FIAC Spare Parts for Petrol Engine Air Compressors S50-360 - AB360 - Honda
€30.99
Tax included
FIAC Spare Parts for Petrol Engine Air Compressors S50-360 - AB360 - Honda
Genuine Parts FIAC for Air compressors with petrol engines S50-360 for use where there is no available electric power supply. Designed with wide-track gauge to facilitate their transport, they have large all-terrain tyres to make it easier to move them.- The range is equipped with 4, 5.5 and 9 HP Honda petrol engines
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Spare Parts for Petrol Engine Air Compressors S50-360 - AB360 - Honda
Genuine Parts FIAC for Air Air compressors with petrol engines S50-360 for use where there is no available electric power supply. Designed with wide-track gauge to facilitate their transport, they have large all-terrain tyres to make it easier to move them on impracticable ground. Equipped with pressure regulator/filter and, in the Agri models, also with a lubricator, they are remarkably powerful, sturdy, versatile, handy and easy to use.
- The range is equipped with 4, 5.5 and 9 HP Honda petrol engines.
In the following table, look for the type of the air compressor and the respective parts of the code .
| Petrol Engine S50 Pump Unit AB 360 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 4080430000 | Kit Screws |
| 1 | 4083140000 | Kit Rubber Foot |
| 1 | 5140210008 | Roll Bar |
| 1 | 7080770000 | The Fitting MF 1/2 |
| 1 | 7152570000 | Spacer |
| 1 | 7195170000 | Automatic Unloading Valve 1/2" |
| 1 | 7237311000 | Tube Feeding |
| 2 | 5152750008 | Tank 50lt |
| 2 | x | Tube Connector |
| 22 | 7062680000 | Bush |
| 23 | 7080160000 | Fitting "L" 1/2 |
| 24 | 7080770000 | The Fitting MF 1/2 |
| 25 | 7082050000 | Fitting "T" 1/4 FFM |
| 26 | 7085020000 | Fitting 1/2 "-3/8" MF |
| 27 | 7085170000 | Fitting 1/4 "-3/8" MM |
| 28 | 7100640000 | Pressure Reducer |
| 29 | 7110240000 | Gauge Ø40-1 / 8 " |
| 30 | 7110480000 | Gauge |
| 31 | 7130160000 | Bleeding Tap M3 / 8 " |
| 32 | 7130440000 | MF Ball Valve 1/4 " |
| 33 | 7130580000 | MF Ball Valve 3/8 " |
| 34 | 7152570000 | Spacer |
| 35 | 7192090000 | Valve Sic. 3/8 "10,4BAR |
| 36 | 7195170000 | Automatic Unloading Valve 1/2" |
| 37 | 7237311000 | Tube Feeding |
| 38 | 4170030000 | Belt Guard Kit |
| 41 | x | Tube Connector |
| 42 | 7370060000 | TRAP Belt. A 46 |
| 43 | 7382680000 | Combustion Engine |
| 44 | 7409090000 | Pulley Øp100-1 "A" F.19,04 |
| 45 | 7458200000 | Belt Guard Bracket |
| 46 | 7458940000 | Belt Guard Bracket |
| 47 | 9101880000 | Pumping Unit AB360 |
| 100 | 4080430000 | Kit Screws |
| 102 | 4083140000 | Kit Rubber Foot |
| Pump Unit AB 360 Spare Parts Pag.2 | ||
| # | Part Num. | Description |
| 1 | 9100270110 | Carter |
| 2 | 9100270120 | Crankcase Bottom cover |
| 4 | 9100270130 | seal |
| 5 | 9100270140 | Crankshaft |
| 6 | 7060180000 | Bearing 6203 "17X40X12 |
| 7 | 7060200000 | bearing 6204 |
| 8 | 9100270150 | Oil seal Ø20x47x7 |
| 9 | 9100270160 | front cover |
| 10 | 9100270170 | back cover |
| 11 | 9100280010 | O-ring 144 |
| 12 | 7011420000 | Screw M6X16 UNI-5739 |
| 13 | 9100280020 | Tang 4x6,5 |
| 14 | 9100270010 | piston rod |
| 15 | 9100270020 | pin |
| 16 | 9100270030 | piston |
| 17 | 4080120000 | Kit segments |
| 18 | 9100270070 | Seeger |
| 19 | 9100270080 | cylinder |
| 20 | 7011100000 | Screw M8X25 UNI-5739 |
| 21 | 9100280070 | Oil Level |
| 22 | 9100270180 | seal |
| 23 | 9100270190 | seal |
| 24 | 9100270090 | valves plate |
| 25 | 9100270200 | Gasket |
| 26 | 9100280090 | valve |
| 27 | 9100270210 | Gasket |
| 28 | 9100270100 | top |
| 29 | 7458340000 | filter plate |
| 30 | 9100010210 | filter element |
| 31 | 9100270240 | Air filter cover |
| 32 | 7012060000 | Screw M4X12 UNI-8112 |
| 33 | 7010080000 | Screw M8x35 UNI-5931 |
| 34 | 9100270220 | conveyor |
| 35 | 7012090000 | Screw M5x12 UNI-8112 |
| 36 | 7011420000 | Screw M6X16 UNI-5739 |
| 37 | 9100280110 | stopper |
| 38 | 7030270000 | Washer Ø8,5X30X4 UNI-6593 |
| 39 | 9100270230 | flywheel |
| 40 | 7011100000 | Screw M8X25 UNI-5739 |
| 41 | 7031010000 | Washer Ø8 UNI-3703 |
| 100 | 9100270260 | Kit valves plate |
| 101 | 9700000078 | seal Kit |
| 102 | 4291140000 | Piston Kit |
| 103 | 9700010170 | Conrod Piston Kit |
