Bosch Spare Parts for Planer PHO30-82
Bosch Original spare parts sourced from the manufacturer, with after-sales service at the lowest price on the web for to make maintenance or repair deteriorated parts for Planer PHO 30-82 - 0603259250.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Planer PHO30-82
Bosch Original spare parts sourced from the manufacturer, with after-sales service at the lowest price on the web for to make maintenance or repair deteriorated parts for Planer PHO 30-82 - 0603259250.
In the following table, look for the model of the Planer and the respective parts of the code.
| Planer PHO 30-82/0 603 259 250 | ||
| 2 | 1604220231 | Field 220V |
| 3/50 | 1606610122 | Fan |
| 4 | 2607200261 | On-Off Switch |
| 5 | 2604460102 | Power supply cord I 4,15m 2 x 1,0mm H05VV-F |
| 6 | 2600703012 | Grommet Ø6,5-Ø6,9x95 MM |
| 6 | 2600703011 | Grommet Ø8,3-Ø9,4x95 MM |
| 7 | 2601035001 | Cable Clip |
| 9 | 2601110791 | Sticker SUNNY SIDE |
| 12 | 1607328028 | Suppression Filter |
| 13 | 2600905051 | Deep-Groove Ball Bearing 7x19x6 |
| 14 | 2600905052 | Deep-Groove Ball Bearing 8x22x7 |
| 16 | 2604337002 | Brush Holder |
| 18 | 2603410001 | Socket head cap screw M3x6,5-4.8 |
| 19 | 2910611019 | Tapping Screw DIN 7981-ST3,9x16-C-H |
| 20 | 1601110481 | Manufacturer's nameplate SHADOW SIDE |
| 25 | 1600502011 | Intermediate Ring |
| 26 | 1600206026 | Intermediate Ring |
| 27 | 2600910001 | Needle bearing Ø14 MM |
| 28 | 2600324009 | Toothed Belt Wheel Z=19 |
| 29 | 2606625009 | Toothed Belt Wheel Z=43 |
| 31 | 2604736002 | Toothed Belt 14 MM, Z=85 |
| 32 | 3605500024 | Gear Cover BLACK |
| 33 | 1601099010 | Scale Window |
| 34 | 2606621001 | Graduated Dial |
| 37 | 3601320001 | Adjusting Slide |
| 38 | 1601006006 | Rubber band |
| 39 | 1605510142 | Protective Cover |
| 40 | 2910601320 | Rec ct-sunk tapping screw DIN7982-ST3,9x19-C-H |
| 41 | 3600290011 | Air-Deflector Ring |
| 42 | 2604652008 | Spiral Spring |
| 43 | 1604619017 | Compression Spring |
| 44 | 1605510139 | Protective Cover |
| 45 | 1604651007 | Compression Spring |
| 46 | 2608000059 | Adjusting Disc |
| 47 | 2603490017 | Torx Oval-Head Screw 3x10 |
| 48 | 1600190016 | Tab Washer |
| 49 | 2605500096 | Handle Cover GREEN |
| 50 | 2600100033 | Shim |
| 51 | 2600190008 | Tab Washer |
| 52 | 2600100588 | Shim 0,5 MM |
| 53 | 1600100632 | Shim 0,2 MM THICK |
| 55 | 2600905052 | Deep-Groove Ball Bearing 8x22x7 |
| 56 | 3600100005 | Shim 0,5 MM THICK |
| 57 | 3604431005 | Connecting Cable L=238 MM WHITE |
| 58 | 3604431006 | Connecting Cable L=383 MM WHITE |
| 61 | 2915011007 | Hex Nut DIN 934-M6-8-A |
| 62 | 2603320004 | Square Nut M6 |
| 63 | 3603342003 | Adjusting Nut |
| 64 | 3603450005 | Hex Screw |
| 72 | 2603320003 | Square Nut M8 |
| 73 | 2603342006 | Round Nut M6 LEFTHAND THREADS |
| 75 | 1603100036 | Rubber Buffer |
| 77 | 2605510036 | Cover |
| 85 | 1600410003 | Slotted Spring Pin |
| 86 | 2603400014 | Set screw |
| 87 | 2603450005 | Hex Screw |
| 704 | 1605411022 | Chips Bag |
| 704/10 | 1605190030 | Fitting |
| 704/20 | 1605703073 | Clamping Piece |
| 704/30 | 2608045003 | Retaining Bracket |
| 704/40 | 1605411022 | Chips Bag |
| 704/50 | 2603490017 | Torx Oval-Head Screw 3x10 |
| 705 | 1607000154 | Connecting Pipe Ø 35 MM |
| 706 | 1608132006 | Depth-Gauge |
| 706/10 | 1601331039 | Stop Bracket |
| 706/20 | 2603480003 | Wing Screw M 6x16 MM |
| 706/30 | 2916011014 | Plain Washer DIN 125-A 6,4-ST |
| 706/40 | 1610210043 | O-Ring 4,0x1,5 MM |
| 707 | 2607001078 | Width Stop 45° |
| 712 | 603095002 | Base |
| 714 | 2607000102 | Parallel-Guide |
| 754 | 2607950504 | Single-Head Eng. Wrench |
| 771 | 2608040039 | Grip-Spring Tensioning E |
| 774 | 2607000096 | Planing Knife |
| 801 | 2605104991 | Housing Section GREEN |
| 801 | 2605104981 | Housing Section BLUE |
| 803 | 2604010924 | Armature 220V |
| 810 | 2607014003 | Carbon-Brush Set |
| 813 | 1610905025 | Deep-Groove Ball Bearing 7x19x6 |
| 835 | 3605510012 | Covering hood |
| 870 | 2603204903 | Planer Head |
| 888 | 1601106032 | Nameplate 26x52 MM |
