Alpina Brushcutter MT 520 D Spare Parts
€1.54
Tax included
Alpina Brushcutter MT 520 D Spare Parts
STIGA-ALPINA-CASTOR-CASTELGARDEN-Mountfield authorized repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter ALPINA MT 520 D (2019) 289421090/TE1.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Brushcutter MT 520 D Spare Parts
STIGA-ALPINA-CASTOR-CASTELGARDEN-Mountfield authorized repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter ALPINA MT 520 D (2019) 289421090/TE1.In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA MT 520 D (2019) 289421090/TE1 Spare Parts | ||
| Motore Pag.1 | ||
| # | Part Num. | Description |
| 1 | 2135110 | Screw |
| 2 | 2135110 | Screw |
| 3 | 112581500/0 | Grower |
| 4 | 2312090 | Flat washer |
| 5 | 118803135/0 | Starter Handle |
| 6 | 118803923/0 | Eyelet |
| 8 | 118803883/0 | Starter Assy |
| 10 | 118803693/0 | Starter Spring |
| 11 | 118803710/0 | Starter pulley |
| 12 | 118803694/0 | Spring |
| 13 | 118803711/0 | Ratchet wheel |
| 14 | 112728450/0 | Screw |
| 15 | 9699-0087-02 | Washer |
| 16 | 118803859/0 | Gasket |
| 17 | 118803678/0 | Start reel |
| 18 | 2312090 | Flat washer |
| 19 | 118550599/0 | Seal Ring |
| 20 | 118803682/0 | Left Crankcase Assy |
| 21 | 118803683/0 | Crankcase Gasket |
| 22 | 119216048/0 | Bearing |
| 23 | 118803686/0 | Crankshaft |
| 24 | 3151050 | Flywheel Key |
| 25 | 118803918/0 | Bearing |
| 26 | 118550590/0 | Washer, Piston Pin |
| 27 | 118803916/0 | Piston Pin |
| 28 | 118803917/0 | Piston |
| 29 | 118803915/0 | Piston Ring |
| 30 | 118803914/0 | Cylinder Gasket |
| 31 | 118803913/0 | Cylinder |
| 32 | 2135110 | Screw |
| 33 | 112581500/0 | Grower |
| 34 | 2312090 | Flat washer |
| 35 | 3210024 | Spark Plug |
| 36 | 118803876/0 | Top housing |
| 37 | 118803691/0 | Wire |
| 38 | 118803882/0 | Spark Plug Cover |
| 39 | 2135110 | Screw |
| 40 | 112581500/0 | Grower |
| 41 | 2312090 | Flat washer |
| 42 | 118803690/0 | Electronic Coil Euro 1 |
| 42 | 118805671/0 | Electronic Coil Euro 2 |
| 43 | 118803823/0 | Pin |
| 44 | 118803681/0 | Right Crankcase Assy |
| 45 | 2135110 | Screw |
| 46 | 112581500/0 | Grower |
| 47 | 2312090 | Flat washer |
| 48 | 118803860/0 | Oil seal |
| 49 | 118803919/0 | Magneto rotor Euro 1 |
| 49 | 118805672/0 | Magneto rotor Euro 2 |
| 50 | 122131750/0 | Nut |
| 51 | 9699-0028-02 | Flat washer |
| 52 | 118803679/0 | Clutch Ass.Y |
| 53 | 112521360/0 | Washer |
| 54 | 118803677/0 | Screw |
| 55 | 118803823/0 | Pin |
| 56 | 118803877/0 | Fan cover |
| 57 | 2135110 | Screw |
| 58 | 112581500/0 | Grower |
| 59 | 2312090 | Flat washer |
| 60 | 118803697/0 | Clutch Drum |
| 61 | 112610800/0 | Snap Ring |
| 62 | 119216048/0 | Bearing |
| 63 | 112609200/0 | Snap Ring |
| 64 | 118803889/0 | Housing |
| 65 | 2135110 | Screw |
| 66 | 112581500/0 | Grower |
| 67 | 2312090 | Flat washer |
| 68 | 118803920/0 | Joint |
| 69 | 118803922/0 | Lower Support |
| 70 | 118803921/0 | Upper support |
| 71 | 2135110 | Screw |
| 72 | 112581500/0 | Grower |
| 73 | 2312090 | Flat washer |
| 74 | 2135110 | Screw |
| 75 | 112581500/0 | Grower |
| 76 | 2312090 | Flat washer |
| 77 | 2135110 | Screw |
| 78 | 112581500/0 | Grower |
| 79 | 2312090 | Flat washer |
| 80 | 2135110 | Screw |
| 81 | 112581500/0 | Grower |
| 82 | 2312090 | Flat washer |
