Bosch Spare Parts for Demolition Hammer SDS-Max GSH 16-30

€2.16
Tax included

Bosch Spare Parts for Demolition Hammer SDS-Max GSH 16-30

Bosch original spare parts for to replace broken parts for to fix Demolition Hammer GSH 16-30 - 3611C35100.

Fix Your Demolition Hammer GSH 16-30. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

Bosch GSH 16-30 - 3611C35100
ITEM CODE: 1600210005
Quantity
Usually Ships in: 10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Bosch Spare Parts for Demolition Hammer SDS-Max GSH 16-30

Fix Your Demolition Hammer GSH 16-30 - 3611C35100. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Demolition Hammer and the respective parts of the code.
Bosch GSH 16-30 - 3611C35100

Demolition Hammer GSH 16-30/3 611 C35 100
# Part Num. Description
2 160422052M Field 220-240V
3 1614011117 Armature 230-240V
4 1607200244 Switch
6 1610703053 Grommet Ø9,7-Ø12x89 MM
7 1601302018 Fastening Clamp
15 1616610102 Fan
25 1610300070 Guide Ring
28 1614614006 Compression Spring
29 1614614007 Compression Spring
33 1611006008 Holding Plate
34 1610102635 Supporting Disc
37 1615500380 Fan Cover
42 1614336078 Brush Holder
42/2 1614336017 Brush Guide
42/3 1614652007 Spiral Spring
42/6 1611390005 Connector
42/8 2912401412 Tapping Screw
43 1610508054 Spacer
46 1615106053 Motor Housing
47 1618000028 Base Plate
48 1615500383 Housing Cover
53 1610190058 Stop Disc
55 1610506019 Control Bushing
56/58 1610500023 Retaining snap ring
56/71 1613101012 Piston Pin
60 1616317086 Cylindrical Gear
61 1616317093 Cylindrical Gear
72 1616110037 Eccentric Shaft
73 1600A0014G Needle bearing
75/74 1613060049 Splined coupling
75/76 1618045022 Strap-Shaped Handle
75/77 1615805069 Bearing Pedestal
75/79 1613060050 Toothed Shaft
75/80 1615500376 Bearing cover
75/81 1615500377 Bearing cover
75/173 1613490008 Torx Oval-Head Screw 6x20
75/174 1613490009 Torx Oval-Head Screw 6x40
75/183 2916280013 Supporting Disc S15x21x1,5 DIN988
75/184 1613349021 Hex Nut
84 1612025070 Carrying Handle
86 2911011270 Hex Screw DIN 931-M8x130-8.8
87 1611316034 Clamping Band
88 1613349017 Star Knob M8 BLACK
95 1614448038 Connecting Cable
118 1610520003 Spacer Tube
119 1610913020 Needle-Roller Assembly
120 1610910092 Needle-Roller Bearing D25xD37x17
123 1610900030 Deep-Groove Ball Bearing 20x47x14
126 2603490023 Torx Oval-Head Screw 4x20
128 2916660021 Spring retaining ring 47x1,75MM, DIN 472
138 1611015059 Sealing Frame
139 1610508050 Plug
157 1610210192 O-Ring
158 1610210191 O-Ring
159 1600210005 O-Ring 66,0x3,0 MM
161 1610290118 Damping Ring
164 1610210194 O-Ring
165 1610210195 O-Ring
169 1613414022 Hex Socket Head Cap Screw
170 1613414023 Hex Socket Head Cap Screw
171 1613490010 Torx Oval-Head Screw M6x20
172 1613490011 Torx Oval-Head Screw M6x50
176 1603435036 Tapping Screw 4,8x78 MM, TORX T-20
180 1613490007 Clamp Screw
181 2912401420 Tapping Screw DIN7981-ST3,9x19-F-Z
183 1613349020 Hex Nut
190 1614503007 Suppression Filter
195 1611110D43 Sticker
661 1615430010 Grease Tube 30 ML
805 1617000723 Power supply cord
808 1601106032 Nameplate 26x52 MM
810 1617014143 Carbon-Brush Set
813 1617000480 Bearing
814 1617000481 Bearing
818 1617000482 Brush-Cover
819 1617000483 Brush-Cover
820 1617000722 Toolholder
821 1617000721 Locking Bolt Set
831 1617000A4Z Plain Washer
835 1617000709 Guide Tube
839 1617000489 Gear Cover
840 1617000490 Gear Housing
841 1617000491 Striker Pin
844 1617000492 Hammer Pipe
845 1617000710 Sealing cap
854 1617000740 Spacer Tube
856 1607000C3N Hammer Piston
857 1617000495 Striker
870 1607000C3P Connecting Rod
875 1617000496 Rubber Torsion-Bar
884 1617000A55 Handle Enclose in cod 160202508k
890 1617000716 Wheel Set
891 1617000715 Lock
892 1607000C3M Hammer Piston
895 1617000702 Wear and Tear Part Set
896 1617000497 Wear and Tear Part Set
897 1615430016 Lubricating Grease 1000 ML
898 1615430015 Grease Tube 225 ML
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
