Bosch Spare Parts for Demolition Hammer GSH 5 E - 0611318703
€57.08
Tax included
Bosch Spare Parts for Demolition Hammer GSH 5 E - 0611318703
Bosch Genuine spare parts or replacement parts for to repair Demolition Hammer GSH 5 E /230 V/EU - 0611318703.Fix Your Demolition Hammer GSH 5 E - 0611318703. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Demolition Hammer GSH 5 E - 0611318703
Fix Your Demolition Hammer GSH 5 E - 0611318703. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Demolition Hammer and the respective parts of the code.
| Demolition Hammer GSH 5 E /230 V/EU 0611318703 | ||
| # | Part Num. | Description |
| 1 | 1615102155 | Motor Housing BLUE |
| 2 | 1614220123 | Field 220-240V |
| 4 | 1617200095 | Switch |
| 6 | 1600703035 | Grommet Ø8,7-Ø9,6x66 MM |
| 7 | 1601302018 | Fastening Clamp |
| 9 | 1611110C41 | Manufacturer's nameplate |
| 13 | 1610900026 | groove ball bearing 8x24x8 |
| 14 | 1610905028 | groove ball bearing 12x32x10 |
| 15 | 1616610090 | Fan |
| 16 | 1610499055 | Ratchet Sleeve |
| 17 | 1610241000 | Catch Disk |
| 18 | 1614601030 | Retaining ring |
| 21 | 1610508038 | Protective Cap |
| 22 | 1610591030 | Protection Sleeve |
| 23 | 1610520001 | Stop Sleeve |
| 25 | 1612300036 | Stopping Device |
| 26 | 1610290076 | Indexing Disk |
| 27 | 1610591028 | Air-Deflector Ring |
| 28 | 1614621000 | Compression Spring |
| 31 | 1610290049 | Damping Ring |
| 34 | 1610516013 | Flange |
| 37 | 1615500321 | Bearing Pedestal BLUE |
| 38 | 1615190105 | Covering hood BLUE |
| 42 | 1614336046 | Brush Holder |
| 43 | 1615500410 | Fan Cover BLACK |
| 53 | 1610102054 | Support Disc |
| 57 | 1618710073 | Striker |
| 69 | 1610099005 | Retaining Bracket |
| 72 | 1616317062 | Eccentric Cog Wheel |
| 73 | 1615500360 | Housing Cover |
| 75 | 1615132087 | Handle BLUE |
| 80 | 1617233037 | Speed governor 220-240V |
| 81 | 1615132088 | Handle Cover BLACK |
| 84 | 160202508D | Auxiliary Handle |
| 86 | 2911021267 | Hex Screw |
| 87 | 1611316022 | Clamping Band |
| 88 | 1613349017 | Star Knob M8 BLACK |
| 89 | 1600A00748 | Clamping Piece |
| 95 | 1610210173 | O-Ring 32,0x1,5 MM |
| 104 | 1610210095 | O-Ring 55,0x2,0 MM |
| 111 | 1610290064 | Bushing |
| 112 | 1613300008 | Hex Nut DIN 936-M8x1-8 |
| 113 | 1613435009 | Tapping Screw ST-4,8x57,5-TORX,T20 |
| 116 | 1610311017 | Inner Ring |
| 121 | 1610328018 | Bushing |
| 126 | 2910211019 | Tapping Screw DIN 7971-ST3,9x16-F |
| 138 | 1611015050 | Sealing Frame |
| 141 | 1610290066 | Rotary shaft lip seal |
| 142 | 1610290061 | Rotary shaft lip seal |
| 143 | 1614601021 | Retaining ring DIN 7993-28x2 |
| 144 | 1610251006 | Supporting Disc |
| 145 | 1610119012 | Spring retaining ring |
| 150 | 1614601041 | Retaining ring |
| 154 | 2916660024 | Spring retaining ring 55x2MM, DIN 472 |
| 160 | 1610210172 | Damping Ring |
| 162 | 1610210091 | O-Ring 24,0x4,0 MM |
| 163 | 1610290065 | Seal Ring |
| 164 | 1610210144 | O-Ring 22,0x3,0 MM |
| 165 | 1610210153 | O-Ring 25,0x4,0 MM |
| 167 | 1610290062 | Rotary shaft lip seal |
| 171 | 1613435014 | Torx Oval-Head Screw M5x16-TORX,T25 SILVER |
| 172 | 1613435013 | Torx Oval-Head Screw M6x30-TORX,T30 SILVER |
| 174 | 1613435012 | Torx Oval-Head Screw M4,8x25-TORX,T25 SILVER |
| 175 | 2912401018 | Tapping Screw DIN7981-ST3,9x13-C-Z |
| 176 | 1613435012 | Torx Oval-Head Screw M4,8x25-TORX,T25 SILVER |
| 177 | 1603435051 | Tapping Screw ST3,9x32 SILVER |
| 195 | 1613435020 | Torx Oval-Head Screw |
| 200 | 1610284000 | Bellows |
| 203 | 1610322009 | Support Disc SILVER |
| 661 | 1615430010 | Grease Tube 30 ML |
| 691 | 16054381CC | Carrying Case |
| 803 | 1614011098 | Armature 220-240V |
| 805 | 1617000723 | Power supply cord |
| 806 | 3604477009 | End Splice |
| 808 | 160111A3H5 | Nameplate |
| 811 | 1617014144 | Carbon-Brush Set |
| 1607000492 | Carbon-Brush Set 10 x 1 617 014 144 | |
| 815 | 1609271281 | Socket head cap screw |
| 817 | 1614652004 | Spiral Spring |
| 818 | 2910011082 | Socket head cap screw DIN 84-AM3,5x6-5.8 |
| 821 | 1617000835 | Bushing |
| 835 | 1617000432 | Hammer Pipe |
| 840 | 1617000837 | Impact Mechanism Housing - DISCONTINUED |
| 841 | 1617000452 | Striker Pin |
| 854 | 1617000442 | Stop Disc |
| 856 | 1617000836 | Hammer Piston |
| 874 | 1617000422 | Holding-Down-Appliance |
| 883 | 1615132109 | Auxiliary Handle |
| 884 | 1602025097 | Auxiliary Handle |
| 885 | 1610190053 | Catch Disk |
| 886 | 2911011270 | Hex Screw DIN 931-M8x130-8.8 |
| 889 | 1618040084 | Clamping Piece |
| 890 | 1609244B42 | Mounting Sleeve |
| 891 | 1617000853 | Spring Pack |
| 892 | 1609244B43 | Bow |
| 895 | 1615430019 | Oil Reservoir 1000 ML |
| 897 | 1617000431 | Wear and Tear Part Set |
| 898 | 1615437512 | Oil Reservoir 50 ML |
