Bosch Spare Parts for Router GOF 1300 CE - 0601613660
Bosch genuine replacement parts for to replace broken parts for to fix Router GOF 1300 CE/230 V/EU - 0601613660.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Router GOF 1300 CE - 0601613660
Bosch genuine replacement parts for to replace broken parts for to fix Router GOF 1300 CE/230 V/EU - 0601613660.
In the following table, look for the model of the Router and the respective parts of the code.
| Router GOF 1300 CE/230 V/EU - 0601613660 | ||
| # | Part Num. | Description |
| 1 | 3605108584 | Motor HousingBLUE |
| 2 | 2610941203 | Field230V |
| 3 | 2610941202 | Armature230V |
| 4 | 2607200251 | Switch |
| 5 | 3604460557 | Power supply cordEU 4,25m 2 x 1,0mm H07 RN-F |
| 6 | 2610947359 | Grommet |
| 7 | 2601035001 | Cable Clip |
| 9 | 2610998943 | Reference Plate |
| 12 | 1617328025 | Suppression Filter |
| 13 | 3600905513 | Ball guide |
| 14 | 3600905512 | Ball guide |
| 19 | 2610910566 | Tapping Screw |
| 22 | 2610997096 | Housing |
| 23 | 3600590508 | Air-Deflector Ring |
| 24 | 3600034506 | Retaining Plate |
| 25 | 3603300502 | Hex Nut |
| 27 | 2610997099 | Cover Plate |
| 28 | 2610997093 | Rod |
| 29 | 2610997094 | Pointer |
| 30 | 2610943199 | Housing Cover |
| 33 | 3601021510 | Swing-Plate |
| 34 | 3604651502 | Torsion Spring |
| 35 | 3603415556 | Shoulder ScrewM4 |
| 36 | 3603231539 | Knob |
| 37 | 3600209500 | Indicator Ring |
| 38 | 3600100528 | Spring Washer |
| 39 | 3600100527 | Washer |
| 40 | 3600360507 | Adjusting Sleeve |
| 41 | 3600400507 | Locking Piece |
| 42 | 2916680005 | Spring Lock WasherB 4 DIN 127 |
| 43 | 3602000510 | Locking Lever |
| 44 | 3603450504 | Lock Bolt |
| 45 | 3604651503 | Lock Spring |
| 46 | 2610997191 | Depth-Gauge |
| 47 | 2600590006 | Ratchet Cap |
| 48 | 3916060500 | Spring Washer |
| 49 | 2910641122 | Oval-Head ScrewDIN 7985-M4X12-4.8-H |
| 50 | 1613480009 | Wing ScrewM6x25 MM |
| 51 | 2610997100 | Compression Spring |
| 52 | 2610943197 | Handle Cover |
| 53 | 2610943198 | Handle Cover |
| 54 | 2610915161 | Screw |
| 55 | 2916650003 | Spring retaining ringDIN 471-12x1-FSt |
| 56 | 2610912599 | Chip Deflector |
| 57 | 3604613508 | Compression Spring |
| 58 | 3603120502 | Guide Piece |
| 59 | 3605510548 | Bellows |
| 60 | 3601010519 | Insert |
| 61 | 1604477005 | Blade terminal |
| 62 | 3604680502 | Retaining snap ring |
| 63 | 2610991306 | Tapping Screw |
| 64 | 3600210507 | O-Ring |
| 65 | 2610945855 | Cable |
| 66 | 2610945856 | Cable |
| 67 | 3600150501 | Spring Lock Washer |
| 68 | 1607233153 | Control Unit230V |
| 69 | 2610912471 | Nameplate |
| 70 | 3603410504 | Socket head cap screw |
| 71 | 1903230007 | BallDIN 5401-4 MM-III-ST |
| 73 | 2610996090 | Set ring |
| 74 | 2910611006 | Tapping ScrewDIN 7981-ST2,9x13-C-H |
| 77 | 3601010521 | Insert |
| 91 | 1610210233 | O-Ring12,0x2,0 MM |
| 92 | 2610913282 | Plain Washer |
| 650/1 | 2610992417 | Single-Head Eng. Wrench |
| 731 | 2608570108 | Collet1/2" |
| 731 | 2608570107 | Collet12 MM |
| 731 | 2608570106 | Collet3/8" |
| 731 | 2608570105 | Collet8 MM |
| 731 | 2608570104 | Collet1/4" |
| 731 | 2608570103 | Collet6 MM |
| 731 | 2608570125 | Collet10 MM |
| 808 | 2610948995 | Nameplate |
| 810 | 2610007957 | Carbon-Brush Set |
| 816 | 2610013632 | Brush Holder |
| 821 | 3604652501 | Spring |
| 826 | 2610997115 | Base |
