Alpina Spare Parts for Lawn Mower BL 460
ALPINA authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Lawn Mower BL 460/295491044/A19-2019.
In the following table, look for the model of the Lawn Mower and the respective parts of the code.
| Lawn Mower BL 460/295491044/A19-2019 | ||
| Chassis Pag.1 | ||
| # | Part Num. | Description |
| 1 | 381004947/0 | Black Chassis |
| 2 | 322108301/2 | Front Baffle |
| 3 | 112728699/0 | Screw |
| 4 | 322108302/0 | Rear Baffle To 31-August-2017 |
| 4 | 322108392/0 | Rear Baffle From 01-September-2018 |
| 5 | 112728699/0 | Screw |
| 6 | 322545213/0 | Plate |
| 7 | 381005139/0 | Left Bracket |
| 8 | 112727801/0 | Screw |
| 9 | 381005137/0 | Right Bracket |
| 10 | 322060242/1 | Belt Cover |
| 10 | 322060242/2 | Belt Cover |
| 11 | 322140239/1 | Mulching Deflector |
| 12 | 112728531/0 | Screw |
| 13 | 322820077/1 | Cap |
| 14 | 112728450/0 | Screw |
| 15 | 119035000/0 | O-R |
| 16 | 322034002/0 | Water Joint |
| 17 | 322055605/0 | Insert |
| Cutting Height Adjustment Pag.2 | ||
| 1 | 322545189/0 | Plate |
| 2 | 322735597/0 | Left Height Adjustment Sector |
| 2 | 322735597/1 | Height Adjustment Sector |
| 3 | 381005141/0 | Wheel Support |
| 3 | 381005159/0 | Wheel Support |
| 3 | 381005253/0 | Wheel Support |
| 4 | 381003354/0 | Height Adjustment Lever |
| 5 | 122519811/0 | Pin |
| 6 | 112521350/0 | Washer |
| 7 | 112155000/0 | Nut |
| 8 | 322545211/0 | Plate |
| 9 | 322735595/0 | Right Height Adjustment Sector |
| 9 | 322735595/1 | Height Adjustment Sector |
| 10 | 322600247/0 | Wheel Protection |
| Handle, Lower Side Pag.3 | ||
| 1 | 381006737/0 | Handle, Lower Side |
| 2 | 112819110/0 | Screw |
| 3 | 122671651/0 | Washer |
| 4 | 322399840/0 | Yellow knob |
| 5 | 112293200/0 | Nut |
| 7 | 112818900/0 | Screw |
| 9 | 322399840/0 | Yellow knob |
| 10 | 112293200/0 | Nut |
| 11 | 112155000/0 | Nut |
| 12 | 112521350/0 | Washer |
| 13 | 112369500/0 | Elastic Disc |
| 14 | 112760605/0 | Screw |
| 15 | 381008692/0 | Screw Kit |
| Handle, Upper Side Pag.4 | ||
| 1 | 381006740/0 | Handle, Upper Side |
| 2 | 112727783/0 | Screw |
| 3 | 322551640/0 | Plate |
| 4 | 112154510/0 | Nut |
| 5 | 181030053/0 | Motor Brake Cable |
| 6 | 381003394/0 | Yellow Engine Brake Lever |
| 6 | 381003394/1 | Yellow Engine Brake Lever |
| 7 | 112154510/0 | Nut |
| 8 | 112521330/0 | Washer |
| 9 | 122430313/0 | Guide spring |
| Wheel Pag.5 | ||
| 1 | 381007447/1 | Wheel - Long Hub |
| 1 | 381007448/0 | Wheel |
| 1 | 381007448/1 | Wheel - Long Short |
| 2 | 119216035/0 | Bearing |
| 3 | 322110687/0 | Gray hubcap |
| 5 | 381007447/1 | Wheel - Long Hub |
| 5 | 381007448/0 | Wheel |
| 5 | 381007448/1 | Wheel - Long Short |
| 6 | 119216035/0 | Bearing |
| 9 | 322110687/0 | Gray hubcap |
| Blade Pag.6 | ||
| 1 | 112735108/1 | Screw |
| 2 | 122463012/4 | Blade Boss Ø 22.2 |
| 3 | 181004460/0 | Mulching blade |
| 4 | 322680021/0 | Washer |
| 5 | 112508128/0 | Elastic Disc |
| 6 | 112735698/0 | Screw |
| 7 | 112139100/0 | Woodruff Key |
| Grass Bag Pag.7 | ||
| 1 | 322785331/0 | Support |
| 2 | 122450464/0 | Spring |
| 3 | 322109556/0 | Cover, Yellow |
| 3 | 322109557/0 | Cover, Gray |
| 4 | 112728699/0 | Screw |
| 5 | 322600206/1 | Black Stone Guard |
| 5 | 322600214/1 | Yellow Stone Guard |
| 5 | 322600216/1 | Grey Stone Guard |
| 6 | 181006409/0 | Frame bag |
| 6 | 181006409/1 | Frame bag |
| 7 | 181002319/0 | Bag |
| 8 | 381008163/0 | Black Stone guard Assy |
