Annovi & Reverberi Parts for Pressure Washer AR1330
€11.93
Tax included
Annovi & Reverberi Parts for Pressure Washer AR1330
We are Annovi & Reverberi original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer Blue Clean AR1330 - 23655.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi & Reverberi Parts for Pressure Washer AR1330
We are Annovi & Reverberi original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer Blue Clean AR1330 - 23655.
In the following tables, look for the spare part and its respective code.
| Pressure Washer Blue Clean 1330 - 23655 | ||
| Casing 1330 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 50611 | Stopper |
| 2 | 51421 | Tank |
| 3 | 51443 | Stopper |
| 4 | 50601 | Seal |
| 5 | 51429 | Hood |
| 6 | 50628 | Protection |
| 7 | 50627 | Wheel |
| 8 | 51417 | Frame |
| 9 | 51420 | Porta-Accessories |
| Pump 1330 Pag.2 |
||
| 1 | 680570 | Screw |
| 2 | 1381550 | Washer |
| 3 | 1260250 | Level Indicator |
| 4 | 1260430 | Ring |
| 5 | 1780690 | Disk |
| 6 | 1140450 | O-Ring |
| 7 | 1260162 | Stopper |
| 8 | 960160 | O-Ring |
| 9 | 1269050 | Complete Valve |
| 10 | 880830 | O-Ring |
| 11 | 1320340 | Ring |
| 12 | 1780720 | Watertight |
| 13 | 1320351 | Piston Guide |
| 14 | 1260420 | O-Ring |
| 15 | 1260450 | Watertight |
| 16 | 1260460 | Oil Seal |
| 17 | 1260164 | Stopper |
| 18 | 1266740 | Oil Seal |
| 19 | 1260790 | Ring |
| 20 | 1320370 | Bearing |
| 21 | 1320330 | Bush |
| 22 | 1320010 | Pump Housing |
| 23 | 880130 | Stopper |
| 24 | 1260110 | Nut |
| 25 | 1260100 | Washer |
| 26 | 1260210 | Piston |
| 27 | 480480 | O-Ring |
| 28 | 1260091 | Disk |
| 29 | 1260070 | Piston |
| 30 | 1260080 | Plug |
| 31 | 1260760 | Screw |
| 32 | 1329010 | Cover |
| 33 | 1260040 | Oil Seal |
| 34 | 1320140 | Piston Rod |
| 35 | 740290 | O-Ring |
| 36 | 1980740 | Stopper |
| 37 | 180101 | O-Ring |
| 38 | 820361 | Stopper |
| 39 | 1260190 | Tree |
| 40 | 1380520 | Tongue |
| 41 | 1320020 | Head |
| 42 | 1269222 | Pre-Assembly Head |
| 43 | 1260750 | Ring |
| 44 | 51230 | Condenser |
| 45 | 44272 | Engine |
| 46 | 20566 | Pre-Installing Pump |
| 47 | 50068 | Seal |
| 48 | 1200430 | Screw |
| 49 | 50099 | Box |
| A | 1864 | Kit Valves |
| B | 2629 | Piston Kit |
| C | 1872 | Kit Kept Oil |
| E | 1874 | Kit Held Water |
| Valve 1330 Pag.3 |
||
| 1 | 1980470 | Screw |
| 2 | 1980300 | Nut |
| 3 | 1980390 | Insert |
| 4 | 1980220 | Disk |
| 5 | 1271070 | Spring |
| 6 | 1080041 | Piston |
| 7 | 1080070 | Plug |
| 8 | 1080401 | Ring |
| 9 | 1080250 | O-Ring |
| 10 | 1980210 | Piston Guide |
| 11 | 740290 | O-Ring |
| 12 | 800560 | O-Ring |
| 13 | 880830 | O-Ring |
| 14 | 1271170 | Ring |
| 15 | 1080190 | O-Ring |
| 16 | 1271160 | Piston |
| 17 | 1980200 | Office |
| 18 | 1470210 | O-Ring |
