Femi Spare Parts for Stationary Band Saws 2200DA XL - 8487024
€3.81
Tax included
Femi Spare Parts for Stationary Band Saws 2200DA XL - 8487024
Femi Genuine spare parts or replacement parts for to repair Stationary Band Saw 2200DA XL - 8487024.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Stationary Band Saws 2200DA XL - 8487024
Femi Genuine spare parts or replacement parts for to repair Stationary Band Saw 2200DA XL - 8487024.
In the following table, look for the model of the Band Saw and the respective parts of the code.
| Band Saw FEMI 2200DA XL - 8487024 | ||
| # | Part Num. | Description |
| 1 | 5130796 | STOP PLATE |
| 3 | 0147007 | Stationary Band Saw 2200DA XL - 8487024 |
| 6 | 0147017 | HAND LEVER |
| 7 | 5182532 | COVER |
| 8 | 5152594 | VICE JAW |
| 9 | 5152595 | VICE JAW |
| 11 | 5130864 | VICE SCREW SUPPORT |
| 12 | 5137963 | COMPLETE VICE GROUP |
| 14 | 0152630 | ELASTIC PIN |
| 16 | 5152611 | VICE JAW |
| 17 | 5130863 | MOBILE VICE |
| 18 | 5159517 | INDEX |
| 20 | 0140059 | LEVER COVER |
| 22 | 5171040 | PIN |
| 23 | 5142023 | LEVER |
| 24 | 5100334 | VICE SCREW |
| 25 | 0140073 | HANDGRIP |
| 26 | 5142090 | QUICK LOCKING LEVER |
| 27 | 5171035 | BUSHING |
| 28 | 0152430 | ELASTIC PIN |
| 30 | 5124033 | WASHER |
| 31 | 0120708 | PLAIN WASHER |
| 34 | 5133703 | TANK BASE |
| 35 | 7113524 | ELECTRIC PUMP |
| 36 | 5871072 | CABLE |
| 38 | 5182533 | PUMP SUPPORT |
| 39 | 5182534 | TANK FILTER |
| 40 | 5124056 | WASHER |
| 42 | 5401935 | PLATE |
| 43 | 0402905 | RIVET |
| 44 | 0124032 | PLAIN WASHER |
| 46 | 5171038 | VICE PIN |
| 47 | 0101716 | SELF-LOCKING NUT |
| 49 | 0606203 | BALL BEARING |
| 51 | 0606306 | BALL BEARING |
| 52 | 5171039 | JOINT PIN |
| 53 | 5063036 | BUSHING |
| 54 | 0802316 | SWITCH |
| 55 | 5182504 | SWITCH COVER |
| 57 | 5124060 | WASHER |
| 58 | 0606204 | BALL BEARING |
| 60 | 5214224 | FREE WHEEL |
| 61 | 5130746 | GUIDE |
| 62 | 5001562 | SHAFT |
| 63 | 5081007 | SPRING |
| 64 | 5142058 | LEVER |
| 65 | 5100505 | BLADE TENSIONING SCREW |
| 66 | 5120661 | SPACER |
| 68 | 5122017 | SPRING CONTEINER |
| 69 | 5124030 | WASHER |
| 70 | 0064002 | BEARING FIFTH WHEEL |
| 71 | 0711528 | CAGE BEARING |
| 72 | 0140099 | BLADE TENSIONING KNOB |
| 73 | 0080260 | SPRING WASHER |
| 76 | 5066016 | BUSHING |
| 77 | 0801101 | MICROSWITCH |
| 78 | 5182842 | SWITCH BOX |
| 80 | 5143005 | MICROSWITCH BUTTON |
| 81 | 5142059 | LEVER |
| 82 | 5182523 | LIGHT PILOT COVER |
| 84 | 0106120 | SELF-LOCKING RING NUT |
| 86 | 5214026 | DRIVING WHEEL |
| 87 | 0155149 | THICKNESS WASHER |
| 88 | 5130795 | WHEEL SUPPORT |
| 90 | 0606204 | BALL BEARING |
| 92 | 0894007 | LIGHT PILOT |
| 93 | 7213006 | GEAR ASSY |
| 94 | 0150139 | WOODRUFF |
| 95 | 0586200 | BALL BEARING |
| 96 | 5024112 | STATOR FIELD |
