AGP Europe Spare Parts for Concrete Grinder G5
€92.34
Tax included
AGP Europe Spare Parts for Concrete Grinder G5
We have the original Spares AGP Europe Parts for Concrete Grinder G5 the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Concrete Grinder G5. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
AGP Europe Spare Parts for Concrete Grinder G5
Fix Your Concrete Grinder G5. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Concrete Grinderl and the respective parts of the code.
| MODEL : G5 CONCRETE GRINDER (AGP Europe) Version 3.0 | ||
| NO. | Code | Parts Name |
| 1.) | 206-031502300-02 | POWER SUPPLY CABLE (VDE-1.5x2Cx3M-H07RNF) |
| 2.) | 203-0004-00000-001 | CORD ARMOR |
| 3.) | 403-M04014003-020 | PANHEAD TAPPING SCREW-B (M4x14) |
| 4.) | 303-01003-004-001 | CABLE CLIP |
| 5.) | 0299-0014-00004-012 | TRIGGER SWITCH (LOCK-ON) |
| 6.) | N/A | |
| 7.) | 303-01001-004-012 | HANDLE HALF-RIGHT (BLACK) |
| 8.) | 303-01001-004-013 | HANDLE HALF-RIGHT (BLACK) |
| 9.) | 403-M04035003-020 | PANHEAD TAPPING SCREW-B (M4x35) |
| 10.) | 403-M04020003-020 | PANHEAD TAPPING SCREW-B (M4x20) |
| 11.) | 403-M04025003-020 | PANHEAD TAPPING SCREW-B (M4x25) |
| 12.) | 303-01002-004-012 | HANDLE HALF-LEFT (BLACK) |
| 13.) | 303-01002-004-013 | HANDLE HALF-LEFT (BLACK) |
| 14.) | 305-03358-000-001 | RUBBER PLUG |
| 15.) | 406-M04006070-050 | SOCKET CAP SCREW (M4x6xP0.7) |
| 16.) | 302-04450-903-001 | CROSS BAR LOWER |
| 17.) | 302-04450-903-002 | CROSS BAR UPPER |
| 18.) | N/A | |
| 19.) | 299-0178-00000-001 | ANTI-VIBRATION MOUNT |
| 20.) | 403-M05035003-160 | PANHEAD TAPPING SCREW-B (M5x35) |
| 21.) | 303-01008-004-018 | MOTOR TAIL CASTING (BLACK) |
| 22.) | 303-01008-004-019 | MOTOR TAIL CASTING (BLACK) |
| 23.) | 402-M04030003-020 | PANHEAD TAPPING SCREW-B-W/WASHER (M4x30) |
| 24.) | 203-0010-00100-001 | THUMB WHEEL (ORANGE-021C) |
| 25.) | 204-0004-22000-017 | ELECTRONICS UNIT (220V) |
| 26.) | 305-00018-000-001 | THREE WIRE PUSH IN CONNECTOR |
| 27.) | 403-M04010002-050 | PANHEAD TAPPING SCREW-B (M4x10) |
| 28.) | 302-04009-000-005 | BRUSH SPRING (0.35x4x4T) |
| 30.) | 307-02006-000-002 | CARBON BRUSH HOLDER (7x17) |
| 31.) | 407-M04010070-050 | PANHEAD MACHINE SCREW (M4x10xP0.7) |
| 32.) | 424-041010-10 | FLAT WASHER (Ø4xØ10x1) |
| 33.) | 432-M04000-00 | RUBBER WASHER (Ø4xØ11x1) |
| 34.) | 302-01007-000-002 | PICKUP MAGNET (Ø8xØ15x5) |
| 35.) | 302-04018-901-001 | SPACER (Ø8xØ12x10.5) |
