Alpina Spare Parts for Brushcutter BJC 336 (2013)
€1.41
Tax included
Alpina Spare Parts for Brushcutter BJC 336 (2013)
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter BJC 336 (2013) 280220001/ALP.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter BJC 336 (2013)
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter BJC 336 (2013) 280220001/ALP.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA BJC 336 (2013) 280220001/ALP - Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118801251/0 | Screw |
| 2 | 118801250/0 | Hub |
| 4 | 118801249/0 | Starter Pulley |
| 5 | 118801252/0 | Starter cord |
| 6 | 118804060/0 | Spring |
| 9 | 118801263/0 | Starter Handle |
| 10 | 118801264/0 | Retainer |
| 11 | 118801262/0 | Starter Ass.Y Black |
| 12 | 2135030 | Screw |
| 13 | 118801254/0 | Starter Cup Ass.Y |
| 17 | 119035159/0 | Seal Ring |
| 18 | 123685026/0 | Crank Case |
| 19 | 123280047/0 | Crankcase Gasket |
| 20 | 114215218/0 | Ball Bearing |
| 21 | 123020025/0 | Crankshaft |
| 22 | 123072002/0 | Flywheel Key |
| 24 | 123685027/0 | Crank Case |
| 25 | 2135060 | Screw |
| 26 | 123880018/0 | Flywheel |
| 29 | 112154200/0 | Nut |
| 30 | 118805187/0 | Ignition Coil |
| 32 | 2135030 | Screw |
| 35 | 123430583/0 | Clutch Unit |
| 37 | 123878058/0 | Screw |
| 53 | 123235007/0 | Needle Bearing |
| 54 | 123202009/0 | Circlip |
| 55 | 123760007/0 | Piston Pin |
| 56 | 123590008/0 | Piston |
| 57 | 123204010/0 | Piston Ring |
| 58 | 123280045/0 | Cylinder Gasket |
| 59 | 123071024/0 | Cylinder |
| 60 | 112760475/0 | Screw |
| 61 | 3210024 | Spark Plug |
| 63 | 118801258/0 | Spark Plug Cover |
| 64 | 123275023/0 | Grommet |
| 65 | 118801461/0 | Red Cylinder Cover |
| 67 | 118801464/0 | Red Cover |
| 68 | 112788910/0 | Screw |
| 69 | 123280041/0 | Intake Manifold Gasket |
| 70 | 123073509/0 | Intake Manifold |
| 71 | 2135030 | Screw |
| 72 | 118801227/0 | Carburetor Gasket |
| 73 | 123054025/0 | Carburetor |
| 74 | 118801229/0 | Lever |
| 75 | 118801228/0 | Air Filter Support + Cover |
| 76 | 123190000/0 | Shutter |
| 78 | 2132160 | Screw |
| 79 | 123220011/0 | Air Filter |
| 80 | 118801298/0 | Filter Cover Red |
| 81 | 118801267/0 | Muffler Gasket |
| 83 | 183740022/0 | Muffler |
| 85 | 118801256/0 | White Cover |
| 88 | 2122210 | Screw |
| 89 | 123280060/0 | Rubber Gasket |
| 90 | 112788910/0 | Screw |
| 91 | 118801265/0 | Fuel Tank |
| 92 | 118801266/0 | Lower Guard |
| 93 | 2135030 | Screw |
| 94 | 2135200 | Screw |
| 95 | 118801319/0 | Tube |
| 96 | 118801318/0 | Grommet |
| 97 | 118801313/0 | Fuel Line |
| 98 | 183520005/0 | Intake Filter |
| 99 | 118801243/0 | Fuel Tank-Cap Ass.Y |
| Handle-Trasmission Pag.2 | ||
| 1 | 123050012/0 | Clutch Drum Assy |
| 2 | 2122080 | Screw |
| 3 | 118801261/0 | Guard |
| 4 | 112610800/0 | Seeger |
| 5 | 119216048/0 | Bearing |
| 6 | 112609200/0 | Seeger |
| 7 | 118801259/0 | Clutch Case |
| 8 | 112760475/0 | Screw |
| 9 | 118801260/0 | Button |
| 10 | 118801316/0 | Reduction |
| 11 | 118801311/0 | Reduction |
| 12 | 118801310/0 | Support |
| 13 | 118801309/0 | Support |
| 14 | 2135020 | Screw |
| 15 | 2135030 | Screw |
| 21 | 183869073/0 | Assy Transm. Tube+Flex |
| 22 | 123020038/0 | Trasmission Shaft |
| 31 | 118801337/0 | Clamp |
| 32 | 112789000/0 | Screw |
| 33 | 118801335/0 | Safety Lever, Red |
| 34 | 118801336/0 | Throttle Lever, Red |
| 35 | 118801334/0 | Spring |
| 36 | 118801373/0 | Right Handgrip,Black |
| 37 | 112735105/0 | Screw |
| 38 | 118801354/0 | Throttle Cable |
| 40 | 118801333/0 | Spring |
| 41 | 118801329/0 | Stop Knob,Red |
| 43 | 118801330/0 | Stop Plate |
| 44 | 118801338/0 | Spring |
| 45 | 118801328/0 | Stop Wire |
| 46 | 118801375/0 | Left Handgrip,Black |
| 50 | 118801322/0 | Stop Wire Adapter |
| 51 | 183780002/0 | Harness Support |
| 52 | 123170004/0 | Spacer |
| 55 | 118801382/0 | Front Handle Assy, Black |
| 71 | 118801327/0 | Harness |
| Gear Case Pag.3 | ||
| 1 | 183820507/0 | Gear case assy |
| 6 | 112727801/0 | Screw |
| 7 | 112789000/0 | Screw |
| 8 | 112727794/0 | Screw |
| 10 | 123670002/0 | Guard |
| 15 | 123250002/0 | Upper Ring Nut |
| 16 | 123250003/0 | Lower Ring Nut |
| 18 | 123120015/0 | Nut |
| 21 | 123784012/0 | Support |
| 22 | 2135050 | Screw |
| 23 | 2135180 | Screw |
| 24 | 118801341/0 | Safety Cover, Black |
| 25 | 112735654/0 | Screw |
| 26 | 118801342/0 | Guard, Black |
| 27 | 112728099/1 | Screw |
| 28 | 123311013/0 | Line Cutter Blade |
| 31 | 123155009/0 | 2 Hedges Nylon Head |
| 32 | 123155010/0 | 3 Teeth Disc |
