Annovi & Reverberi Parts for Low Pressure Pump AR 45 LFP
€61.34
Tax included
Annovi & Reverberi Parts for Low Pressure Pump AR 45 LFP
Annovi & Reverberi Genuine spare parts or replacement parts for to repair Low Pressure Pump AR 45 LFP C Liquid Fertilizer Proof cod. 32002.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi & Reverberi Parts for Low Pressure Pump AR 45 LFP
Annovi & Reverberi Genuine spare parts or replacement parts for to repair Low Pressure Pump AR 45 LFP C Liquid Fertilizer Proof cod. 32002.In the following tables, look for the spare part and its respective code.
| Low Pressure Pump AR 45 LFP C Liquid Fertilizer Proof cod. 32002 Pag.1 | |||
| Position | Code | Description | Note |
| 1 | 3120410 | Line | Viton CAR45LFP |
| 2 | 720031 | O-ring | AR45bp |
| 2 | 720030 | O-ring | |
| 3 | 3120050 | Line | |
| 4 | 3120060 | Line | |
| 5 | 3120510 | Nut | Inox |
| 6 | 3120760 | Washer | Inox AR45LFP |
| 6 | 3120761 | Washer | Z/B AR4Sbp |
| 7 | 3120250 | Screw | Inox Go AR4SLFP |
| 7 | 3120251 | Screw | C10 AR45bp |
| 8 | 3120680 | Gasket | Viton AR4SLFP |
| 8 | 3120230 | Gasket | AR45bp |
| 9 | 3129051 | Complete valve | AR45LFP |
| 9 | 3129050 | Complete valve | AR45bp |
| 10 | 621782 | Screw | Inox C10 AR45LFI |
| 10 | 621780 | Screw | C10 OAR45bp |
| 12 | 3040160 | Elbow | |
| 13 | 750670 | Ring nut | |
| 14 | 1880460 | O-ring | Viton b4 AR45LFP |
| 14 | 390290 | O-ring | 4 AR45bp |
| 15 | 3120130 | Piston ring | |
| 16 | 3120090 | Sleeve | |
| 17 | 3120082 | Diaphragm | BlueFlex AR4SLFP |
| 17 | 3120080 | Diaphragm | NBR AR45bp |
| 17 | 3120081 | Diaphragm | Viton |
| 17 | 3120085 | Diaphragm | Desmopan |
| 18 | 3120120 | Plate | |
| 19 | 3120101 | Hub pin | C25 (a) AR4SLFP |
| 19 | 3120100 | Hub pin | C25 (a) AR4Sbp |
| 21 | 3120790 | Nut | C20 AR45LFP |
| 21 | 3120110 | Nut | Inox C20 AR45bp |
| 22 | 3120020 | Head | |
| 25 | 1880450 | Ring | |
| 26 | 3120070 | Piston | |
| 27 | 380300 | Pin | |
| 28 | 3120180 | Connecting-rod | |
| 29 | 1460490 | Ring | |
| 30 | 380230 | Bearing | |
| 31 | 1300120 | Ring | |
| 32 | 3120500 | Shaft | AR4SLFP/bp C |
| 33 | 3120160 | Ring | |
| 34 | 961790 | Ring | |
| 35 | 3240290 | Cardan protection | |
| 36 | 320622 | Washer | Inox AR45LFP |
| 36 | 320620 | Washer | AR45bp |
| 37 | 820672 | Screw | Inox Go AR45LFP |
| 37 | 820670 | Screw | C10 AR45bp |
| 38 | 3120380 | Line | |
| 39 | 3120051 | Line | |
| 40 | 740290 | O-ring | |
| 41 | 3120690 | Plug | C2 |
| 42 | 1140450 | O-ring | Viton AR45LFP |
| 42 | 1140451 | O-ring | AR45bp |
| 44 | 3120440 | Ring nut | |
| 45 | 3120460 | Elbow | |
| 61 | 620342 | Screw | Inox C30 AR45LFP |
| 61 | 620340 | Screw | C30 AR45bp |
| 62 | 3120140 | Foot | |
| 63 | 880530 | Plug | C20 |
| 64 | 3120010 | Pump body | |
| 65 | 3120240 | Tank | C20 |
| 66 | 650920 | O-ring | |
| 67 | 1040320 | Plug | |
| 68 | 961780 | Bearing | |
| 69 | 720030 | O-ring | |
| 70 | 3120271 | Screw | Inox C10 AR45LFP |
| 70 | 3120270 | Screw | C10 AR45bp |
| 71 | 3120640 | Ring | |
| 72 | 2840891 | O-ring | Viton AR45LFP |
| 72 | 2840890 | O-ring | AR45bp |
| 73 | 3120170 | Shaft | AR45LFP/bp SP |
| 74 | 3120760 | Washer | Inox |
| 75 | 2280950 | Key | (d) |
| Parts Kit Pag.2 | |||
| Model | Position | Quantity | |
| KIT 43080 | 17 | 3 | |
| Membrane BlueFlex | |||
| BlueFlex diaphragms | |||
| KIT 42521 | 17 | 3 | |
| Membrane NBR | |||
| NBR diaphragms | |||
| KIT 42522 | 17 | 3 | |
| Membrane Viton | |||
| Viton diaphragms | |||
| KIT 42523 | 17 | 3 | |
| Membrane Desmopan | |||
| Desmopan diaphragms | |||
| KIT 42816 | 08-set | 6+6 | |
| Valvole / Valves AR45LFP | |||
| KIT 42524 | 08-set | 6+6 | |
| Valvole / Valves AR45bp | |||
| KIT 43081 | 2-14-40-42-66-69-72 | 24+1+1+1+1+1+1 | |
| OR /O-RingsAR45LFP | |||
| KIT 42525 | 2-14-40-42-66-69-72 | 24+1+1+1+1+1+1 | |
| OR /O-RingsAR45bp | |||
| Services Kit Pag.3 | |||
| KIT 43082 - AR45LFP | |||
| KIT 42526 - AR45bp | |||
| Position | Quantity | ||
| 2 | 4 | ||
| 8 | 6 | ||
| 9 | 6 | ||
| 12 | 1 | ||
| 13 | 1 | ||
| 14 | 1 | ||
| 17 | 3 | ||
| 18 | 3 | ||
| 19 | 1 | ||
| 21 | 3 | ||
| 40 | 1 | ||
| 42 | 1 | ||
| 44 | 1 | ||
| 45 | 1 | ||
| 66 | 1 | ||
| 67 | 1 | ||
| 72 | 1 | ||
| 74 | 3 | ||