| 36.) | 303-01251-026-015 | MOTOR HOUSING (GRAY-RAL7016) |
| 37.) | 299-0002-20000-126 | STATOR (220V-94x54x45) |
| 38.) | 402-M05060003-020 | PANHEAD TAPPING SCREW-B-W/WASHER (M5x60) |
| 39.) | 303-01057-004-005 | FAN BAFFLE (BLACK) |
| 40.) | 302-05514-000-008 | BALL BEARING (6200) |
| 41.) | 299-0001-20000-150 | ARMATURE (220V-94x54x45) |
| 42.) | 302-05516-000-002 | BALL BEARING (6202) |
| 43.) | 302-06018-000-009 | ARMATURE GEAR (M1.5x12T) |
| 44.) | 201-0003-00164-059 | GEAR PLATE (RED-187C) |
| 45.) | 407-M04025070-050 | PANHEAD MACHINE SCREW (M4x25xP0.7) |
| 46.) | 303-01215-004-002 | HANDLE BRACKET (BLACK) |
| 47.) | 302-05502-000-001 | BALL BEARING (608) |
| 48.) | 302-06008-000-046 | OUTPUT GEAR (M1.5x28T) |
| 49.) | 201-0002-00026-086 | GEAR HOUSING (GRAY-RAL7016) |
| 50.) | 406-M04012070-090 | SOCKET CAP SCREW (M4x12xP0.7) |
| 51.) | 402-M05045003-020 | PANHEAD TAPPING SCREW-B-W/WASHER (M5x45) |
| 52.) | 422-S17-0 | EXTERNAL CIRCLIP (S-17) |
| 53.) | 302-05523-000-002 | BALL BEARING (6303) |
| 54.) | 421-05012-10 | PARALLEL KEY (5x5x12) |
| 55.) | 302-04003-000-170 | SPINDLE (M14xP2.0-88MM) |
| 56.) | N/A | |
| 57.) | N/A | |
| 58.) | N/A | |
| 59.) | N/A | |
| 60.) | 406-M04010070-160 | SOCKET CAP SCREW (M4x10xP0.7) |
| 61.) | N/A | |
| 62.) | N/A | |
| 63.) | N/A | |
| 64.) | N/A | |
| 65.) | 302-04222-903-008 | INNER FLANGE (Ø22.2 / Ø25.4) |
| 66.) | 302-04114-901-004 | OUTER FLANGE (M14) |
| 67.) | 305-00039-901-001 | LOCK NUT WRENCH (30MM) |
| 68.) | 302-04179-901-001 | FACE SPANNER WRENCH (93MM) |
| 69.) | N/A | |
| 70.) | N/A | |
| 71.) | 423-25100-2 | ZIP TIE (2.5x100MM) |
| 72.) | 0205-0014-00000-003 | WIRE SLEEVE (Ø6x45CM) |
| 73.) | 305-00010-904-013 | HEX KEY (M6) |
| 74.) | N/A | |
| 75.) | N/A | |
| 76.) | N/A | |
| 77.) | N/A | |
| 78.) | N/A | |
| 79.) | N/A | |
| 80.) | 303-01331-164-001 | HALF-MOON DOOR (RED-187C) |
| 81.) | 203-0112-00004-005 | CLEANING BRUSH |
| 82.) | N/A | |
| 83.) | 403-M04010003-020 | PANHEAD TAPPING SCREW-B (M4x10) |
| 84.) | 303-01081-004-007 | DUST SKIRT (BLACK) |
| 85.) | 203-0112-00004-006 | CLEANING BRUSH |
| 86.) | 202-0145-00901-001 | SHOULDER BOLT (M4xP0.7x26L) |
| 87.) | 413-M04010003-020 | FLAT HEAD TAPPING SCREW-B (M4x10) |
| 88.) | 303-01300-004-001 | COVER PANEL (BLACK) |
| 89.) | 302-04026-000-010 | SPRING (Ø0.55xØ4.9xØ6x15Lx6T) |
| 90.) | 303-02002-004-053 | OIL SEAL (Ø24xØ32x4) |
| 91.) | 302-03182-903-005 | BEARING PLATE |
| 92.) | 305-00001-000-028 | CARBON BRUSH (7x17x20) |
