Bosch Spare Parts for Table Saw GTS 18V-216
€1.41
Tax included
Bosch Spare Parts for Table Saw GTS 18V-216
We are BOSCH original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Table Saw GTS 18V-216 - 3601M44000 - 18 V/EU.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Table Saw GTS 18V-216
We are BOSCH original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Table Saw GTS 18V-216 - 3601M44000 - 18 V/EU - Biturbo Brushless.In the following table, look for the model of the Bench Saw and the respective parts of the code.
| Table Saw GTS 18V-216 - 3601M44000 - 18 V/EU | ||
| # | Part Num. | Description |
| 27 | 1609B01281 | Screw |
| 60 | 1609B06706 | Battery Holder |
| 67 | 1609B06200 | Contact retainer |
| 75 | 2609110353 | Torx Oval-Head Screw |
| 77 | 1609280477 | Compression Spring |
| 85 | 1609BP7039 | Self-locking nut |
| 97 | 1609B06705 | Mounting Bracket |
| 98 | 1609B04541 | Screw |
| 99 | 1609B01186 | Bushing |
| 100 | 1609B01196 | Socket head cap screw |
| 128 | 1609B04562 | Set screw |
| 158 | 1609B01282 | Screw |
| 163 | 1609B03874 | Body |
| 167 | 1609B06699 | Table top |
| 171 | 1609B06218 | Pointer |
| 172 | 1609B03959 | Extension unit |
| 173 | 1609B03960 | Rail |
| 174 | 1609B03961 | Rail |
| 175 | 1609B03963 | Plate |
| 176 | 1609B06801 | Rail |
| 177 | 1609B06802 | Rail |
| 178 | 1609B02751 | Screw |
| 179 | 1609B06382 | Cover |
| 180 | 1609B00627 | Screw |
| 181 | 1609B02181 | Washer |
| 182 | 1609B06400 | Cover |
| 183 | 1609B03990 | Shoulder Screw |
| 184 | 1609B01322 | Flange Bolt |
| 185 | 1609B03886 | Scale |
| 186 | 1609B06589 | Shoulder Screw |
| 187 | 1609B03964 | Mounting Bracket |
| 188 | 1609B03965 | Handle Bar |
| 189 | 1609B03966 | Cam |
| 190 | 1609B03967 | Link Piece |
| 191 | 1609B03968 | Link Piece |
| 192 | 1609B03969 | Nut |
| 193 | 1609B03970 | Pin |
| 194 | 1609B03971 | Bar |
| 195 | 1609B03972 | Spring Plate |
| 196 | 1609B03973 | Clamping Lever |
| 197 | 1609B03974 | Rivet |
| 199 | 1609B01992 | End Clip |
| 200 | 1609B00647 | Screw |
| 201 | 1609B03976 | Compression Spring |
| 202 | 1609B03975 | Flange nut |
| 203 | 1609B06406 | Flange nut |
| 204 | 1609B03993 | Bracket |
| 205 | 1609B00670 | Washer |
| 224 | 1609B01253 | Plain Washer |
| 225 | 1609BP7138 | Tapping Screw |
| 822 | 1609B04590 | Guide |
| 823 | 1609B06781 | Upper guard |
| 825 | 1609B06423 | Mitre Fence |
| 864 | 1609B06424 | Fastening parts kit |
| 868 | 1609B06415 | Fixing Plate |
| 887 | 1609B05715 | Pad |
| 888 | 1609B05657 | Clamping Unit |
| Table Saw GTS 18V-216 | 3 601 M44 000 | 18 V / EU | ||
| 2 | 160702267K | Brushless DC motor |
| 19 | 1609B00655 | Screw |
| 21 | 1609B06685 | Motor Jacket |
| 26 | 1609B06265 | Ribbon cable |
| 28 | 16072335GB | Electronic Module |
| 29 | 1609B06697 | Plate |
| 30 | 1609B03361 | Screw |
| 31 | 1609B06223 | Cover |
| 32 | 1609B06686 | Cover |
| 33 | 1609B06698 | Cover |
| 34 | 1609B06352 | Rubber Clamp |
| 38 | 1609B03947 | Output Shaft |
| 39 | 1609B06362 | Helical Gear |
| 40 | 1609B03944 | Gear Cover |
| 41 | 1609B01050 | Screw |
| 42 | 1609B06547 | Bearing |
| 43 | 1609B03948 | Bearing cover |
| 44 | 1609B06785 | Locking Lever |
| 45 | 1609B03937 | Torsion Spring |
| 46 | 1609B03923 | Shoulder Screw |
