Femi Spare Parts for Mitre Saws 732 - 8420023
€22.87
Tax included
Femi Spare Parts for Mitre Saws 732 - 8420023
Femi original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of Mitre Saw 732 - 8420023.Fix Your Mitre Saw 732. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Mitre Saws 732 - 8420023
Fix Your Mitre Saw 732 - 8420023. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Mitre Saws and the respective parts of the code.
| Mitre Saw for Wood 732-8420023 | ||
| # | Part Num. | Description |
| 1 | 5181782 | UPPER PROTECTION GROUP |
| 2 | 5130462 | UPPER WORKING TABLE |
| 3 | 7130629 | UPPER REST GROUP |
| 4 | 5871074 | CABLE |
| 5 | 5850113 | CARBON BRUSHE SET |
| 6 | 5182563 | MOTOR COVER |
| 8 | 7801829 | MOTOR ASS'Y |
| 12 | 5159012 | SCREW CAP |
| 13 | 5182884 | MOTOR HOUSING |
| 16 | 0526200 | BALL BEARING |
| 17 | 5024119 | STATOR |
| 18 | 5050140 | HANDLE |
| 19 | 0802622 | SWITCH |
| 20 | 7820124 | ELECTRONIC CARD = 7075046 |
| 21 | 5050139 | HANDLE |
| 24 | 5153504 | CABLE LOCKING DEVICE |
| 25 | 5221021 | RUBBER GASKET |
| 27 | 5181003 | RUBBER PROTECTION |
| 28 | 7130622 | TRANSMISSION GROUP |
| 29 | 5182562 | BOX COVER |
| 30 | 5181784 | PROTECTION GROUP |
| 31 | 5100336 | SCREW |
| 32 | 5190308 | BLADE FLANGE |
| 34 | 7013148 | ROTOR - ARMATURE |
| 35 | 5182883 | ELECTRIC BOX |
| 37 | 3278539 | WOOD DISC D254x2.5 F30 Z 24 |
| 37 | 3278540 | WOOD DISC D254x2.5 F30 Z 40 |
| 39 | 5120672 | SPACER |
| 40 | 0107012 | WING NUT |
| 41 | 5130883 | TABLE GUIDE |
| 42 | 5181781 | LOWER PROTECTION |
| 45 | 5120673 | SPACER |
| 46 | 0221106 | O-RING SEAL |
| 47 | 5171072 | LOCKING PIN |
| 48 | 5182886 | FAN COVER |
| 49 | 0526201 | BALL BEARING |
| 50 | 0106116 | RING NUT |
| 51 | 5124085 | WASHER |
| 52 | 5170003 | LOCKING PIN |
| 53 | 5080163 | SPRING |
| 54 | 5042813 | MITRE SAW ARM |
| 55 | 5190309 | BLADE FLANGE |
| 57 | 0151409 | SNAP RING |
| 60 | 5080160 | SPRING |
| 63 | 5183084 | RIVING KNIFE |
| 64 | 5130882 | TABLE GUIDE |
| 65 | 7130621 | LEVER AND PROTECTION GROUP |
| 67 | 5182882 | ARM COVER |
| 69 | 5080162 | SPRING |
| 70 | 0107013 | WING NUT |
| 71 | 5100337 | SCREW |
| 72 | 7130625 | TRANSMISSION GROUP |
| 74 | 5171073 | PIVOT PIN |
| 75 | 5124084 | WASHER |
| 76 | 7130630 | JOINT-SHAFT GROUP |
| 77 | 5181780 | LOWER PROTECTION |
| 78 | 5159013 | SCREW CAP |
| 79 | 5080161 | SPRING |
| 80 | 5130880 | BASE |
| 82 | 5100339 | SCREW |
| 87 | 5181783 | BLADE PROTECTION |
| 88 | 5081029 | SPRING |
| 89 | 5137982 | SPRING SUPPORT |
| 90 | 0147019 | HAND LEVER |
| 91 | 5120674 | SPACER |
| 92 | 5100338 | SCREW |
| 93 | 7130626 | ROD STOP GROUP |
| 94 | 0142002 | WOOD PUSHING DEVICE |
| 96 | 5171074 | SUPPORT PIN |
| 98 | 5137979 | SWIVEL SUPPORT |
| 99 | 5130881 | JOINT SUPPORT |
| 102 | 5140056 | KNOB |
| 104 | 5137980 | RUBBER FOOT |
| 105 | 5133720 | BASE |
| 106 | 5159519 | INDEX |
| 108 | 5170537 | LOCKING PIN |
| 109 | 5402228 | GRADUATE PLATE |
| 180 | 5850009 | BRUSH HOLDER TR240-732-999 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi 732 - 8420023
10 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM CODE OR S/N FEMI:
- FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
