Bosch Spare Parts for Angle Grinder PWS 7-125
€1.57
Tax included
Bosch Spare Parts for Angle Grinder PWS 7-125
We are BOSCH original spare parts Dealers at low at discounted prices and an service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder PWS 7-125/0 603 374 003.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Angle Grinder PWS 7-125
We are BOSCH original spare parts Dealers at low at discounted prices and an service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder PWS 7-125/0 603 374 003.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder PWS 7-125/0 603 374 003 | ||
| # | Part Num. | Description |
| 1 | 1605108189 | Motor Housing GREEN |
| 2 | 1604220272 | Field 220-230V |
| 3/50 | 1606610121 | Fan |
| 4 | 1607200086 | Switch |
| 4/10 | 2910110048 | Pan head screw DIN 85-AM3x6-CUZN |
| 6 | 2600703012 | Grommet Ø6,5-Ø6,9x95 MM |
| 6a | 2600703011 | Grommet Ø8,3-Ø9,4x95 MM |
| 6b | 2600703013 | Grommet Ø7,6-Ø8,2x95 MM |
| 7 | 1601302017 | Fastening Clamp |
| 9 | 1601118711 | Reference Plate |
| 12 | 1607328029 | Suppression Filter |
| 13 | 2600905032 | Deep-Groove Ball Bearing 7x19x6 |
| 14 | 1600905011 | Deep-Groove Ball Bearing 8x22x7 |
| 18 | 1604611026 | Compression Spring |
| 22 | 1602319002 | Adjusting Slide |
| 23 | 1602026057 | Switch Handle BLACK |
| 25 | 1600508005 | Housing Cover GREEN |
| 26 | 1600502020 | Rubber Bushing |
| 27 | 1600206025 | Rubber Ring |
| 28 | 1605805061 | Bearing Flange |
| 29 | 1601328005 | Air-Deflector Ring |
| 32 | 1603523110 | Grinding Spindle M14, SW17 |
| 35 | 1600136012 | Shim 0,1 MM THICK |
| 35a | 1600136010 | Shim 0,2 MM THICK |
| 35b | 1600136011 | Shim 0,3 MM THICK |
| 36 | 1600150011 | Spring Washer |
| 38 | 1606333606 | Crown Gear Z=36 |
| 39 | 1604652013 | Spiral Spring |
| 40 | 2916660009 | Spring retaining ring DIN 472-25x1,2MM |
| 43 | 1606333605 | Bevel Gear Z=11 |
| 45 | 1603300016 | Hex Nut M7, SW10 |
| 47 | 2910211018 | Tapping Screw DIN 7971-ST3,9x13-F |
| 48 | 2910211005 | Tapping Screw DIN 7971-ST2,9x9,5-F |
| 49 | 2912401420 | Tapping Screw DIN7981-ST3,9x19-F-Z |
| 50 | 2912401420 | Tapping Screw DIN7981-ST3,9x19-F-Z |
| 53 | 1604448015 | Connecting Cable |
| 54 | 1604448016 | Connecting Cable |
| 55 | 2912401420 | Tapping Screw DIN7981-ST3,9x19-F-Z |
| 104 | 1600210044 | O-Ring 4,5x1,0 MM BLUE |
| 650/50/20 | 1600210039 | O-Ring 20,35x1,78 MM |
| 652/20 | 2910022197 | Socket head cap screw DIN 84-M 6x16-8.8 |
| 652/20a | 2910141197 | Hex Socket Head Cap Screw DIN 912-M6x16-8.8 |
| 750/10 | 2602025067 | Auxiliary Handle M10, Ø32,5x105 MM |
| 750/20 | 1603340040 | Clamping Nut M14 |
| 750/30 | 1607950043 | Pin-Type Face-Wrench |
| 750/50 | 1605703099 | Clamping-Flange Ø22,2x42 MM |
| 752 | 1605510117 | Protective Cover Ø 125 MM (5") |
| 753 | 1603340027 | Fast Locking Flange M14, SDS-CLIC |
| 803 | 1604010429 | Armature With Fan 220-230V |
| 805 | 1607000386 | Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F |
| 808 | 1601106032 | Nameplate 26x52 MM |
| 810 | 1607014162 | Carbon-Brush Set |
| 816 | 1600A003G4 | Brush Holder |
| 821 | 1605806483 | Gear Housing - OUT OF STOCK |
| 821/010 | 1607000253 | Push-Button BLACK |
| 838 | 1607000943 | Crown Gear |
| 841 | 1600910018 | Needle bearing Ø8xØ12x8 MM |