| 19 | 1540272 | Screw |
| 20 | 390080 | O-Ring |
| 21 | 1540510 | Valve Body |
| 22 | 1140450 | O-Ring |
| 23 | 1540630 | O-Ring |
| 24 | 1540280 | Collector |
| 25 | 880270 | O-Ring |
| 26 | 2260420 | Screw |
| 27 | 1460430 | O-Ring |
| 28 | 1540170 | Shutter |
| 29 | 1080091 | Spring |
| 30 | 394280 | O-Ring |
| 31 | 1540300 | Nut |
| 32 | 1540570 | Junction |
| 33 | 1560650 | Hose |
| 34 | 480480 | O-Ring |
| 35 | 1250280 | Sphere |
| 36 | 1560520 | Spring |
| 37 | 23422 | Complete Valve |
| 38 | 800560 | O-Ring |
| 39 | 480560 | O-Ring |
| 40 | 1560680 | Knob |
| 41 | 1560660 | Ring |
| 42 | 1569206 | Pre-Assembly IDR |
| F | 2812 | Seal Kit |
| Water Circuit 1330 Pag.4 |
||
| 1 | 50514 | Washer |
| 2 | 50541 | Washer |
| 3 | 50527 | Nut |
| 4 | 51415 | Tube |
| 5 | 3260310 | High Pressure Hose |
| 6 | 50481 | Junction |
| 7 | 50517 | Washer |
| 8 | 50463 | Junction |
| 9 | 50480 | Junction |
| 10 | 50461 | Junction |
| 11 | 50463 | Junction |
| 12 | 50322 | Thermostat |
| 13 | 50607 | Tube |
| 14 | 1341030 | Filter |
| 15 | 1560600 | Junction |
| 16 | 3000 | Filter |
| 17 | 50488 | Junction |
| 18 | 50466 | Junction |
| 19 | 51416 | Support |
| 20 | 50467 | Junction |
| 21 | 3260110 | Safety Valve |
| 22 | 51425 | Pressure Switch |
| 23 | 51426 | Manometer |
| 24 | 3260510 | Pressure Switch |
| 25 | 50469 | Hose |
| Fuel Circuit 1330 Pag.5 |
||
| 1 | 50751 | Junction |
| 2 | 50468 | Junction |
| 3 | 3160310 | Pump |
| 4 | 3160320 | Solenoid |
| 5 | 3161440 | Cable |
| 6 | 3260050 | Pressure Switch |
| 7 | 3260370 | Connector |
| 8 | 3260380 | Protection |
| 9 | 3160300 | Coupling |
| 10 | 50491 | Hose |
| 11 | 50464 | Junction |
| 12 | 50603 | Tube |
| 13 | 50747 | Filter |
| 14 | 50608 | Tube |
| 15 | 50595 | Stopper |
| 16 | 1341030 | Filter |
| 17 | 50647 | Engine |
| 18 | 50584 | Fan |
| 19 | 50590 | Sump |
| Electric Circuit 1330 Pag.6 |
||
| 1 | 3260120 | Light |
| 2 | 3260140 | Light |
| 3 | 50674 | Switch |
| 4 | 50322 | Thermostat |
| 5 | 51431 | License Plate |
| 6 | 3260130 | Card |
| 7 | 50577 | Fairlead |
| 8 | 1760450 | Cable |
| 9 | 3260440 | O-Ring |
| 10 | 3260450 | Seal |
| 11 | 51428 | Box |
| 12 | 1382060 | Switch |
| 13 | 50577 | Fairlead |
| Boiler 1330 Pag.7 |
||
| 1 | 3260520 | Cable |
| 2 | 50548 | Electrode |
| 3 | 50751 | Junction |
| 4 | 50468 | Junction |
| 5 | 50586 | Cover |
| 6 | 50465 | Junction |
| 7 | 51129 | Nozzle |
| 8 | 50603 | Tube |
| 9 | 50586 | Cover |
| 10 | 50588 | Support |
| 11 | 50593 | Cover |
| 12 | 50589 | Resistance |
| 13 | 50450 | Hook |
| 14 | 3260040 | Transformer |
| 15 | 3260520 | Cable |
| Accessories 1330 Pag.8 |
||
| 1 | 41089 | Gun |
| 2 | 3160160 | High Pressure Hose |
| 3 | 40826 | Lance |
| 4 | 3082 | Nozzle |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