| 8 | 381008164/0 | Yellow Stone guard Assy |
| 8 | 381008166/0 | Grey Stone guard Assy |
| 9 | 381008735/0 | Kit plastic pin |
| Engine - Carburator, Fuel Tank Pag.8 | ||
| 2 | 112292102/0 | Nut |
| 3 | 118551467/0 | Starter Assy |
| 4 | 118551362/0 | Starting handle |
| 8 | 112789000/0 | Screw |
| 9 | 118551456/0 | Starter control |
| 10 | 118550908/0 | Air conveyor |
| 11 | 118550907/0 | Pin |
| 12 | 118550906/0 | Pin |
| 13 | 112791500/0 | Screw |
| 14 | 118551475/0 | Electronic Coil |
| 16 | 9400-0244-00 | Spark Plug |
| 17 | 118550930/0 | Prisoner |
| 18 | 118550929/0 | Gasket |
| 19 | 118550928/0 | Spacer |
| 20 | 118550927/0 | Gasket |
| 21 | 118551489/0 | Carburetor |
| 22 | 118550924/0 | Gasket |
| 23 | 118551461/0 | Air Filter Assy |
| 24 | 118551459/0 | Rod |
| 25 | 118551352/0 | Stopper |
| 26 | 118550946/0 | Filter |
| 27 | 118550945/0 | Filter |
| 28 | 118550944/0 | Air Filter Cover |
| 29 | 112292102/0 | Nut |
| 30 | 118551481/0 | Fuel Pipe |
| 31 | 118550918/0 | Hose clamp |
| 32 | 118550314/0 | Fuel Filter |
| 33 | 118551454/0 | Tank |
| 34 | 118550943/0 | Tank cap |
| 35 | 112792099/0 | Screw |
| 36 | 118550920/0 | Breather Fuel Pipe |
| 37 | 118550933/0 | Throttle Lever |
| 38 | 118550931/0 | Plate |
| 39 | 112789000/0 | Screw |
| 40 | 118550932/0 | Spring |
| 41 | 118550805/0 | Screw |
| 42 | 118550806/0 | Nut |
| 43 | 118550925/0 | Throttle rod |
| 44 | 118550898/0 | Muffler gasket |
| 45 | 118551464/0 | Muffler |
| 46 | 112792425/0 | Screw |
| 47 | 118550900/0 | Muffler protection |
| 48 | 118551277/0 | Bolt |
| Engine - Piston, Crankshaft Pag.9 | ||
| 18 | 118550929/0 | Gasket |
| 19 | 118550928/0 | Spacer |
| 20 | 118550927/0 | Gasket |
| 44 | 118550898/0 | Muffler gasket |
| 51 | 118550336/0 | Nut |
| 52 | 118550905/0 | Flywheel Assy |
| 53 | 118551277/0 | Bolt |
| 54 | 112791500/0 | Screw |
| 55 | 118551483/0 | Flywheel Brake Assy |
| 56 | 118550911/0 | Spring |
| 57 | 118550300/0 | Seal ring |
| 58 | 118550897/0 | Cylinder Assy |
| 59 | 112789000/0 | Screw |
| 60 | 118550904/0 | Cover |
| 61 | 118550903/0 | Gasket |
| 62 | 118550902/0 | Valve |
| 63 | 118551488/0 | Crankshaft Assy |
| 64 | 118550288/0 | Woodruff |
| 65 | 118550283/0 | Washer |
| 66 | 118550890/0 | Shaft Camm |
| 68 | 112789000/0 | Screw |
| 69 | 118550888/0 | Control |
| 70 | 118550936/0 | Regulator shaft |
| 71 | 118550666/0 | Washer |
| 72 | 118550935/0 | Seal ring |
| 73 | 118550856/0 | Pin |
| 74 | 118550379/0 | Seal ring |
| 75 | 118551209/0 | Engine crankcase |
| 76 | 118550887/0 | Oil cap Assy |
| 77 | 112791500/0 | Screw |
| 78 | 118551276/0 | Bolt |
| 79 | 118550891/0 | Valve Cover |
| 80 | 118550892/0 | Screw |
| 81 | 118550893/0 | Rocker Valve Arm |
| 82 | 118550894/0 | Plate |
| 83 | 118550895/0 | Stopper |
| 84 | 118550896/0 | Spring |
| 85 | 118550910/0 | Valve Assy |
| 86 | 118550291/0 | Valve Lifter |
| 87 | 118550912/0 | Push Rod |
| 88 | 118551482/0 | Piston |
| 89 | 118551445/0 | Piston Ring Assy |
| 90 | 118550915/0 | Piston pin |
| 91 | 118550914/0 | Circlip |
| 92 | 118551487/0 | Conrod Assy |
| 93 | 118551223/0 | Wheat |
| 95 | 118550940/0 | Engine Gasket Assy |
| Cover Engine Pag.10 | ||
| 1 | 322055629/0 | Gray Cover |
| 2 | 322055630/0 | Yellow Cover |
| 3 | 322055627/0 | Gray Cover |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
BL460 - 295491044/A19-2019
11 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