| 83 | 118803707/0 | Muffler Guard |
| 84 | 118803688/0 | Muffler |
| 85 | 118803706/0 | Muffler Gasket |
| 86 | 118803676/0 | Muffler Gasket |
| 87 | 2135110 | Screw |
| 88 | 112581500/0 | Grower |
| 89 | 2312090 | Flat washer |
| 90 | 2135110 | Screw |
| 91 | 112581500/0 | Grower |
| 92 | 2312090 | Flat washer |
| 93 | 118803675/0 | Gasket |
| 94 | 118803708/0 | Admitting pipe |
| 96 | 118803830/0 | Screw |
| 97 | 2135110 | Screw |
| 98 | 112581500/0 | Grower |
| 99 | 2312090 | Flat washer |
| 100 | 118550587/0 | Carburettor Gasket |
| 101 | 118803709/0 | Carburetor |
| 102 | 118803880/0 | Filter Cover |
| 103 | 118803881/0 | Spone |
| 104 | 2135110 | Screw |
| 105 | 112581500/0 | Grower |
| 106 | 2312090 | Flat washer |
| 107 | 118803879/0 | Air box base |
| 108 | 118803878/0 | Air box assembly |
| 109 | 118803886/0 | Fuel Tank Cap |
| 110 | 118803888/0 | Rubber |
| 111 | 118803887/0 | Rod |
| 112 | 118803885/0 | Fuel Tank |
| 113 | 118803712/0 | Rubber bump |
| 114 | 118803875/0 | Housing |
| 115 | 2135110 | Screw |
| 116 | 112581500/0 | Grower |
| 117 | 2312090 | Flat washer |
| 118 | 118800198/0 | Breather Valve Ass.Y |
| 119 | 118803105/0 | Oil return pipe |
| 120 | 118803107/0 | Fuel Tube |
| 121 | 118803105/0 | Oil return pipe |
| 122 | 118803106/0 | Retainer |
| 123 | 118803924/0 | Snap Ring |
| 124 | 118800199/0 | Fuel Filter |
| 125 | 118805059/0 | Intake Manifold Kit |
| Transmission Pag.2 | ||
| # | Part Num. | Description |
| 1 | 118802596/0 | Wire Buckle |
| 2 | 118803862/0 | Harness clamp assembly |
| 3 | 6981434 | Screw |
| 4 | 118803861/0 | Camp |
| 5 | 2432040 | Nut |
| 6 | 118803890/0 | Straight shaft assembly |
| 9 | 118804850/0 | Gear box assembly |
| 24 | 118803848/0 | Ring Nut |
| 25 | 118803849/0 | Spacer |
| 26 | 118804856/0 | Blade retainer |
| 27 | 118803845/0 | Washer |
| 28 | 118803847/0 | Bottom Guard |
| 29 | 118803828/0 | Nut |
| 30 | 118803827/0 | Screw |
| 31 | 2132110 | Screw |
| 32 | 112581500/0 | Grower |
| 33 | 2312090 | Flat washer |
| 34 | 2132180 | Screw |
| 35 | 112581500/0 | Grower |
| 36 | 2312090 | Flat washer |
| 37 | 118804857/0 | Drive Shaft |
| 38 | 118803724/0 | Lower Guard |
| 39 | 118803830/0 | Screw |
| 40 | 118803723/0 | Cutting Blade |
| 41 | 118803725/0 | Safety Cover |
| 42 | 118803909/0 | Camp |
| 43 | 2132180 | Screw |
| 44 | 112581500/0 | Grower |
| 45 | 2312090 | Flat washer |
| 46 | 118803892/0 | Rubber handle |
| 47 | 118803891/0 | AL tubing |
| 48 | 118803908/0 | Knob |
| 49 | 112521331/0 | Washer |
| 50 | 118803901/0 | Upper support |
| 51 | 118803902/0 | Support |
| 52 | 118803903/0 | Lower Support |
| 53 | 2432040 | Nut |
| 54 | 118803904/0 | Support |
| 55 | 6981263 | Outfit, Screws |
| 58 | 118803893/0 | Handle Assy |
| 59 | 6981435 | Screw |
| 60 | 118803895/0 | Semi-Handgrip, Left |
| 61 | 118803898/0 | Lock trigger |
| 62 | 118803900/0 | Jacket Tube |
| 63 | 118803906/0 | Wire cable |
| 64 | 118803907/0 | Wire cable |
| 65 | 118803905/0 | Throttle cable assembly |
| 66 | 2432040 | Nut |
| 67 | 118803830/0 | Screw |
| 68 | 118803830/0 | Screw |
| 69 | 118803894/0 | Semi-Handgrip, Right |
| 70 | 118803897/0 | Spring |
| 71 | 118803896/0 | Trigger |
| 72 | 118803899/0 | Spring |
| 73 | 118800202/0 | Switch |
| 74 | 118802316/0 | Blade 3 arc |
| 75 | 118804855/0 | Sleeve |
