Annovi & Reverberi Parts for Pressure Washer AR925/945
search
  • Annovi & Reverberi Parts for Pressure Washer AR925/945
  • Annovi & Reverberi Parts for Pressure Washer AR925/945

Annovi & Reverberi Parts for Pressure Washer AR945

€30.06
Tax included

Annovi & Reverberi Parts for Pressure Washer AR 945

Annovi & Reverberi genuine replacement parts for to replace broken parts for to fix Pressure Washer Blue Clean AR 945 - 22324.

IDENTIFICAZIONE - ANNOVI-3.jpg
ITEM CODE: 1864
Quantity
on 10/15 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Annovi & Reverberi Parts for Pressure Washer AR945

Annovi & Reverberi genuine replacement parts for to replace broken parts for to fix Pressure Washer Blue Clean AR 945 - 22324.

In the following tables, look for the spare part and its respective code.
Annovi & Reverberi Parts for Pressure Washer AR945

Casing 945 Pag.1
1 2360637 Blue Casing
2 2360020 Handle
3 2360360 Screw
4 2360300 Stopper
5 2360090 Hook
6 2360170 Stopper
7 2360100 Support
8 2100300 Screw
9 2360270 Knob
10 2000110 Screw
11 2360040 Black Hood
12 2360370 Gasket
13 2360340 Colonnetta
14 2360050 Plate
15 380240 Nut
16 1680930 Stopper
17 2360010 Basis
18 2360560 Axle
19 2360571 Wheel
20 380620 Washer
21 1470220 Screw
22 1682420 Stopper
23 2000240 O-Ring
24 2000230 Filter
25 1270960 Pipe Cleaner
26 2360110 Clamp
27 2100300 Screw
28 850250 Screw
29 1270910 Stopper
30 2360760 Knob
31 2360670 Colonnetta
33 2360780 Antivibration
Pump 945 Pag.2
1 960160 O-Ring
2 1260162 Stopper
3 1269050 Complete Valve
4 880830 O-Ring
5 620301 Stopper
6 1780140 Ring
7 1260220 Tenuta Water
8 1780110 Piston Guide
9 1780010 Pump Housing
10 1266740 Oil Seal
11 1260790 Ring
12 1780550 Ring
13 1780490 Bearing
14 880130 Stopper
15 1780050 Plug
16 1780510 O-Ring
17 1200430 Screw
18 1789010 Cover
19 1780040 Piston Rod
20 1780060 Piston
21 480480 O-Ring
22 1260091 Disk
23 1780080 Piston
24 1260100 Washer
25 1260110 Nut
27 740290 O-Ring
28 1980740 Stopper
30 1260460 Oil Seal
31 1780120 Piston Guide
32 770260 O-Ring
33 1260450 Tenuta Water
34 820361 Stopper
35 180101 O-Ring
36 1780020 Head
37 1381550 Washer
38 1322730 Screw
40 1321190 Bearing
41 1321080 Ring
44 180030 Screw
45 1780180 Tree
46 1380520 Tongue
47 1260750 Ring
57 1789202 Pre-Assembly Head
58 3232 Manometer
59 7906 Pre-Assembly Pump
A 1864 Kit Valves
B 2746 Piston Kit
C 2786 Kit Oil Seals
E 2747 Kit Kept Water
G 2745 Kit Support Rings
Valve 945 Pag.3
2 392840 Screw
3 1980300 Nut
4 2500540 Insert
5 1980220 Disk
6 1271070 Spring
7 1080041 Piston
8 1080070 Plug
9 1080401 Ring
10 1080250 O-Ring
11 2500550 Cotter Pin
12 1980210 Piston Guide
13 740290 O-Ring
14 800560 O-Ring
15 880830 O-Ring
16 1271170 Ring
17 1080190 O-Ring
18 1271160 Piston
19 2460420 Office
20 1080250 O-Ring
21 1540272 Screw
22 390080 O-Ring
23 1540660 Valve Body
24 1140450 O-Ring
25 1460430 O-Ring
26 1540170 Shutter
27 1080091 Spring
28 394280 O-Ring
29 1560660 Ring
30 2360650 Knob
31 480560 O-Ring
32 800560 O-Ring
34 1560650 Hose
35 480480 O-Ring
36 1250280 Sphere
37 1560520 Spring
38 1540580 Junction
39 1540300 Nut
41 1540280 Collector
42 1540630 O-Ring
44 880270 O-Ring
45 2260420 Screw
46 480440 O-Ring
47 1560900 Junction
48 40393 Junction
50 1340260 Filter
52 1981190 Screw
53 1260820 O-Ring
54 1540881 Piston
55 1981320 Spring
56 2022201 Fork
57 2029758 Pre-Assembly Box TSS
58 660190 O-Ring
59 880840 O-Ring
60 1540870 Stopper
61 22078 Complete Valve
62 1123960 Junction
63 1569210 Pre-Assembly IDR
64 1120681 O-Ring
65 42458 Kit TSS
66 1080192 O-Ring
F 42451 Gasket Kit
Engine 945 Pag.4
1 1700110 O-Ring
2 1700080 Plate
3 1940410 O-Ring
4 1700740 Mini-Contactor
5 1261570 Screw
6 2360590 Card
7 1460460 Screw
8 1700590 Nut
9 2180650 Cable
10 1700930 Cover
11 2360730 Switch
12 880270 O-Ring
13 1382380 Gland
14 1261560 Screw
15 1080190 O-Ring
16 1700640 Cable
17 44121 Engine
18 1341140 Gasket
Accessories 945 Pag.5
1 40925 Gun
2 40115 Lancia + Head
3 3095 Nozzle
4 40541 Lancia + Head Without Nozzle
5 40958 Lancia + Head
6 2000770 O-Ring
7 1271960 High Pressure Hose

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Annovi Reverberi AR 945 22324
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
New

Download

Diagram Annovi & Reverberi AR945

Diagram Annovi & Reverberi AR945

Download (752.42KB)