| 47 | 1609B03929 | Adjusting Screw |
| 48 | 1609BT4033 | Nut |
| 49 | 1609B03913 | Inner Disc |
| 50 | 1609B06217 | Cable |
| 51 | 1609B03915 | Flange |
| 52 | 1609B03916 | Nut |
| 53 | 1609B05720 | Guard Plate |
| 54 | 1609B01690 | Screw |
| 56 | 1609B06694 | Bellows |
| 59 | 1609B00637 | Tapping Screw |
| 242 | 1609B04626 | Retaining ring |
| 261 | 1609B06807 | Screw |
| 828 | 1609B06782 | Riving Knife |
| 835 | 1609B06214 | Gear Box |
| Table Saw GTS 18V-216 | 3 601 M44 000 | 18 V / EU | ||
| 4 | 2607202394 | Switch |
| 8 | 1609BN0407 | Nameplate |
| 18 | 1609B06380 | Screw |
| 23 | 1609B06340 | Switch Cover |
| 24 | 1609B06341 | Switch Cover |
| 25 | 1609B06333 | Switch Box |
| 55 | 1609B06687 | Bracket Support |
| 57 | 1609B06688 | Cover |
| 58 | 1609B06707 | Cover |
| 95 | 1609B04551 | Stopper |
| 96 | 1609B06561 | Screw |
| 103 | 1609B06708 | Cover |
| 105 | 1609B01046 | Plastic-Cutting Screw |
| 141 | 1609B06711 | Label |
| 169 | 1609B06422 | Spring Plate |
| 206 | 1609B03983 | Base |
| 207 | 1609B03979 | Front Plate |
| 208 | 1609B03984 | Tube |
| 209 | 1609B03985 | Bottom Plate |
| 210 | 1609B03986 | Foot Cover |
| 211 | 1609B03988 | Cover |
| 212 | 1609B03995 | Spring Plate |
| 213 | 1609B06702 | Handle |
| 214 | 1609B01243 | Screw |
| 215 | 1609B03981 | Bracket |
| 216 | 1609BP7098 | Rubber Ring |
| 217 | 1609B06378 | Plate |
| 218 | 1609B06405 | Screw |
| 220 | 1609B03994 | Bracket |
| 221 | 1609B06413 | Bracket |
| 222 | 1609B00969 | Screw and washer assembly |
| 223 | 1609B04082 | Rivet |
| 229 | 1609B00636 | Tapping Screw |
| 231 | 1609B06383 | Bushing |
| 232 | 1609B06385 | Screw |
| 234 | 1609B06410 | Workpiece Pusher |
| 235 | 1609B06384 | Wrench Attachment |
| 236 | 1609B03891 | Wrench Attachment |
| 237 | 1609B06421 | Knob |
| 238 | 1609B05286 | Clip |
| 241 | 1609B06715 | Label |
| 246 | 1609B06560 | Screw |
| Table Saw GTS 18V-216 | 3 601 M44 000 | 18 V / EU | ||
| 61 | 1609B04525 | Drive Shaft |
| 62 | 1609B00675 | Washer |
| 63 | 1609B05390 | Hex Socket Head Cap Screw |
| 64 | 1609B06704 | Screw Bar |
| 65 | 1609B04522 | Support Plate |
| 66 | 1609B06220 | Pointer |
| 68 | 1609B00650 | Screw |
| 69 | 1609B04253 | Belt |
| 70 | 1609B01287 | Retaining clip |
| 71 | 1609B04524 | Bushing |
| 72 | 1609B04520 | Gear |
| 73 | 1609B00624 | Screw |
| 74 | 1609B04519 | Guide Bar |
| 78 | 1609B06808 | Washer |
| 79 | 1609B04528 | Hand Wheel |
| 80 | 1619P03825 | Screw and washer assembly M5x16 |
| 81 | 1609B00757 | Plain Washer |
| 82 | 1609B04529 | Crank |
| 83 | 1609B00689 | Screw |
| 84 | 1609B06368 | Screw |
| 86 | 1609B03863 | Dust Cleaner |
| 87 | 1609B06718 | Lower guard |
| 88 | 1609B04530 | Supporting Sleeve |
| 91 | 1609B04531 | Compression Spring |
| 92 | 1609B04517 | Carriage |
| 93 | 1609B04560 | Screw |
| 94 | 1609B03829 | Special Washer |
| 101 | 1609B06363 | Dust Extraction |
| 109 | 1609B06689 | Mounting Plate |
| 112 | 1609B06809 | Washer |
| 113 | 1609B06690 | Mounting Plate |
| 114 | 1609B06691 | Dust-Cover Holder |
| 243 | 1609B00644 | Retaining ring |
| 247 | 1609B00631 | Screw |
| 651 | 1609B06703 | Dust Bag |
| 876 | 1609B05713 | Locking Lever |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
