BLUE
57 3604431012 Connecting Cable L=180 MM WHITE - DISCONTINUED
58 1604477005 Blade terminal
61 2915011007 Hex Nut DIN 934-M6-8-A
62 3603414026 Lens Head Screw DIN 7981-ST3,9x16-C-H
63 3603410001 Socket head cap screw
64 2910141203 Hex Socket Head Cap Screw DIN 912-M6x25-8.8
67 2914201506 Oval-Head Screw 4x18 MM,TORX T20
68 2914411403 Thread-forming tap. Screw DIN 7500-CM 5x12-ST
69 3600000006 Cover Plate
71 3600703001 Hose - DISCONTINUED
72 1903230007 Ball DIN 5401-4 MM-III-ST
74 3604431013 Connecting Cable L=260 MM WHITE - DISCONTINUED
75 3604630000 Compression Spring
78 1907950006 Offset Screwdriver DIN 911-SW5 BLACK
79 3601119077 Reference Plate CAUTION
80 3601110241 Reference Plate
87 1600101023 Plain Washer 0,5 MM THICK
88 3603121003 Detent Pin
90 2914552107 Microencapsulated Screw DIN 84-AM4x12-8.8
90 2910211006 Tapping Screw DIN 7971-BZ2,9x13
91 3600210015 O-Ring 4,0x1,0 MM
92 3600301007 Sintered-Metal Bushing 14 MM
93 3607218001 Speed governor 230-240V
94 3604438005 Connecting Cable L=300 MM GRAY
95 3604438004 Connecting Cable L=300 MM BLUE - DISCONTINUED
96 3604438006 Connecting Cable L=420 MM WHITE
100 1601110310 Reference Plate
199 1601110286 Reference Plate
650 3605500038 Protective Cover BLACK
745 3602317011 Guide Rail 400 MM
746 3604730008 Saw Chain 400 MM
804 1607200107 On-Off Switch
816/30 1607014129 Carbon-Brush Set
816/40 2604652008 Spiral Spring
821 3607031214 Housing Section
825 3605500082 Gear Cover
830 3604010050 Armature 220-240V
835 1614460026 Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F
840 3607031199 Sprocket wheel
844 3603317002 Reservoir Cap
853 3607031182 Braking Device
873 3606317031 Spindle With Gear Z=38
888 1601106032 Nameplate 26x52 MM
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GKE 40 BC - 0601586803
10 Items

Data sheet

SHIPPING IN:
RESERVATION ONLY
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
New

Download

Diagram Bosch GKE 40 BC

Diagram Bosch GKE 40 BC

Download (100.8KB)