| 97 | 7241009 | DOWN FEED HYDRAULIC GROUP |
| 98 | 0606007 | BALL BEARING |
| 99 | 5124054 | SPACER |
| 101 | 7213005 | GEAR ASSY |
| 102 | 0731212 | NEEDLE BEARING |
| 103 | 0124026 | THICKNESS WASHER |
| 104 | 7213004 | GEAR ASSY |
| 105 | 5850006 | CARBON BRUSHE HOLDER |
| 106 | 5154501 | CABLE LOCKING DEVICE |
| 108 | 0181021 | WOODRUFF |
| 110 | 5182823 | SWITCH BOX |
| 111 | 0181018 | WOODRUFF |
| 112 | 5182843 | MOTOR COVER |
| 113 | 5850111 | FAN WITH MAGNETIC RING |
| 115 | 5182525 | COVER |
| 117 | 7801611 | MOTOR |
| 119 | 0816005 | NOISE SUPPRESSOR |
| 120 | 5061041 | RUBBER BUSHING |
| 121 | 7013134 | ROTOR |
| 122 | 0241443 | PIPE FITTING |
| 124 | 0802611 | SWITCH SINGLE PHASE 8A |
| 132 | 5181858 | BLADE PROTECTION |
| 133 | 0123315 | RUBBER WASHER |
| 134 | 1855803 | COOLING LIQUID PIPE |
| 135 | 5181688 | CABLE PROTECTION |
| 138 | 5152596 | PROTECTION FIXING DEVICE |
| 139 | 7130567 | INNER BEARING ASS'Y |
| 141 | 7820118 | ELECTRONIC CARD |
| 142 | 7130740 | HANDLE GRIP WITH STOP BUTTON ASS'Y |
| 143 | 0806029 | EMERGENCY BUTTON |
| 144 | 5124091 | RUBBER WASHER |
| 145 | 0241367 | PIPE FITTING |
| 148 | 5154103 | CABLE LOCKING DEVICE |
| 151 | 0241366 | PIPE FITTING |
| 152 | 1855805 | COOLING LIQUID PIPE |
| 153 | 0600607 | BALL BEARING |
| 154 | 5181627 | PROTECTION |
| 156 | 5130747 | SUPPORT |
| 3280025 | PACKAGE N°5 BLADE 19x0,9x2140 Z8/12 | |
| 3280024 | PACKAGE N°1 BLADE 19x0,9x2140 Z8/12 | |
| 157 | UNI 5931 M8x30 | |
| 158 | 5181628 | PROTECTION AND OUTER FELT HOLDER |
| 159 | 5181683 | SLIDING PROTECTION SX BLACK SEMIL. SMOOTH |
| 160 | 0147002 | SNAP LEVER-ART.522-83-M10 |
| 161 | 0124029 | FLAT WASHER D.10X24 THICKNESS 3 ZN |
| 162 | 0063025 | DISTANCE FE D.6X10X H.10 SINT C11 VAPOR. |
| 163 | 5100069 | BEARING ADJUSTMENT SCREW FOR 791 |
| 164 | 5130942 | MOVABLE BLADE GUIDE |
| 165 | 0124027 | WASHER THICKNESS PS 6X12 THICK.1 |
| 166 | UNI 5931 M6x25 | |
| 167 | 0600626 | BEARING 626 6x19x 6 2RS |
| 168 | 5130943 | BLADE GUIDE SUPPORT |
| 169 | 5100070 | BEARING ADJUSTMENT SCREW FOR 791 |
| 170 | 0600607 | BEARING 607 7x19x 6 2RS |
| 171 | 5120638 | SPACER FOR BEARING D.6X12 H.1,5 |
| 172 | UNI 1751 Ø6 | |
| 173 | UNI 5721 M6 | |
| 174 | 0241442 | TERMINAL FITTING - ART.GES 6 / M10X1 |
| 175 | UNI 5732 M10x40 | |
| 176 | 0241442 | TERMINAL FITTING - ART.GES 6 / M10X1 |
| 177 | UNI 5721 M6 | |
| 178 | UNI 1751 Ø6 | |
| 179 | 5120638 | SPACER FOR BEARING D.6X12 H.1,5 |
| 180 | 5133772 | RIGHT UPRIGHT BLACK SEM.BUCC. |
| 181 | 5133773 | LEFT UPRIGHT BLACK SEM.BUCC. |
| 182 | 7820154 | DIGITAL ELECTRONIC REGULATOR 2200 - 115/230 V - 50/60 HZ |
| 183 | 5140071 | REGULATOR KNOB |
| 184 | 5142114 | PANEL ON-OFF LEVER |
| 185 | 5138098 | CONTROL SUPPORT |
| 186 | 5050156 | ON-OFF LEVER HOOK |
| 187 | 0801216 | END-RUN MICROSWITCH |
