Annovi & Reverberi Parts for Low Pressure Pump AR 75 LFP C

€0.74
Tax included

Annovi & Reverberi Parts for Low Pressure Pump AR 75 LFP C

Annovi & Reverberi Genuine spare parts or replacement parts for to repair Low Pressure Pump AR 75 LFP C Liquid Fertilizer Proof cod. 33156.
ITEM CODE: 1040060
Quantity
Ship on 10/15 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Annovi & Reverberi Parts for Low Pressure Pump AR 75 LFP C

Annovi & Reverberi Genuine spare parts or replacement parts for to repair Low Pressure Pump AR 75 LFP C Liquid Fertilizer Proof cod. 33156.

In the following tables, look for the spare part and its respective code.
Low Pressure Pump AR 75 LFP C Liquid Fertilizer Proof cod. 33156
Position Code Description Note
1 4800110 Line
2 3120230 Gasket bp model
2 3120680 Gasket Viton   LFP model
3 3129050 Complete valve bp model
3 3129051 Complete valve LFP model
4 550040 O-ring bp model
4 880311 O-ring Viton LFP model
5 651100 Ring nut
6 4800360 Hose tail
7 1140431 Screw Geomet C20 bp m.
7 1140432 Screw Inox C20 LFP mod.
8 390314 Washer Geomet bp model
8 390315 Washer Inox LFP model
9 3120511 Nut Geomet bp model
9 3120510 Nut Inox LFP model
10 4800030 Head
11 4800010 Pump body
12 800862 Screw Geomet C25 bp m.
12 800861 Screw Inox C25 LFP model
13 390314 Washer Geomet bp model
13 390315 Washer Inox LFP model
14 380080 Ring
15 4800040 Connecting-rod
16 380300 Pin
17 4800190 Piston
18 4800200 Piston ring
19 4800210 Sleeve
20 3120082 Diaphragm BlueFlex
21 4800020 Plate
22 3120760 Washer Inox
23 3120100 Hub pin C35 bp model
23 3120101 Hub pin C35 LFP model
24 3120110 Nut C30 bp model
24 3120790 Nut C30 LFP model
25 4800050 Cardan protection
26 4240590 Screw
27 390180 O-ring
28 4700030 Tank
29 380243 Washer Geomet bp model
29 380245 Washer Inox LFP model
30 620611 Screw Geomet C10 bp m.
30 620612 Screw Inox C10 LFP model
31 1040060 O-ring
32 750050 Plug
33 650640 Screw Geomet C50 bp m.
33 650642 Screw Inox C50 LFP mod.
34 4800060 Foot
35 4800130 Line
36 1140450 O-ring bp model
36 1140451 O-ring Viton LFP model
37 3120440 Ring nut
39 3120690 Plug C2
38 3120460 Elbow
41 2440230 O-ring
42 1260790 Ring
43 1320370 Bearing
44 3460090 Ring
45 4800180 Shaft versione C
46 621130 Bearing
47 230380 Ring
48 200390 Ring
50 2840890 O-ring bp model
50 2840891 O-ring Viton LFP model
51 820510 O-ring
52 3460330 Fitting
53 180101 O-ring bp model
53 180102 O-ring Viton LFP model
54 1609000 Safety valve 20 bar
55 550450 Ring nut
56 880831 O-ring Viton
57 550460 Elbow
58 880581 Plug C30
59 4800320 Shaft versione SP
60 2460480 Key (a)
61 680350 Screw C20
62 961340 Washer
63 650300 Coupling
64 4800350 Ring
65 800200 Ring
66 4800011 Pump body C/C model
67 1300050 Ring
68 650250 Key
69 4800330 Shaft versione C/C
Parts Kit
Model Position Quantity
KIT 43080 20 3
Membrane BlueFlex
BlueFlex diaphragms
KIT 42816 2-3 6+6
Valvole / Valves
AR75LFP
KIT 42524 2-3 6+6
Valvole / Valves
AR75bp
KIT 46142 4-27-31-36-41-50-51 1+1+1+1+1+1+1
OR /O-Rings
AR75LFP
KIT 46143 4-27-31-36-41-50-51 1+1+1+1+1+1+1
OR /O-Rings
AR75bp
Service Kit
KIT 46144 - AR75LFP
KIT 46145 - AR75bp
Posizione Quantità
2 6
3 6
4 1
5 1
6 1
20 3
21 3
22 3
23 3
24 3
27 1
28 1
31 1
32 1
36 1
37 1
38 1
41 1
47 1
50 1
51 1

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi&Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi&Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
AR75LFP C - 33156
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS APPROX.
New

Download

Diagram Annovi AR 75 LFP C

Diagram Annovi AR 75 LFP C

Download (341.15KB)
